FPR2130-ASA-K9 – 10G ASA Firewall – 12xRJ45 4×1/10G SFP+ – NetMod Bay
3/mo Solds
Established Global IT Distributor
With over a decade of industry experience, we are a certified Cisco Partner delivering genuine enterprise networking hardware and trusted services to system integrators, ISPs, and enterprises worldwide.
FPR2130-ASA-K9 Description
FPR2130-ASA-K9 is a Cisco Firepower 2130 ASA firewall appliance for branch, campus edge, and data center firewall deployments that need the ASA software role on a 1RU Firepower 2100 Series platform. The appliance combines twelve RJ-45 10M/100M/1GBASE-T data ports, four fixed 1/10G SFP+ ports, and one front network module bay for additional interface options, with a 400W AC power supply included and dual AC redundancy available when a second supply is installed. Cisco performance data identifies the Firepower 2130 ASA platform with 10 Gbps stateful inspection firewall throughput, 5 Gbps multiprotocol firewall throughput, two included security contexts with expansion up to 30, and ASA management through ASDM, Cisco Security Manager, or Cisco Defense Orchestrator.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
FPR2130-ASA-K9 |
|
Product type |
Cisco Firepower 2130 ASA firewall appliance |
|
Security software role |
Cisco ASA software |
|
Form factor |
1RU rack-mount appliance |
|
Fixed data interfaces |
12 x RJ-45 10M/100M/1GBASE-T and 4 x 1/10G SFP+ |
|
Network module bay |
One front network module slot |
|
Optional network modules |
10G SFP+ and 1/10G fail-to-wire options |
|
Management interface |
1 x 10M/100M/1GBASE-T RJ-45 |
|
Storage |
1 x 200 GB SSD installed and 1 spare slot for MSP |
|
Power supply design |
Ships with one 400W AC power supply; dual AC optional |
|
Default power supply |
FPR2K-PWR-AC-400 400W AC included; second AC supply optional |
|
Stateful inspection firewall throughput |
10 Gbps |
|
ASA multiprotocol firewall throughput |
5 Gbps |
Product Performance
Key Features
Cisco lists FPR2130-ASA-K9 as the Firepower 2130 1RU appliance with one network module bay and an ASA software role, keeping it distinct from the FPR2130-NGFW-K9 Threat Defense PID.
The 2130 platform uses twelve fixed RJ-45 Gigabit data interfaces plus four fixed 1/10G SFP+ interfaces, so optical handoff planning differs from the 2110 and 2120 fixed 1G SFP models.
Firepower 2130 contains one front network module slot for Cisco-listed 10G SFP+ or fail-to-wire module options when the firewall design needs more or different interface types.
The 2130 ASA values increase stateful throughput, multiprotocol throughput, connection scale, new-connection rate, VPN throughput, VPN peer count, and context ceiling above the 2120 row.
Cisco states that the Firepower 2130 ships with one AC power supply and supports a second AC supply or a DC power plan, so power redundancy and power-cord choices belong in the BOM review.
The ASA deployment guide lists the Firepower 2100 ASA Essentials license, add-on context licenses, and strong-encryption license path, making Smart Account and export authorization checks part of ordering.
Application Scenarios
Specify FPR2130-ASA-K9 when the approved security design remains Cisco ASA and the cabling plan requires fixed SFP+ ports rather than the fixed 1G SFP layout on lower 2100 models.
Use this SKU when the appliance must keep the Firepower 2100 ASA operating model while reserving one network module slot for Cisco-supported interface expansion.
Select the ASA PID when support records, migration planning, and operating procedures are tied to ASA; use FPR2130-NGFW-K9 only when the project changes to Threat Defense software.
