QSFP-H40G-ACU10M – 40G QSFP+ Active Copper – 10m Length – Direct-Attach Cable
0/mo Solds
Stable Global Supply Chain for Thriving Businesses.
- $3,000,000 Inventory
- Certified Cisco Partner ships
- Collaborating with FedEx, UPS, DHL
Established Global IT Distributor
With over a decade of industry experience, we are a certified Cisco Partner delivering genuine enterprise networking hardware and trusted services to system integrators, ISPs, and enterprises worldwide.
QSFP-H40G-ACU10M Description
QSFP-H40G-ACU10M is the Cisco 10-meter 40GBASE-CR4 QSFP+ active copper direct-attach cable for compatible Cisco QSFP+ ports.
It is a fit when the link should remain a fixed copper assembly but the distance is beyond the short passive DAC range. Keep it separate from AOC cables and passive copper lengths, because the cable type affects routing, compatibility review, and receiving checks.
For purchasing, confirm the 10-meter path, host platform, line card or port type, software release, and whether active copper is the intended medium. Layer23-Switch can help check price, stock, warranty support, shipping timing, and Cisco compatibility.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
QSFP-H40G-ACU10M |
|
Brand |
Cisco |
|
Product family |
Cisco 40GBASE QSFP modules |
|
Product type |
40GBASE-CR4 QSFP+ direct-attach copper cable |
|
Interface form factor |
QSFP+ to QSFP+ direct attach |
|
Ethernet rate |
40 Gigabit Ethernet |
|
Cable standard |
40GBASE-CR4 |
|
Cable length |
10 meters |
|
Cable electronics |
Active |
|
Pull tab color |
Red |
|
Cable AWG |
26 AWG |
|
QSFP-end cable diameter |
9 mm |
|
QSFP-end bend radius |
50 mm |
|
QSFP-end face plate distance |
100 mm |
|
Jacket material |
PVC |
|
Jacket color |
Black |
|
Power consumption, per QSFP end |
1.5 W |
|
Operating temperature range |
0 to 70 C |
Application Scenarios
Use QSFP-H40G-ACU10M when the measured path between two compatible Cisco QSFP+ ports needs a 10-meter copper assembly. The active cable design gives buyers a Cisco-listed option for longer copper runs without moving to a separate optics-and-fiber bill of materials.
This SKU fits deployments where the cabling team wants a factory-terminated 40G cable with a defined length, pull-tab color, bend radius, and jacket type. The 10-meter length should be matched to the real tray or ladder route, not estimated from cabinet distance alone.
QSFP-H40G-ACU10M is useful as a direct replacement or spare when the installed network already uses Cisco 40GBASE-CR4 active copper cables. Before ordering, confirm the target platform and software release in Cisco’s compatibility matrix so the spare matches the supported device list.
Product Comparison
|
Parameter |
QSFP-H40G-ACU10M |
QSFP-H40G-ACU7M | |
|---|---|---|---|
|
Product family |
Cisco 40GBASE QSFP modules |
Cisco 40GBASE QSFP modules |
Cisco 40GBASE QSFP modules |
|
Product type |
QSFP+ direct-attach copper cable |
QSFP+ direct-attach copper cable |
QSFP+ direct-attach copper cable |
|
Cable standard |
40GBASE-CR4 |
40GBASE-CR4 |
40GBASE-CR4 |
|
Interface form factor |
QSFP+ to QSFP+ direct attach |
QSFP+ to QSFP+ direct attach |
QSFP+ to QSFP+ direct attach |
|
Ethernet rate |
40 Gigabit Ethernet |
40 Gigabit Ethernet |
40 Gigabit Ethernet |
|
Cable length |
10 meters |
7 meters |
5 meters |
|
Cable electronics |
Active |
Active |
Passive |
|
Pull tab color |
Red |
Blue |
Gray |
|
Cable AWG |
26 AWG |
26 AWG |
26 AWG |
|
QSFP-end cable diameter |
9 mm |
9 mm |
9 mm |
|
QSFP-end bend radius |
50 mm |
50 mm |
50 mm |
|
QSFP-end face plate distance |
100 mm |
100 mm |
100 mm |
|
Jacket material |
PVC |
PVC |
PVC |
|
Jacket color |
Black |
Black |
Black |
- QSFP-H40G-ACU10M is the 10-meter active copper option in this Cisco 40GBASE-CR4 QSFP+ direct-attach group.
