C9500-40X-E Description
The C9500-40X-E is a Cisco Catalyst 9500 Series fixed core and aggregation switch with a Network Essentials license, built for distribution layers that terminate dozens of 10G fiber links. The switch has 40 1/10G SFP/SFP+ ports, one uplink slot for an 8-port 10G or 2-port 40G network module, 960 Gbps of switching capacity and 64,000 MAC addresses under the default template. The base hardware carries no network module, and the uplink slot must hold either a module or a blank before the switch is operated.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
C9500-40X-E |
|
Network license |
Network Essentials |
|
Downlink ports |
40 x 1/10G SFP/SFP+ |
|
Uplink network module slot |
1 slot for C9500-NM-8X (8 x 10G SFP/SFP+) or C9500-NM-2Q (2 x 40G QSFP+), ordered separately |
|
ASIC |
Cisco UADP 2.0 |
|
Switching capacity |
960 Gbps |
|
Forwarding rate |
720 Mpps |
|
MAC address (distribution template) |
64,000 |
|
IPv4/IPv6 LPM |
64,000 / 32,000 |
|
Default power supply |
PWR-C4-950WAC-R 950W AC |
|
Power supply slots |
2, hot-swappable, 1+1 redundant |
|
Minimum software release |
Cisco IOS XE Everest 16.6.1 |
Product Performance
Key Features
The uplink slot takes either C9500-NM-8X, which brings the switch to 48 10G SFP/SFP+ ports, or C9500-NM-2Q with two 40G QSFP+ ports. Each of those 40G ports can also run as four 10G ports over a breakout cable, so the 2-port module still serves eight 10G links when 40G is not needed.
The default distribution template holds 64,000 MAC addresses, 64,000 IPv4 and 32,000 IPv6 LPM routes, and 48,000 IPv4 host routes. The core template doubles multicast routes to 32,000 at the cost of MAC capacity, which drops to 16,000; the NAT template raises PBR and NAT entries from 2,000 to 16,000.
Network Essentials runs Layer 2 and routed access with RIP, EIGRP Stub and OSPF up to 1,000 routes, plus VRRP, PIM Stub, MACsec-128 and SSO. BGP, VRF, VXLAN, MPLS, StackWise Virtual and MACsec-256 sit in Network Advantage and are not available on this license.
NETCONF, RESTCONF, gRPC, YANG models and model-driven telemetry are part of Network Essentials. Programmatic configuration and streaming telemetry therefore run on this switch without moving to the Advantage tier.
Two hot-swappable slots accept PWR-C4-950WAC-R on 90 to 264 VAC or PWR-C4-950WDC-R on -36 to -72 VDC. The switch ships with one supply installed, and a second unit in the other slot gives 1+1 redundancy.
Five variable-speed FAN-T4-R fans cool the chassis front to back, and each one can be swapped while the switch runs for up to 120 seconds. Sound power stays at or below 68.3 LWAd dB.
Application Scenarios
In a building distribution room, the switch terminates 10G fiber runs from each access closet and routes between floors with OSPF, sending traffic toward the campus core over its uplink module.
A campus with a handful of buildings can run its core and distribution on one tier, with VRRP keeping the default gateway available across a pair of these switches and OSPF carrying routes to the WAN edge.
Servers and storage arrays with 10G SFP+ interfaces connect directly to the 40 downlink ports, and a 40G QSFP+ module carries their traffic to the core as Layer 2 trunks.
Product Comparison
|
Parameter |
C9500-40X-E |
C9500-40X-A | ||
|---|---|---|---|---|
|
Downlink ports |
40 x 1/10G SFP/SFP+ |
40 x 1/10G SFP/SFP+ |
40 x 10G SFP/SFP+ |
16 x 1/10G SFP/SFP+ |
|
Uplink network module |
Slot only, module ordered separately |
Slot only, module ordered separately |
C9500-NM-2Q included (2 x 40G QSFP+) |
Slot only, module ordered separately |
|
Switching capacity |
960 Gbps |
960 Gbps |
960 Gbps |
480 Gbps |
|
Forwarding rate |
720 Mpps |
720 Mpps |
720 Mpps |
360 Mpps |
|
MAC address (distribution template) |
64,000 |
64,000 |
64,000 |
64,000 |
|
IPv4/IPv6 LPM |
64,000 / 32,000 |
64,000 / 32,000 |
64,000 / 32,000 |
64,000 / 32,000 |
|
Network license |
Network Essentials |
Network Advantage |
Network Essentials |
Network Essentials |
C9500-40X-E and C9500-40X-A are the same 40-port 10G switch, and the license is the only difference: Network Advantage adds BGP, VRF, VXLAN, MPLS, StackWise Virtual and MACsec-256 to the Layer 2 and OSPF routed access of Network Essentials. A core pair that must run as one StackWise Virtual system, or that peers with BGP, needs C9500-40X-A from the start. An installed C9500-40X-E moves up later with the C9500-DNA-40X-E-A upgrade license, which cannot be applied at the time of purchase. When 40G uplinks are fixed at design time, C9500-40X-2Q-E bundles the C9500-NM-2Q module, and C9500-48X-E bundles C9500-NM-8X for 48 10G ports. Sites that need only 16 fiber ports can drop to C9500-16X-E at 480 Gbps and 360 Mpps.