Product Comparison
|
Parameter |
FPR2130-ASA-K9 | |||
|---|---|---|---|---|
|
Cisco PID description |
Firepower 2130 appliance 1RU with one network module bay ASA |
Firepower 2130 appliance 1RU with one network module bay NGFW |
Firepower 2120 appliance 1RU ASA |
Firepower 2140 appliance 1RU with one network module bay ASA |
|
Default power supply |
FPR2K-PWR-AC-400 400W AC included; second AC supply optional |
FPR2K-PWR-AC-400 400W AC included; second AC supply optional |
Single integrated 250W AC power supply |
Two FPR2K-PWR-AC-400 400W AC supplies included |
|
Firewall model |
Firepower 2130 |
Firepower 2130 |
Firepower 2120 |
Firepower 2140 |
|
Security software role |
Cisco ASA software |
Firewall Threat Defense software |
Cisco ASA software |
Cisco ASA software |
|
Form factor |
1RU |
1RU |
1RU |
1RU |
|
Fixed data interfaces |
12 x RJ-45 and 4 x 1/10G SFP+ |
12 x RJ-45 and 4 x 1/10G SFP+ |
12 x RJ-45 and 4 x 1G SFP |
12 x RJ-45 and 4 x 1/10G SFP+ |
|
Network module support |
One network module bay |
One network module bay |
No network module bay |
One network module bay |
|
ASA stateful inspection throughput |
10 Gbps |
Threat Defense software role |
6 Gbps |
20 Gbps |
|
ASA multiprotocol throughput |
5 Gbps |
Threat Defense software role |
3 Gbps |
10 Gbps |
|
Concurrent firewall connections |
2 million |
Threat Defense software role |
1.5 million |
3 million |
|
New connections per second |
40000 |
Threat Defense software role |
28000 |
75000 |
|
IPsec VPN throughput |
1 Gbps |
Threat Defense software role |
700 Mbps |
2 Gbps |
|
Maximum VPN peers |
7500 |
7500 |
3500 |
10000 |
|
Security contexts |
2 included; 30 maximum |
Threat Defense software role |
2 included; 25 maximum |
2 included; 40 maximum |
|
Power supply design |
One 400W AC included; dual AC or DC optional |
One 400W AC included; dual AC or DC optional |
Single integrated 250W AC |
Dual 400W AC included; DC optional |
- In a FPR2130-ASA-K9 vs FPR2130-NGFW-K9 comparison, the hardware model and network module bay match, but the current SKU follows the Cisco ASA software order path while the NGFW PID is tied to Threat Defense.
- The FPR2130-ASA-K9 difference from FPR2120-ASA-K9 is both scale and interface design: the 2130 adds fixed 1/10G SFP+ ports, one network module bay, higher ASA capacity values, and a larger context ceiling.
- For FPR2130-ASA-K9 vs FPR2140-ASA-K9, the comparison stays in the modular 2100 hardware class, but the 2140 raises ASA throughput, connection scale, VPN capacity, context maximum, and default dual-AC power.
- Buyers deciding which model to choose should confirm ASA versus Threat Defense first, then compare the 2100 Series row by port speed, module slot requirement, ASA sizing values, and power design.
Selection Guide
1. Confirm the ASA orderable PID
Choose FPR2130-ASA-K9 when the approved firewall build calls for Cisco ASA on a Firepower 2130 appliance rather than a Threat Defense orderable identity.
2. Match the 2130 ASA sizing row
Select this SKU when 10 Gbps stateful inspection throughput, 5 Gbps multiprotocol throughput, 2 million concurrent connections, or 7500 VPN peers match the sizing file.
3. Use the module bay deliberately
Keep the 2130 when the BOM needs one network module slot; stay with FPR2120-ASA-K9 only if fixed 1G SFP ports and no module bay satisfy the design.
4. Decide power redundancy before quoting
Verify whether the single included 400W AC supply is enough, or whether the order should add a second AC supply or move to a site-approved DC power plan.
