C8225-G2 – 2×1/10GE SFP+ – 8x1GE Copper – 16 GB DRAM – Desktop Router
Established Global IT Distributor
With over a decade of industry experience, we are a certified Cisco Partner delivering genuine enterprise networking hardware and trusted services to system integrators, ISPs, and enterprises worldwide.
C8225-G2 Description
The C8225-G2 is the security-services tier of the all-gigabit Cisco 8200 Series desktop routers. Its faceplate is 2x 1/10 GE SFP+ plus eight 1 GE copper ports split as two WAN, two Flex and four LAN, with no cellular bay, no module slot and no PoE-capable supply anywhere in the configuration. It shares that faceplate exactly with C8221-G2, and the pair differ only in DRAM at 16 GB against 8 GB and Threat protection at 2.4 Gbps against 1 Gbps. Forwarding, IPsec and SD-WAN are 19, 5 and 4 Gbps on both. The chassis is a 5 lb desktop unit running on a 66W AC adapter, and the platform starts at Cisco IOS XE Release 26.1.2.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
C8225-G2 |
|
Platform type |
Desktop form factor |
|
WAN Ports |
2x 1/10 GE SFP+ and 2x 1 GE RJ-45 |
|
Flex Ports |
2x 1 GE RJ-45 |
|
LAN Ports |
4x 1 GE RJ-45 |
|
Cellular Slot |
None on this platform |
|
PoE capability |
Not a PoE power sourcing device |
|
Default power supply model |
66W AC external adapter |
|
Forwarding throughput |
19 Gbps at 512 bytes |
|
Threat protection throughput |
2.4 Gbps at EMIX |
|
DRAM |
16 GB |
|
Chassis weight |
5 lb (2.27 kg) |
|
Minimum software release |
Cisco IOS XE Release 26.1.2 |
Product Performance
Key Features
C8221-G2 carries exactly the same ports, adapters, chassis and software floor; the only reasons to choose this SKU are 16 GB of DRAM instead of 8 GB and 2.4 Gbps of Threat protection instead of 1 Gbps.
Cisco lists no PoE-capable supply for this model, so all ten ports are data-only; a branch needing to power an endpoint has to move to the mGig models in the series or add an injector.
The two 1/10 GE SFP+ cages accept 1 GE or 10 GE optics, so the same router terminates a gigabit copper handoff through an SFP or a 10 GE fibre circuit without changing part number.
This model starts at Cisco IOS XE Release 26.1.2 while C8235-G2 and C8231-G2 start at 17.18.1, so the all-gigabit and multigigabit halves of the series sit in different release families.
Typical consumption is 21W against 26.70W and 27.11W for the mGig models, which matters where several routers share a small UPS or a metered circuit.
The chassis is rated to 45 degrees C at sea level, but Cisco publishes 40 degrees C once the dust and liquid cover is fitted, so a protected install trades thermal headroom for ingress protection.
Application Scenarios
Deployed where every local device and circuit runs at 1 GE and the SFP+ cages carry the uplink, without powered endpoints or cellular backup.
Installed with the dust and liquid cover in workshop, retail back-of-house or light-industrial spaces, operating inside the reduced 40 degrees C envelope.
Placed where NAT, firewall, intrusion prevention, URL filtering and malware protection run on the router rather than at a hub, using the 2.4 Gbps inspection tier.
Product Comparison
|
Parameter |
C8225-G2 | ||
|---|---|---|---|
|
Platform type |
Desktop |
Desktop |
Desktop |
|
WAN Ports |
2x 1/10 GE SFP+, 2x 1 GE RJ-45 |
2x 1/10 GE SFP+, 2x 1 GE RJ-45 |
2x 1/10 GE SFP+, 2x 2.5 GE mGig (2x UPOE+) |
|
Flex Ports |
2x 1 GE RJ-45 |
2x 1 GE RJ-45 |
2x 2.5 GE mGig (2x PoE+) |
|
LAN Ports |
4x 1 GE RJ-45 |
4x 1 GE RJ-45 |
4x 2.5 GE mGig |
|
Cellular Slot |
None on this platform |
None on this platform |
1 x PIM |
|
PoE capability |
Not a PoE power sourcing device |
Not a PoE power sourcing device |
120W with the 230 W AC for PoE adapter |
|
Default power supply model |
66W AC external adapter |
66W AC external adapter |
66 W AC external adapter |
|
Forwarding throughput |
19 Gbps |
19 Gbps |
19 Gbps |
|
Threat protection throughput |
2.4 Gbps |
1 Gbps |
2.4 Gbps |
|
DRAM |
16 GB |
8 GB |
16 GB |
|
Typical power consumption |
21W |
21W |
27.11 W |
|
Chassis weight |
5 lb |
5 lb |
7 lbs |
|
Minimum software release |
Cisco IOS XE Release 26.1.2 |
Cisco IOS XE Release 26.1.2 |
Cisco IOS XE Release 17.18.1 |
- C8225-G2 and C8221-G2 are the same product on every line the data sheet publishes except two. Ports, adapters, typical draw, chassis, temperature range and software floor are identical; DRAM is 16 GB against 8 GB and Threat protection is 2.4 Gbps against 1 Gbps.
