SFP-10/25G-LR-I Description
The SFP-10/25G-LR-I is a Cisco 10/25GBASE-LR SFP28 industrial-temperature transceiver for 10G and 25G single-mode links in outdoor cabinets and unconditioned equipment rooms. The 1310 nm optic covers 10 km at either rate over G.652 fiber, or 15 km as an engineered link below 9.3 dB of insertion loss with RS-FEC, and is rated -40 to 85°C. Full 25G reach depends on RS-FEC at the host port; with BASE-R FEC the link may reach 3.5 km, and 1.5 km with no FEC, depending on fiber quality.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Optic type |
10/25GBASE-LR SFP28 |
|
Data rate |
10G or 25G |
|
Reach |
10 km at 10G and 25G |
|
Fiber |
G.652 single-mode fiber |
|
Wavelength |
1310 nm |
|
Connector type |
Dual LC/PC |
|
Host FEC at 25G |
RS-FEC for full reach |
|
Operating case temperature |
-40 to 85°C (industrial) |
|
Maximum power consumption |
1.3W |
Application Scenarios
At an outdoor cell site, an NCS 540 fronthaul router carries 10G or 25G links over single-mode fiber on this optic. The module also supports CPRI rate options 7 to 10 and keeps its -40 to 85°C rating inside the cabinet.
Service providers place NCS 560 and NCS 5500 aggregation routers in remote huts that are not climate controlled, and the optic links each hut to its neighbor over up to 10 km of G.652 fiber.
Product Comparison
|
Parameter |
SFP-10/25G-LR-I |
SFP-10/25G-BXD-I | ||
|---|---|---|---|---|
|
Standard |
10/25GBASE-LR |
10/25GBASE-LR |
10GBASE-LR, 10GBASE-BR10, 25GBASE-BR10 |
25GBASE-ER |
|
Cable distance |
10 km; up to 15 km as an engineered link below 9.3 dB insertion loss with RS-FEC |
10 km |
10 km; up to 15 km as an engineered link below 8 dB insertion loss with RS-FEC |
40 km; links beyond 30 km are engineered links |
|
Cable type |
Duplex G.652 single-mode |
Duplex G.652 single-mode |
Single-strand G.652 single-mode |
Duplex G.652 single-mode |
|
Wavelength |
1310 nm |
1310 nm |
Transmit 1330 nm, receive 1270 nm |
1310 nm |
|
FEC at 25G |
RS-FEC for full reach; 3.5 km with BASE-R FEC, 1.5 km without FEC |
RS-FEC required for 25G operation |
RS-FEC for full reach; 3.5 km with BASE-R FEC, 1.5 km without FEC |
RS-FEC for full reach |
|
Operating case temperature |
-40 to 85°C |
0 to 70°C |
-40 to 85°C |
-40 to 85°C |
SFP-10/25G-LR-I and SFP-10/25G-LR-S share 10/25GBASE-LR optics at 1310 nm and 10 km of G.652 reach, but the industrial model is rated -40 to 85°C against 0 to 70°C. The host lists also differ: the TMG matrix shows SFP-10/25G-LR-I on no Catalyst 9200, 9300, 9400, 9500 or 9600 family, so Catalyst 9000 ports in conditioned rooms take SFP-10/25G-LR-S. Where only one strand of single-mode fiber is free, SFP-10/25G-BXD-I keeps the industrial rating and 10 km reach but must pair with SFP-10/25G-BXU-I at the far end. Spans beyond 15 km, up to 40 km, move to SFP-25G-ER-I, which runs 25GBASE-ER only.
Ordering Checklist
- Host support: The target router or switch lists SFP-10/25G-LR-I in the Cisco TMG matrix, which covers families such as NCS 540, NCS 560, NCS 5500, Cisco 8000 Series and Catalyst 1300X. TMG lists hosts per transceiver PID, so support for another 25G optic does not cover this one.
- Fiber and patch cords: The link runs on duplex G.652 single-mode fiber with LC patch cords that have PC or UPC end faces. APC patch cords are not supported on the dual LC/PC connector.
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | SFP-10/25G-LR-I | Cisco ordering description | 10/25GBASE-LR SFP28 Module for SMF, Industrial Temp |
| Form factor | SFP28 | Data rate | 10G and 25G |
| Cable type | SMF | Fiber standard | G.652 |
| Wavelength | 1310 nm | Cable distance | 10 km at 10G and 25G |
| Engineered link | Up to 15 km with channel insertion loss below 9.3 dB and RS-FEC | Host FEC requirement | RS-FEC on host ports for full reach at 25G |
| Reach at 25G with reduced FEC | 3.5 km with BASE-R FEC, 1.5 km without FEC, depending on fiber quality | CPRI data rate options | 7, 8, 9 and 10 |
| Connector type | Dual LC/PC | Patch cord connectors | PC or UPC only; APC not supported |
| Max power consumption | 1.3W | Pull tab / bail latch color | Blue |
| Transmit power (10G) | +0.5 dBm maximum, -6.7 dBm minimum | Receive power (10G) | +0.5 dBm maximum, -15.9 dBm minimum |
| Wavelength range (10G) | 1260 to 1355 nm | Transmit power (25G) | +2.0 dBm maximum, -5.5 dBm minimum |
| Receive power (25G) | +2.0 dBm maximum, -14.8 dBm minimum | Wavelength range (25G) | 1295 to 1325 nm |
| Operating case temperature | -40°C to 85°C (-40°F to 185°F), industrial range | Storage temperature | -40°C to 85°C (-40°F to 185°F) |
| DOM | DOM hardware capable | Platform support | Host list in the Cisco Transceiver Module Group (TMG) Compatibility Matrix |
| Standards | SFF-8402, SFF-8472, IEEE 802.3-2015, IEEE P802.3by, IEEE P802.3cc | Safety certifications | Laser Class 1 21CFR-1040 LN#50 7/2001; Laser Class 1 IEC60825-1 |
| Environmental compliance | RoHS 6 |
Get More Information
Need pricing, stock, or shipping details for the SFP-10/25G-LR-I ? Layer23-Switch can help you check current availability, lead time, and delivery options for this. Send us the part number, quantity, and destination country via live chat or email [email protected] for a fast quotation.
Quality Certifications
Customer Reviews
Questions & Answers
-
What happens to the reach of SFP-10/25G-LR-I at 25G when the host runs BASE-R FEC?
-
Can SFP-10/25G-LR-I run a 15 km link?
-
Is SFP-10/25G-LR-I rated for cabinets that fall below 0 degrees C?
-
Which fiber and connector does SFP-10/25G-LR-I use?
