C1000-24P-4X-L – 24x1G PoE+ Ports – 4x10G SFP+ Uplinks – 195W PoE Budget

Brand: Cisco Category: Catalyst 1000 Switches Model: C1000-24P-4X-L
4.98 reviews11 Questions
List Price: $3,292.78 54% OFF
$1,529.96
Price Alert
In StockShips in as little as 1 business day Brand New
Related models
Cisco SN CheckSN verification before shipment.Verify authenticity3-Year WarrantyExtended, enterprise-gradeWarranty terms14-Day ReturnsStraightforward RMA processReturn policyExpress Shipping2-6 Business Daysvia UPS, FedEx, DHL and more
Trusted & Secure Payments

Shop Expert-Recommended Accessories for the C1000-24P-4X-L

Explore optics, stacking accessories, modules, and power supplies—all verified by our engineers for use with this model.
  • SFP-10G-SR-S

    SFP-10G-SR-S

    10GBASE-SR SFP+ - S-Class - 400m OM4 MMF
    Original price was: $853.95.Current price is: $52.00.
  • SFP-10G-LR-S

    SFP-10G-LR-S

    10GBASE-LR SFP+ - S-Class - 10km SMF
    Original price was: $2,439.88.Current price is: $150.00.
  • GLC-SX-MMD

    GLC-SX-MMD

    1000BASE-SX SFP - MMF 850nm - DOM
    Original price was: $633.46.Current price is: $59.00.
  • GLC-LH-SMD

    GLC-LH-SMD

    1000BASE-LX/LH SFP - 10km SMF / 550m MMF - DOM
    Original price was: $1,260.58.Current price is: $95.80.

Why Layer23-Switch

Stocked, Shipped and Supported by One Team

Founded
Customers
Units shipped
Countries
Cisco switches in stock at the Layer23-Switch warehouse
Play

Inventory You Can See

Cisco stock on hand
Models ready to ship
Warehouse space

Ships in 1 Business Day

In-stock orders leave our Hong Kong or U.S. warehouse within 1 business day after payment, with tracking by email.

DHL FedEx UPS Duties included: US · CA · UK

LSCare Warranty

3years on enterprise equipment

  • Advance replacement for in-stock models
  • New unit for dead-on-arrival
  • 14-day returns on sealed items

Free CCIE Support

Certified engineers help before and after you buy. Reply within 1 business day by email or live chat.

Part number check Configuration Troubleshooting

Verify Before You Pay

100%factory-sealed

Get label and serial photos before shipment, and check every serial number with Cisco.

C1000-24P-4X-L Description

The C1000-24P-4X-L is a Cisco Catalyst 1000 Series fixed managed Layer 2 PoE+ access switch for campus closets that power endpoints and aggregate over 10G fiber. The switch has 24 10/100/1000 RJ45 PoE+ ports sharing a 195W budget, four 10G SFP+ uplinks, 128 Gbps of switching bandwidth and a fanless chassis. The PoE budget is fixed by the model and cannot be increased later, and routing is limited to static routes.

Quick Specs

Parameter

Specification

Product ID

C1000-24P-4X-L

Product type

Fixed managed Gigabit Ethernet Layer 2 switch

Downlink ports

24 x 10/100/1000 RJ45 PoE+ ports

Uplink ports

4 x 10G SFP+ uplinks

Default PoE budget

195W available PoE

Per-port PoE support

Up to 30W per PoE port

Fan design

Fanless 24-port model

Internal power input

Single fixed internal AC power supply

Switching capacity

128 Gbps for 24-port models with 10G uplinks

Forwarding rate

95.23 Mpps for 24-port models with 10G uplinks

Dimensions

17.48 x 11.76 x 1.73 in.

Weight

3.68 kg

Product Performance

Powered Gigabit Access Density
Fixed Endpoint Power Ceiling
10G-uplink Forwarding Class

Key Features

195W PoE Budget Across 24 Ports

The budget is shared by all PoE+ ports, which works out to about 8W per port if every port draws at once. A single port can still deliver up to 30W.

Four 10G SFP+ Uplinks

The SFP+ slots run at 10G and also accept 1G SFP modules, so the uplinks can start on existing 1G fiber and move to 10G later.

128 Gbps Switching Capacity

Switching bandwidth is 128 Gbps with a forwarding rate of 95.23 Mpps, enough to keep the 10G uplinks from limiting the 24 copper ports.

Fanless Operation

The 24-port PoE+ chassis has no fan, so it can sit in an office or classroom without noise.

Static Routing On A Layer 2 Platform

The switch routes between VLANs with static routes, with room for 542 direct and 256 indirect IPv4 unicast routes. Dynamic routing protocols are not supported.

Single IP Management With 10G Peers

Up to eight Catalyst 1000 Gigabit switches can be managed from one IP address. 10G models group only with other 10G models, and the grouping links must be SFP+ rather than 1G SFP.