- QSFP-H40G-ACU7M keeps the active copper design but reduces the fixed cable length to 7 meters.
- QSFP-H40G-CU5M is a shorter passive copper alternative, so it should not be substituted when the design specifically calls for an active 10-meter run.
- The 7-meter, 10-meter, and 5-meter copper options share the same Cisco-listed QSFP-end cable diameter, bend radius, face plate distance, jacket material, and jacket color values.
Selection Guide
1. Choose this cable for a confirmed 10-meter copper path
Select QSFP-H40G-ACU10M when the measured rack route needs 10 meters and the host ports support Cisco 40GBASE-CR4 QSFP+ active copper direct attach. If the path is shorter, compare the 7-meter active cable or passive copper SKUs before locking the order.
2. Keep active copper and passive copper separate
Do not replace this SKU with a passive `QSFP-H40G-CU` cable only because the connector family looks similar. The active and passive Cisco copper DAC lines differ by length coverage and electronics, which can affect both compatibility checks and receiving inspection.
3. Validate the Cisco platform and software release
Use Cisco’s 40-Gigabit Ethernet compatibility matrix to check the exact network device, module, and minimum software release. The same cable can appear across several Cisco platforms, but support is still tied to the host hardware and release train.
4. Quote the exact model for commercial checks
Request price, stock, warranty support, and shipping timing with `QSFP-H40G-ACU10M` exactly. A one-character difference can change the line item from active copper to passive copper, optical AOC, or breakout cable.
Ordering Checklist
|
Check Item |
What to Confirm |
Why It Matters |
|---|---|---|
|
Exact SKU |
QSFP-H40G-ACU10M |
Prevents substitution with 7-meter active, 5-meter passive, or 10-meter optical AOC models |
|
Cable length |
10-meter installed route with service slack |
Avoids tight bends while preventing excess cable storage in dense racks |
|
Cable type |
40GBASE-CR4 QSFP+ active copper direct attach |
Keeps the order aligned with the required copper DAC design |
|
Host compatibility |
Target Cisco platform, module, and software release |
Cisco support depends on the installed device and release |
|
Physical routing |
9 mm diameter, 50 mm bend radius, and 100 mm face plate distance |
Helps the rack team confirm clearance before shipment |
|
Procurement details |
Price, stock, warranty support, and shipping window |
Keeps the purchase aligned with deployment and receiving dates |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | QSFP-H40G-ACU10M | Brand | Cisco |
| Product family | Cisco 40GBASE QSFP modules | Product type | 40GBASE-CR4 QSFP+ direct-attach copper cable |
| Interface form factor | QSFP+ to QSFP+ direct attach | Ethernet rate | 40 Gigabit Ethernet |
| Cable standard | 40GBASE-CR4 | Cable length | 10 meters |
| Cable electronics | Active | Pull tab color | Red |
| Cable AWG | 26 AWG | QSFP-end cable diameter | 9 mm |
| QSFP-end bend radius | 50 mm | QSFP-end face plate distance | 100 mm |
| Jacket material | PVC | Jacket color | Black |
| Power consumption, per QSFP end | 1.5 W | Latency, per link | Less than 0.1 microsecond |
| Operating temperature range | 0 to 70 C | Storage temperature range | -40 to 85 C |
| Standards reference | IEEE 802.3ba and QSFP MSA SFF-8436 | Compatibility reference | Cisco 40-Gigabit Ethernet Transceiver Modules Compatibility Matrix |
Get More Information
Need pricing, stock, or shipping details for the QSFP-H40G-ACU10M ? Layer23-Switch can help you check current availability, lead time, and delivery options for this. Send us the part number, quantity, and destination country via live chat or email sales@layer23-switch.com for a fast quotation.