Ordering Checklist
|
Review Area |
Required Decision |
Source-Based Risk |
|---|---|---|
|
Exact appliance PID |
Confirm FPR2130-ASA-K9 rather than FPR2130-NGFW-K9 |
Cisco lists separate ASA and NGFW PIDs for the same 2130 hardware model |
|
ASA licensing |
Add the Firepower 2100 ASA Essentials license and any needed context license |
ASA features and context expansion depend on Smart Account entitlements |
|
Security contexts |
Decide whether 2 included contexts are enough or whether expansion toward 30 contexts is required |
The 2130 context maximum differs from the 2120 and 2140 values |
|
Fixed SFP+ optics |
Match the four fixed 1/10G SFP+ ports to Cisco-supported optics or cables |
Unsupported optics can delay installation and support acceptance |
|
Network module |
Select the required Cisco 10G SFP+ or fail-to-wire module when the base ports are not enough |
The 2130 module slot is a separate interface planning item |
|
Power design |
Confirm one AC supply, second AC supply, or DC supply plan plus regional power cords |
Cisco states AC and DC modules cannot be mixed in the chassis |
Optional Add-ons
|
Model |
Description |
|---|---|
|
L-FPR2100-ASA= |
Cisco Firepower 2100 ASA Essentials license |
|
L-FPR2K-ASASC-5= |
Cisco Firepower 2100 add-on 5 security context license |
|
L-FPR2K-ASASC-10= |
Cisco Firepower 2100 add-on 10 security context license |
|
L-FPR2K-ENC-K9= |
Cisco Firepower 2100 ASA strong encryption license when the account is not already export-authorized |
|
FPR2K-NM-8X10G |
Firepower 2100 8-port 10G SFP+ network module |
|
FPR2K-NM-8X1G |
Firepower 2100 8-port 1G network module |
|
FPR2K-NM-6X10SR-F |
Firepower 2100 6-port 10G SR fail-to-wire network module |
|
FPR2K-NM-6X10LR-F |
Firepower 2100 6-port 10G LR fail-to-wire network module |
|
FPR2K-PWR-AC-400= |
400W AC power supply spare for Firepower 2130 and 2140 |
|
FPR2K-PWR-DC-350= |
350W DC power supply spare for Firepower 2130 and 2140 |
|
FPR2K-FAN= |
Fan tray spare for Firepower 2130 and 2140 |
|
FPR2K-SSD200= |
200 GB SSD spare for Firepower 2130 and 2140 |
|
FPR-MSP-SSD= |
Malware Storage Pack SSD option |
|
FPR2K-SLIDE-RAILS= |
Slide rail kit spare |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | FPR2130-ASA-K9 | Product Type | Cisco Firepower 2130 ASA firewall appliance |
| Firewall Model | Firepower 2130 | Security Software Role | Cisco ASA software |
| Form Factor | 1RU rack mount | Chassis Dimensions | 1.73 x 16.90 x 19.76 in. (4.4 x 42.9 x 50.2 cm) |
| Fixed RJ-45 Ports | 12 x 10M/100M/1GBASE-T | Fixed SFP+ Ports | 4 x 1/10G SFP+ |
| Maximum Ethernet Interfaces | Up to 24 total Ethernet ports with network module | Network Module Bay | One front network module slot |
| Network Module Options | 10G SFP+ and 1/10G fail-to-wire options | Management Port | 1 x 10M/100M/1GBASE-T RJ-45 |
| Console Port | 1 x RJ-45 console | USB Port | 1 x USB 2.0 Type-A |
| Airflow | Front to rear; cold aisle to hot aisle through the I/O side | Storage | 1 x 200 GB SSD installed; second slot reserved for MSP |
| Power Supply Included | One 400W AC power supply | Power Supply Options | Dual 400W AC optional; single or dual 350W DC optional |
| Power Redundancy | 1+1 AC or DC with dual supplies | AC Input Voltage | 100 to 240V AC |
| AC Maximum Current | Less than 6A at 100V | AC Maximum Output Power | 400W |
| AC Frequency | 50 to 60 Hz | DC Input Voltage | -48V to -60VDC |
| DC Maximum Output Power | 350W | Fan Design | 1 hot-swappable fan module with 4 fans |
| Rack Mounting | 4-post EIA-310-D rack; optional 2-post brackets | Weight | 19.4 lb (8.8 kg) with 1 power supply, 1 network module, 1 fan module, and 2 SSDs |
| Operating Temperature | 32 to 104F (0 to 40C) | Operating Humidity | 10 to 85% noncondensing |
| Operating Altitude | 10000 ft maximum | Stateful Inspection Firewall Throughput | 10 Gbps |
| Multiprotocol Firewall Throughput | 5 Gbps | Concurrent Firewall Connections | 2 million |
| New Connections Per Second | 40000 | IPsec VPN Throughput | 1 Gbps |
| Maximum VPN Peers | 7500 | Security Contexts | 2 included; 30 maximum |
| High Availability | Active/active and active/standby | Local ASA Management | Adaptive Security Device Manager |
| Centralized ASA Management | Cisco Security Manager or Cisco Defense Orchestrator | ASA Essentials License PID | L-FPR2100-ASA= |
| Context License Options | L-FPR2K-ASASC-5= and L-FPR2K-ASASC-10= | Strong Encryption PID | L-FPR2K-ENC-K9= |
| Network Module Release Check | Verify firmware package and ASA compatibility for selected module |
