PWR-C5-600WAC/2 – 600W AC power supply for Catalyst 9200

Brand: Category: Availability: In Stock Model:

PWR-C5-600WAC/2

(11 customer reviews)
Questions

0/mo Solds

List Price: $1632 $504.83
  • 100% Genuine
    Original, factory-authenticated
  • S/N Verifiable
    Verified by official serial-check
Condition New Factory Sealed Related Quantity
Trusted & Secure Payments
Shipping Express Shipping 2-6 Days, via DHL, FedEx, UPS, etc. Packaging weight and dimensions included:
layer23-switch
Certified Expertise for Project Delivery

CCIE · JNCIE · NSE7 · ACDX · HPE · Dell Server/AI Expert

Stable Global Supply Chain for Thriving Businesses.

  • $3,000,000 Inventory
  • Certified Cisco Partner ships
  • Collaborating with FedEx, UPS, DHL

Free Expert Support from Planning to Deployment

  • Assistance with product selection and network solution design
  • Configuration guidance and best-practice recommendations
  • Troubleshooting support provided by CCIE-level technical experts

Established Global IT Distributor

With over a decade of industry experience, we are a certified Cisco Partner delivering genuine enterprise networking hardware and trusted services to system integrators, ISPs, and enterprises worldwide.

PWR-C5-600WAC/2 Description

PWR-C5-600WAC/2 AC power supply (aka Catalyst 9200 600W PSU Rev 2) is a field-replaceable Cisco OEM module engineered for Catalyst 9200 and 9200L switches. This Rev 2 spare delivers 54 VDC at up to 11.1 A, ensuring sustained PoE+ performance. The universal 100–240 VAC input (IEC 320-C16), 20 ms hold-up, and efficient thermal profile (2,047 BTU/hr) guarantee enterprise-grade reliability. Its compact 1.58″ × 4.0″ × 7.6″ design and 0.77 kg weight facilitate quick installation. Ideal for high-availability networks, the PWR-C5-600WAC/2 maximizes uptime and protects critical infrastructure.

Model Meaning

Model Code

Meaning

PWR

Power Supply

C5

Cisco Catalyst 5th-generation (Catalyst 9200/9200L series)

600W

Maximum DC output power: 600 Watts

AC

Alternating‐current input

/2

Revision 2 (updated internal components for enhanced reliability)

Supported Platforms

    Model comparison

    Model

    Rated Power

    Input Voltage

    Output Voltage

    Output Current

    Holdup Time

    BTU/hr

    Dimensions

    Weight

    Connector

    PWR-C5-125WAC=

    125 W

    100–240 VAC, 50–60 Hz

    12 VDC

    10.5 A

    ≥ 20 ms

    426.5 BTU/hr

    1.58″ × 4.0″ × 7.6″

    1.5 lb (0.68 kg)

    IEC 320-C14

    PWR-C5-600WAC/2

    600 W

    100–240 VAC, 50–60 Hz

    54 VDC

    11.1 A

    ≥ 20 ms

    2 047.3 BTU/hr

    1.58″ × 4.0″ × 7.6″

    1.7 lb (0.77 kg)

    IEC 320-C16

    PWR-C5-1KWAC=

    1 000 W

    100–240 VAC, 50–60 Hz

    54 VDC

    16.5 A

    ≥ 20 ms

    3 412 BTU/hr

    1.58″ × 4.0″ × 7.6″

    2.0 lb (0.90 kg)

    IEC 320-C16

    Specifications

    Parameter Specification Parameter Specification
    Model PWR-C5-600WAC/2 Rated Power 600 W
    Input Voltage 100–240 VAC, 50–60 Hz Input Current 7 A–2.8 A
    Output Voltage 54 VDC Output Current 11.1 A
    Holdup Time ≥ 20 ms at 100 VAC BTU/hr 2 047.3 BTU/hr
    Dimensions 1.58″ × 4.0″ × 7.6″ Weight 1.7 lb (0.77 kg)
    Connector IEC 320-C16 Compliance UL/CE/CCC certified

    Get More Information

    Discover unbeatable prices and fast shipping for the PWR-C5-600WAC/2 Access the detailed PWR-C5-600WAC/2 datasheet and ensure you’re getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via Live chat or email us at [email protected]

    Quality Certifications

    Customer Reviews

    Write A Review
    5.0
    (11 reviews)
    5 Stars
    11
    4 Stars
    0
    3 Stars
    0
    2 Stars
    0
    1 Stars
    0
      Elena V.
      Posted on 18/09/2025
      Verified Buyer
      5.0

      Arrived safely in Europe. Packaging was robust.

      Michael Ross
      Posted on 25/06/2025
      Verified Buyer
      5.0

      Honest vendor. What you see is what you get. Brand new seals.

      Supply Chain
      Posted on 14/02/2025
      Verified Buyer
      5.0

      Smooth import process to Germany. Documentation was perfect.

      Izabella James
      Posted on 11/05/2024
      Verified Buyer
      5.0

      Arrived fast, great support, would purchase again.

      Lennox Martinez
      Posted on 18/04/2024
      Verified Buyer
      5.0

      Original Cisco, no compatibility problems, runs quietly.

    Questions & Answers

    • How to troubleshoot a dual 600W supply for C5 series if no power is delivered?

      First, check that both AC cords are securely plugged in. Inspect LEDs on both modules, reseat each unit, and check system logs for error codes.

    • Is every needed accessory included with the C5 dual supply package?

      Yes, the kit typically contains two AC modules, power cords, mounting brackets, and a quick installation guide.

    • How does this twin 600W unit differ from a single module setup?

      The dual unit provides redundancy, allowing one module to power the switch if the other fails, while a single module does not.

    • Can this supply set be swapped with compatible alternatives?

      Use only compatible Cisco modules for best reliability. Always check your model’s supported supply list.

    • What scenarios require two 600W AC modules working in tandem?

      Ideal for core or aggregation layer switches needing high uptime or supporting large PoE loads.

    • What safety warnings come with dual power supply installs?

      Disconnect both modules from mains, let the device discharge, and wear anti-static gear during replacement.

    • Is this solution supported by all C5-compatible hardware?

      Not all models support dual supplies; always check your switch’s hardware guide.

    • How do I confirm that both supplies in the set are online?

      Use `show environment power` to see both modules and check that LEDs are green on each.

    • Does this dual module need software updates?

      No update is needed for the modules themselves, but always use the latest switch software.

    • What fault indicators should I look for on either module?

      Amber or red LEDs or CLI error messages indicate a fault requiring further investigation.

    • Is regular maintenance required, and how often?

      Inspect and dust modules every quarter, more frequently in dusty rooms.

    • Is live replacement of either supply possible?

      Yes, if your switch supports hot-swap, you can replace one module while the other powers the device.

    • What is the max PoE support for the twin supply set?

      Redundant supplies can handle higher PoE demand, but total output depends on both the modules and the switch.

    • Where can I read official Cisco guides for dual installs?

      Official hardware and installation guides are on the Cisco support portal.

    • How to confirm both modules are authentic Cisco parts?

      Look for Cisco labels, holograms, and serials. Purchase only from official distributors.

    • What are the ideal operating conditions for this kit?

      Operate in clean, cool environments—0–40°C (32–104°F) with good ventilation.

    • Does losing one module affect network uptime?

      Redundancy is lost but network stays online if the remaining module can handle the load.

    • How can I check supply status using CLI?

      Use `show power` and review both module entries for errors.

    • What is the best way to store a spare dual supply?

      Keep in anti-static packaging in a cool, dry place.

    • What support options are available for this set?

      Warranty and support are available from Cisco via TAC or your reseller.