Ordering Checklist
- Software subscription: Add an Essentials term that matches Network Essentials, either C9500-DNX-E-40X-3Y, -5Y or -7Y or C9500-DNA-E-3Y, -5Y or -7Y. A new order cannot be completed without a subscription at the license tier.
- Smart Account: Name the Smart Account that receives the license entitlements. Cisco requires one on every Catalyst 9500 order.
- Second power supply: The configurator preselects a second supply; keep it for 1+1 redundancy or select C9500-SPS-NONE to remove it. A spare redundant AC unit orders as PWR-C4-950WAC-R/2.
- Uplink network module: The C9500-40X-E line carries no network module, so add C9500-NM-8X or C9500-NM-2Q when the uplink slot will be used. The slot must hold a module or a blank before the switch runs.
- Power cords: Select a power cord type for the destination country for each supply. The configuration cannot be completed without one.
- Optics: Order SFP/SFP+ and QSFP+ optics separately, choosing part numbers listed for Catalyst 9500 in the Cisco Optics-to-Device Compatibility Matrix.
Optional Add-ons
|
Model |
Description |
|---|---|
|
Cisco Catalyst 9500 network module with eight 10G SFP/SFP+ uplink ports | |
|
Cisco Catalyst 9500 network module with two 40G QSFP+ uplink ports | |
|
PWR-C4-950WAC-R/2 |
950W AC Config 4 redundant power supply, front-to-back cooling |
|
PWR-C4-950WDC-R |
950W DC power supply module for -36 to -72 VDC sites |
|
FAN-T4-R |
Catalyst 9500 Type 4 front-to-back cooling fan, field replaceable |
|
CVR-QSFP-SFP10G |
Cisco QSA module that converts a QSFP port into an SFP+ port |
C9500-40X-E Switch Rear Panel
The switch rear panel includes StackWise connectors, StackPower or XPS connectors, ports, fan modules, and power supply modules.
Components Delivered in the Shipping Box
The shipping box contains the model of the switch you ordered and other components needed for installation. Some components are optional, depending on your order.
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | C9500-40X-E | Network license | Network Essentials |
| Downlink ports | 40 x 1/10G SFP/SFP+ | Uplink network module slot | 1 slot for C9500-NM-8X or C9500-NM-2Q; module or blank required for operation |
| C9500-NM-8X ports | 8 x 10G SFP/SFP+ | C9500-NM-2Q ports | 2 x 40G QSFP+ |
| 40G port breakout | Ports 41 and 42 each configurable as 4 x 10G with a breakout cable | Maximum 10G ports | 48 with C9500-NM-8X |
| ASIC | Cisco UADP 2.0 | Switching capacity | 960 Gbps |
| Forwarding rate | 720 Mpps | MAC address | 64,000 (distribution template); 16,000 (core template) |
| IPv4/IPv6 LPM | 64,000 / 32,000 | IPv4/IPv6 host routes | 48,000 / 24,000 (distribution template); 32,000 / 16,000 (core template) |
| IPv4/IPv6 multicast routes | 16,000 / 8,000 (distribution template); 32,000 / 16,000 (core template) | IGMP/MLD snooping | 16,000 |
| SGT labels | 8,000 | NetFlow | 128,000 |
| Security ACL | 18,000 | QoS ACL | 18,000 |
| PBR/NAT | 2,000 (distribution template); 16,000 (NAT template) | Default power supply | PWR-C4-950WAC-R 950W AC |
| Supported power supplies | PWR-C4-950WAC-R 950W AC; PWR-C4-950WDC-R 950W DC | Power supply slots | 2, hot-swappable, 1+1 redundant |
| AC input voltage | 90 to 264 VAC, 47 to 63 Hz | DC input voltage | -36 to -72 VDC |
| Fan modules | 5 x FAN-T4-R, variable speed, hot-swappable for up to 120 seconds | Airflow | Front to back |
| Acoustic noise | No greater than 68.3 LWAd dB | Rear-panel ports | USB 3.0 host port |
| Operating temperature | 32°F to 104°F (0 to 40°C) | Storage temperature | -4°F to 149°F (-20°C to 65°C) |
| Relative humidity | Operating 5% to 90%; non-operating 5% to 95% (noncondensing) | Operating altitude | Up to 6000 ft (1800 m) |
| Storage altitude | Up to 15,000 ft (4500 m) | Rack units | 1 RU |
| Dimensions (H x W x D) | 1.73 x 17.5 x 21.5 in. (4.4 x 44.5 x 56.7 cm) | Weight | 11.68 kg (25.75 lb) with 2 power supplies and built-in fans |
| Minimum software release | Cisco IOS XE Everest 16.6.1 |
