C-NIM-8T Description
The C-NIM-8T is a Cisco Catalyst 8000 Series LAN/WAN network interface module for branch routers that need more copper Ethernet ports. Eight RJ-45 ports run at 10M/100M/1G as Layer 2 switch ports by default, and the module supplies no PoE to attached devices. Only ports 6 and 7 can be converted to Layer 3 WAN ports with MACsec, and the module needs a direct NIM slot on a Catalyst 8200, 8200L or 8300 router running Cisco IOS XE 17.11.1 or later.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
C-NIM-8T |
|
Connection media |
8 x RJ-45 |
|
Port speeds |
10M/100M/1G |
|
Power over Ethernet (PoE) |
Not supported |
|
Native Layer 3 ports |
Ports 6 and 7 (last two ports) |
|
MACsec support |
IEEE 802.1AE; 256-bit WAN MACsec in Layer 3 mode, 128-bit LAN MACsec in Layer 2 mode |
|
Supported platforms |
C8300-1N1S-6T, C8300-1N1S-4T2X, C8300-2N2S-6T, C8300-2N2S-4T2X, C8200-1N-4T, C8200L-1N-4T |
|
Installation slot |
NIM slot only; C-SM-NIM-ADPT carrier not supported |
|
Minimum Cisco IOS XE release |
17.11.1 Universal Image |
Application Scenarios
In a small branch office, the router doubles as the site’s LAN switch: desktops, printers and other wired devices plug into the module’s RJ-45 ports, with voice and data kept on separate VLANs and fewer devices to manage.
Where a carrier delivers a copper Ethernet circuit, port 6 or port 7 is converted to a Layer 3 WAN interface and can encrypt the link to the provider edge with 256-bit WAN MACsec.
Product Comparison
|
Parameter |
C-NIM-8T | ||
|---|---|---|---|
|
Port speeds |
10M/100M/1G |
100M/1G/2.5G |
1G/10G |
|
Connection media |
8x RJ-45 |
8x RJ-45 |
4x SFP/SFP+ |
|
Power over Ethernet (PoE) |
No |
Yes, 802.3af, 802.3at and 802.3bt compliant |
No |
|
UPOE+ power |
Not applicable |
Up to 360W (4x 90W) |
Not applicable |
|
Catalyst 8000 edge platforms family support |
Catalyst 8300 and 8200 Series and 8200L |
Catalyst 8300 and 8200 Series and 8200L |
Catalyst 8300 Series |
|
Minimum required Cisco IOS version |
17.11.1 |
17.12.2 |
17.11.1 |
C-NIM-8T and C-NIM-8M both carry eight RJ-45 ports, but C-NIM-8T runs them at 10M/100M/1G with no PoE, while the PoE model runs 100M/1G/2.5G and supplies up to 360W of UPOE+ at 90W per port on four ports. Branches that power access points, IP phones or cellular gateways from the router, or that need 2.5G copper links, order C-NIM-8M, provided the router runs Cisco IOS XE 17.12.2 rather than 17.11.1. Sites that need SFP-based fiber ports at 1G or 10G move to C-NIM-4X with four SFP/SFP+ ports, but only on a Catalyst 8300 Series router; Catalyst 8200 and 8200L hosts take the two RJ-45 modules.
Ordering Checklist
- Catalyst 8300 hosts: C8300-1N1S-6T, C8300-1N1S-4T2X, C8300-2N2S-6T and C8300-2N2S-4T2X, with the module in a direct NIM slot. The C-SM-NIM-ADPT carrier does not support it.
- Catalyst 8200 hosts: C8200-1N-4T and C8200L-1N-4T both accept the module in their single NIM slot, and C8200L-1N-4T support applies with a 1G uplink.
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | C-NIM-8T | Cisco ordering description | Cisco 8-port 10M/100M/1G LAN/WAN with IEEE 802.1AE MACsec |
| Spare PID | C-NIM-8T= | Form factor | Network Interface Module (NIM) |
| Connection media | 8 x RJ-45 | Port speeds | 10M/100M/1G |
| Power over Ethernet (PoE) | Not supported | 10G backplane connection | Yes |
| Native Layer 3 ports | Ports 6 and 7; ports 0 to 5 Layer 2 only | Flex port default mode | Layer 2; converted to Layer 3 with no switchport |
| Layer 3 features | Feature parity with Catalyst 8300 Series onboard ports | First-hop redundancy on VLAN interfaces | HSRP, VRRP and GLBP |
| MACsec support | IEEE 802.1AE | WAN MACsec | 256-bit, on the last two flex ports in Layer 3 mode |
| LAN MACsec | 128-bit in Layer 2 mode; switch-to-switch supported, switch-to-host not supported | 1G WAN MACsec peers | Up to 8 per port |
| Layer 2 features | 802.1Q trunking, 802.1D STP, PVST, VTP (client, server, transparent), voice VLAN, IGMP snooping, 802.1X with CoA and posture validation, SPAN, port security, Auto-MDIX | Layer 2 port-channels | Not supported |
| Maximum number of VLANs supported | 1024 | Maximum number of VLAN IDs | 4095 |
| QoS queues | Eight per port; strict priority by default, SDWRR scheduling | Spanning tree protocol instances | 1 per VLAN (max 128) |
| Secure MAC addresses | Up to 100 | Jumbo frames | 8 kB |
| Jumbo MTU on C8300-2N2S-4T2X and C8300-2N2S-6T | 2048 | OIR support | Yes |
| Supported platforms | C8300-1N1S-6T, C8300-1N1S-4T2X, C8300-2N2S-6T, C8300-2N2S-4T2X, C8200-1N-4T, C8200L-1N-4T | C8200L-1N-4T support | Yes, with 1G uplink |
| Installation slot | NIM slot only | C-SM-NIM-ADPT carrier support | Not supported |
| LAN/WAN modules per chassis | 1 | NIM slots on host | 1 on C8300-1N1S and Catalyst 8200 models; 2 on C8300-2N2S models |
| Minimum Cisco IOS XE release | 17.11.1 Universal Image | Cisco Catalyst SD-WAN manager release | 20.11 or later |
| Flex-Switch mode activation | Router reload after first insertion | Dimensions (H x W x D) | 1.25 x 3.50 x 7.24 in. (32 x 89 x 184 mm) |
| Weight | 8.1 oz (230 g) | Operating temperature at sea level | -5°C to 55°C (23°F to 131°F) |
| Storage temperature | -40°C to 70°C (-38°F to 150°F) | Relative humidity | 5 to 95% |
| Operating humidity | 5 to 85% |
Get More Information
Need pricing, stock, or shipping details for the C-NIM-8T ? Layer23-Switch can help you check current availability, lead time, and delivery options for this. Send us the part number, quantity, and destination country via live chat or email [email protected] for a fast quotation.
Quality Certifications
Customer Reviews
Questions & Answers
-
How many MACsec peers does a 1G WAN port on C-NIM-8T support?
-
Does C-NIM-8T support LAN MACsec to the router host?
-
Which NFVIS release supports C-NIM-8T in a Catalyst 8300 uCPE?
-
Can C-NIM-8T be fitted in a C-SM-NIM-ADPT carrier on a Catalyst 8300?