Application Scenarios

Campus Classroom Wing

In a classroom wing, the switch powers ceiling access points and IP phones over PoE+ and sends their traffic to the building distribution switch over a 10G SFP+ uplink.

Camera Aggregation Cabinet

At a campus gate or parking structure, the switch powers IP cameras from its PoE+ ports and moves the video to the recording server over 10G fiber.

Branch Office With 10G Fiber

A branch office with 10G fiber to its core can use the switch to feed desk phones and access points while keeping the uplink free of a 1G bottleneck.

Product Comparison

Parameter

C1000-24P-4X-L

C1000-24P-4G-L

C1000-24T-4X-L

C1000-24FP-4X-L

Gigabit Ethernet / FE ports

24 10/100/1000 RJ45 PoE+

24 10/100/1000 RJ45 PoE+

24 10/100/1000 RJ45 Data

24 10/100/1000 RJ45 PoE+

PoE power budget

195W

195W

0W (no PoE)

370W

Uplink ports

4 SFP+ (10G)

4 SFP (1G)

4 SFP+ (10G)

4 SFP+ (10G)

Switching capacity

128 Gbps

56 Gbps

128 Gbps

128 Gbps

Forwarding rate

95.23 Mpps

41.67 Mpps

95.23 Mpps

95.23 Mpps

Fanless

Yes

Yes

Yes

No

Layer 3 functionality

Static routing

Static routing

Static routing

Static routing

Single IP management

Up to 8 switches

Up to 8 switches

Up to 8 switches

Up to 8 switches

C1000-24P-4X-L and C1000-24P-4G-L share 24 PoE+ ports and a 195W PoE budget, but C1000-24P-4X-L has 4 x 10G SFP+ uplinks at 128 Gbps switching bandwidth while C1000-24P-4G-L has 4 x 1G SFP uplinks at 56 Gbps, so sites with only 1G aggregation links can use C1000-24P-4G-L. Closets with no powered endpoints and 10G uplinks can use C1000-24T-4X-L, the data-only model. Powered loads above 195W need C1000-24FP-4X-L, which offers a 370W budget on the same 10G uplinks but is fan-cooled rather than fanless. Cisco fixes the budget per model and it cannot be increased later, so the PoE decision is final when the switch is ordered.

PoE Power Planning

Check Item

Cisco-confirmed Value

Planning Impact

Available PoE

195W

Count the combined draw of phones, access points, cameras, and other powered devices against this fixed budget

Per-port PoE support

Up to 30W per PoE port

A single attached device may require PoE+ power, but the total switch budget still limits simultaneous load

Consumption with PoE

220.68W

UPS and branch electrical planning should include the powered-switch draw

Power budget expansion

Fixed by model

Cisco states the PoE budget of a Catalyst 1000 model cannot be increased

Ordering Checklist

  • Power cord: Select one AC power cord for the destination country; the cord is not included and must be selected on the order.
  • Uplink optics: Add Cisco-supported SFP+ or SFP modules, sold separately, for the 4 x 10G SFP+ slots. With SFP-10G-ER or SFP-10G-ER-S the limit is 45C up to 5,000 ft and 40C up to 10,000 ft.
  • Console cable and cord clip: Add CAB-CONSOLE-RJ45 or CAB-CONSOLE-USB for console access and PWR-CLP to retain the power cord; both are separate accessories that are easy to leave off the order.

Optional Add-ons

Model

Description

CAB-CONSOLE-RJ45

Cisco console cable 6 ft. with RJ-45 for all Catalyst 1000 models

PWR-CLP

Power cable restraining clip for all Catalyst 1000 models

Specifications

Parameter Specification Parameter Specification
Product ID C1000-24P-4X-L Product type Fixed managed Gigabit Ethernet Layer 2 switch
Downlink ports 24 x 10/100/1000 RJ45 PoE+ ports Uplink ports 4 x 10G SFP+ uplinks
Default PoE budget 195W available PoE Per-port PoE support Up to 30W per PoE port
Fan design Fanless 24-port model Internal power input Single fixed internal AC power supply
Voltage 100 to 240V AC in Frequency 50 to 60 Hz
Input current 1.316A to 2.314A Power rating 0.45 kVA maximum consumption
Consumption without PoE 25.68W Consumption with PoE 220.68W
Forwarding bandwidth 64 Gbps for 24-port models with 10G uplinks Switching capacity 128 Gbps for 24-port models with 10G uplinks
Forwarding rate 95.23 Mpps for 24-port models with 10G uplinks MAC addresses 16000
Maximum active VLANs 256 VLAN IDs available 4094
Maximum STP instances 64 Maximum SPAN sessions 4
Console port RJ-45 Ethernet console USB-A port 1 USB-A port for storage and Bluetooth console
CPU ARM v7 800 MHz DRAM 512 MB
Flash 256 MB Operating temperature -5 to 50°C at sea level
Operating altitude 10000 ft (3000 m) Operating humidity 5% to 90% at 40°C non-condensing
Dimensions 17.48 x 11.76 x 1.73 in. Weight 3.68 kg

Quality Certifications

Customer Reviews

Write A Review
4.9
(8 reviews)
5 Stars
7
4 Stars
1
3 Stars
0
2 Stars
0
1 Stars
0
    Timothy Chen
    Posted on 24/02/2026
    Verified Buyer
    5.0

    We’ve reordered the same products multiple times. Quality has been consistent every time.

