IE-3100-18T2C-A – 18 Ports – 2 × 1G combo uplinks – industrial switch
|
Condition: |
New Factory Sealed |
|
2/mo Solds | |
|
Warranty: | |
| Related: | |
|
Price: |
Original price was: $8,577.00.$1,874.06Current price is: $1,874.06. |
|
Quantity: |
|
|
Shipping: |
Express Shipping 2-6 Days, via DHL, FedEx, UPS, etc. |
|
Payment: | |
IE-3100-18T2C-A Description
Cisco IE-3100-18T2C-A is a rugged, fan-less DIN-rail Gigabit switch offering 18 copper downlinks and 2 combo SFP/RJ-45 uplinks. With Cisco IOS XE Network Advantage, it unlocks advanced security (MACsec, 802.1X), powerful automation APIs (NETCONF/RESTCONF), and industry-protocol support in extreme –40 °C to 75 °C environments. Known as the IE3100-18T2C rugged switch or industrial gigabit edge switch, it’s perfect for manufacturing, smart infrastructure, and utility networks.
Product Highlights
Ethernet Ports
Combo ports(SFP/RJ-45)
Forwarding Rate
Model Meaning
|
Code segment |
Meaning |
|---|---|
|
IE |
Cisco Industrial Ethernet family |
|
3100 |
IE 3100 Rugged Series |
|
18T |
18 × 10/100/1000 Base-T RJ-45 downlinks |
|
2C |
2 × 1 Gb combo (SFP/RJ-45) uplinks |
|
A |
Network Advantage software license |
Key Features
High-Density Gigabit Switching
20 non-blocking 1 GbE ports (18 RJ-45, 2 combo) deliver line-rate performance for real-time control and video backhaul.
Rugged Industrial Reliability
Fan-less, IP30-rated chassis survives –40 °C to 75 °C, 5–95 % humidity, and IEC-certified shock/vibration.
Flexible Combo Uplinks
Dual SFP/RJ-45 slots enable seamless fiber or copper backhaul, supporting redundant rings and long-distance links.
Advanced IOS XE Network Advantage
Secure Boot, hardware-accelerated MACsec, 802.1X port authentication, plus RESTCONF/NETCONF APIs for zero-touch automation.
Energy-Efficient Design
Typical power draw of 17.7 W with wide 9.6–60 V DC input and reverse-polarity protection for battery or solar applications.
Comprehensive Protocol Support
Native PROFINET, EtherNet/IP, Modbus TCP, PTP timing, and REP/MRP ring recovery for seamless PLC and SCADA integration.
Applications Scenarios
Railway Signaling
High-reliability switching for wayside cabinets and signal controllers.
Wind Farm Controls
Edge aggregation for turbine sensors, SCADA and weather stations.
Mining Automation
Rugged Ethernet in excavators, conveyors and remote monitoring stations.
Rugged Industrial Ethernet Switch Product Comparison
|
Parameter |
IE-3100-18T2C-A | ||
|---|---|---|---|
|
Downlink ports |
18 × RJ-45 |
8 × RJ-45 |
18 × RJ-45 |
|
Uplink ports |
2 × SFP/RJ-45 |
2 × SFP/RJ-45 |
2 × SFP/RJ-45 |
|
Total ports |
20 |
10 |
20 |
|
Software license |
Network Advantage |
Network Advantage |
Network Essentials |
|
Switching capacity |
Line-rate |
Line-rate |
Line-rate |
|
MAC table |
8 000 entries |
8 000 entries |
8 000 entries |
|
Power consumption |
17.7 W typical |
17.7 W typical |
17.7 W typical |
|
Input voltage |
9.6–60 V DC |
9.6–60 V DC |
9.6–60 V DC |
|
Operating temp |
–40 °C–75 °C |
–40 °C–75 °C |
–40 °C–75 °C |
|
Conformal coating |
No |
No |
No |
|
Weight |
1.27 kg |
0.86 kg |
1.27 kg |
IE-3100-18T2C-A Front Panel Overview
The illustrations in this section provide an overview of the variety of components available on the various switch models in this product family. Not all models are illustrated.|
Number |
Feature |
Number |
Feature |
|---|---|---|---|
|
1 |
Dual-media SFP port LEDs |
6 |
Express Setup LED |
|
2 |
Dual-media copper port LEDs |
7 |
System LED |
|
3 |
1000BASE-T port LEDs |
8 |
Alarm input LEDs |
|
4 |
Power connector LED |
9 |
Alarm output LED |
|
5 |
Management console LED |
– |
– |
Get More Information
Discover unbeatable prices and fast shipping for the IE-3100-18T2C-A Access the detailed IE-3100-18T2C-A datasheet and ensure you’re getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via Live chat or email us at [email protected]Quality Certifications
Specifications
| Parameter | Value |
|---|---|
| Model | IE-3100-18T2C-A |
| Total Ports | 20 × 1 GbE |
| Copper Downlinks | 18 × 10/100/1000 RJ-45 |
| Combo Uplinks | 2 × SFP/RJ-45 |
| Software License | Network Advantage |
| Switching Capacity | Line-rate, all ports |
| Forwarding Rate | Line-rate |
| MAC Address Table | 8 000 entries |
| VLANs Supported | 256 |
| IGMP Groups | 512 |
| Egress Queues | 8 hardware queues |
| DRAM | 4 GB |
| SD Card Support | 1/4/16 GB |
| Input Voltage | 9.6–60 V DC |
| Power Consumption | 17.7 W typ. |
| Max Current | 2 A @ 12 V; 0.5 A @ 48 V |
| Dimensions (H×W×D) | 5×4.3×5.08 in |
| Weight | 1.27 kg |
| Operating Temp | –40 °C to 75 °C |
| Storage Temp | –40 °C to 85 °C |
| Relative Humidity | 5–95 % non-condensing |
| Shock | 30 G, 11 ms half-sine |
| Vibration | 5–150 Hz sinusoidal |
| Ingress Rating | IP30 |
| Warranty | 5-year limited hardware |