    Stephen Ward
    Posted on 20/01/2026
    Verified Buyer
    4.0

    The product passed every aspect of our standard inspection process. Wish the lead time was a bit shorter, but product quality made up for it.

    Margaret Hernandez
    Posted on 27/12/2025
    Verified Buyer
    5.0

    Hard to find anything to complain about.

    Fox Mulder
    Posted on 25/07/2024
    Verified Buyer
    5.0

    The truth is out there… and so is this switch. It works. Reliable connection.

    Dana Scully
    Posted on 12/05/2024
    Verified Buyer
    5.0

    Scientifically speaking, the hardware is sound. Packaging was sterile and secure.

Questions & Answers

  • Can C1000-24P-4X-L be stacked with other switches?

    C1000-24P-4X-L joins up to eight Catalyst 1000 Gigabit switches in a Single IP Management group managed from one IP address. 10G models group only with other 10G models, and the grouping links must be SFP+ rather than 1G SFP.

  • How far does Layer 3 routing go on C1000-24P-4X-L, and how is it managed?

    C1000-24P-4X-L routes between VLANs with static routes only, with room for 542 direct and 256 indirect IPv4 unicast routes. Dynamic routing protocols are not part of the feature set. Management uses the RJ-45 Ethernet console port or a Bluetooth console on the USB-A port.

  • Does C1000-24P-4X-L forward jumbo frames, and at what MTU?

    C1000-24P-4X-L supports a Layer 3 MTU of 9198 bytes and jumbo Ethernet frames of 10,240 bytes. These values apply to all Catalyst 1000 models. Connected servers and uplink peers must use matching MTU values, because a frame over the smallest MTU on the path is dropped.

  • Which ACL and multicast table sizes apply on C1000-24P-4X-L?

    C1000-24P-4X-L holds 600 IPv4 and MAC security ACEs, 600 IPv6 ACEs and 1024 multicast groups, alongside 16,000 unicast MAC addresses. The public datasheet gives 16,000 MAC addresses, so size MAC tables from that value. Security policy is limited to 600 ACEs per address family.

  • Which IPv6 route and SVI limits apply on C1000-24P-4X-L?

    C1000-24P-4X-L supports 64 SVIs, 414 IPv6 direct routes and 128 IPv6 indirect routes, with static routing as the only routing method. Route tables are limited to the 414 direct and 128 indirect IPv6 values, so plan prefix counts within those limits.

  • What ambient temperature range can C1000-24P-4X-L run in at 5,000 ft and 10,000 ft?

    C1000-24P-4X-L runs at ambient temperatures up to 45 C at 5,000 ft (1500 m) and up to 40 C at 10,000 ft. The 50 C figure is short-term only per the datasheet footnote, and cold start needs 0 C. Sustained operation must stay inside the 45 C and 40 C steps.

  • How do I convert an SFP+ uplink on C1000-24P-4X-L into a Single IP Management port?

    Enter switch N hstack-port 1 or 2 followed by the uplink name, save with copy running-config startup-config, then reload C1000-24P-4X-L. Uplinks use the names TenGigabitEthernet 1/0/1-4, and at most two ports can serve as management ports. Mixing SFP and SFP+ as management ports is not supported.

  • Can sFlow run on C1000-24P-4X-L when it is a Single IP Management member?

    No. sFlow cannot be used on member switches in a Single IP Management group that includes C1000-24P-4X-L. Single IP Management is a management feature, not a data-plane stack, with one active unit and the other units as members. The link uses front-panel uplinks, downlink gigabit ports are not supported for it, and no Fast Ethernet model can join.

  • Which egress queue count applies to QoS on C1000-24P-4X-L?

    The datasheet states up to 8 egress queues and 2 thresholds per port on C1000-24P-4X-L, with egress bandwidth control, shaping and priority queuing. Plan QoS policies around 8 queues per port, because queue counts above that figure are not available on this model.

  • What can the USB-A port on C1000-24P-4X-L be used for?

    The USB-A port on C1000-24P-4X-L is limited to USB storage and a Bluetooth dongle for CLI and GUI access. The switch has an ARM v7 800 MHz CPU, 256 MB flash and 512 MB DRAM, measured in megabytes, not megabits, plus a 1.5 MB egress buffer.

  • Does perpetual PoE on C1000-24P-4X-L keep endpoints powered during a switch power outage?

    No. Perpetual PoE on C1000-24P-4X-L applies only to soft reloads, meaning an image upgrade, a crash or a manual reboot. It does not cover a switch power outage or removal of the power supply. Phones and access points still lose power if the AC feed to the switch drops.