- Because forwarding, IPsec and SD-WAN are 19, 5 and 4 Gbps on both, the premium buys nothing for a branch that routes and encrypts without running the full inspection stack locally. The decision is a single question about where security services execute.
- C8235-G2 shows what the multigigabit half of the series adds for the same 16 GB and 2.4 Gbps: every copper port moves to 2.5 GE, a PIM cellular bay appears, and a 120W PoE budget becomes available, at the cost of 2 lbs, 6W more typical draw and a different software train at 17.18.1.
- For deciding which SKU to order, settle whether inspection runs on the router, which separates this model from C8221-G2; then check whether any endpoint needs more than 1 GE or any power at all, since both of those move the order to C8235-G2 and a different release family.
Selection Guide
1. When One Gigabit Of Inspection Is The Ceiling
C8221-G2 matches this router on every port, adapter and chassis figure and differs only at 1 Gbps of Threat protection and 8 GB of DRAM; a branch inspecting at a regional hub gets identical routing and encryption without paying for headroom it will not reach.
2. No Path To A Powered Port
Cisco lists no PoE-capable supply for this model or its twin, so an endpoint needing power means either an injector or a move to C8235-G2; this is a permanent property of the configuration rather than an adapter choice.
3. Twenty-Six Point One Two Against Seventeen Point Eighteen
The all-gigabit models start at Cisco IOS XE Release 26.1.2 while the multigigabit models start at 17.18.1; an estate standardised on the 17.18 train has to qualify a new release family before this router enters service, and the reverse is true moving the other way.
4. Where Gigabit Copper Is Genuinely Enough
Eight 1 GE ports against the eight 2.5 GE ports of C8235-G2 costs nothing where local devices are gigabit-attached, and saves 2 lbs and roughly 6W of typical draw per site across a large branch estate.
5. Ingress Protection Narrows The Thermal Band
Fitting the dust and liquid cover drops the rated ceiling from 45 to 40 degrees C, so a protected installation in a warm space needs the same thermal check as the uncovered multigigabit models rather than the wider band the bare chassis carries.
Ordering Checklist
|
Check Item |
What to Confirm |
Why It Matters |
|---|---|---|
|
Inspection tier at order time |
Confirm 2.4 Gbps of Threat protection is required rather than the 1 Gbps of C8221-G2. |
The two SKUs are otherwise identical and Cisco documents no upgrade path between them. |
|
Powered endpoints |
Confirm no endpoint will draw power from the router. |
No PoE-capable supply is listed for this model, so a powered device needs an injector or a different SKU. |
|
Software train readiness |
Confirm the estate can run Cisco IOS XE Release 26.1.2 and Cisco Catalyst SD-WAN Release 26.1.2. |
The all-gigabit 8200 models do not run the 17.18 family the multigigabit models use. |
|
Uplink optics |
Confirm 1 GE or 10 GE SFP optics are on the order for the two SFP+ cages. |
The cages ship without transceivers and the copper ports cannot carry the uplink. |
|
Dust and liquid cover |
Confirm whether the cover is required and that the site stays inside 40 degrees C if it is fitted. |
The cover reduces the rated ceiling from 45 to 40 degrees C. |
|
Rack-mount tray |
Confirm the rack-mount tray is on the order if the chassis will be racked. |
Cisco publishes the racked dimension only with that tray, which is a separate accessory. |
Optional Add-ons
|
Add-on |
Description |
|---|---|
|
Secondary 66W AC adapter |
Additional external adapter listed as a secondary PSU option. |
|
Rack-mount tray |
Accessory that brings the desktop chassis to 2.835 x 12 x 17.56 in. for rack installation. |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | C8225-G2 | Series | Cisco 8200 Series Secure Routers |
| Platform type | Desktop form factor | WAN Ports | 2x 1/10 GE SFP+ and 2x 1 GE RJ-45 |
| Flex Ports | 2x 1 GE RJ-45 | LAN Ports | 4x 1 GE RJ-45 |
| Cellular Slot | None on this platform | Expansion Slots | None; only the -E models in this series carry a NIM slot |
| Management port | 1x RJ-45 out-of-band management | Console port | 1x RJ-45 |
| DRAM | 16 GB | Storage | 16 GB |
| Default power supply model | 66W AC external adapter | Alternative power supplies | Secondary PSU external adapter option at 66W AC |
| PoE capability | Not a PoE power sourcing device; Cisco lists no PoE-capable supply for this model | Typical power consumption | 21W |
| Input voltage | AC: 85 to 264 VAC | Forwarding (512B) | 19 Gbps |
| IPsec (512B) | 5 Gbps | SD-WAN (512B) | 4 Gbps |
| Threat protection (EMIX) | 2.4 Gbps | SD-WAN measurement basis | IPsec, Quality of Service, deep packet inspection and Flexible NetFlow enabled |
| Threat protection measurement basis | 100% Direct Internet Access NAT, NGFW, Intrusion Prevention System, URL Filtering and Advanced Malware Protection enabled | IPv4/IPv6 routes | 1.5M |
| IPsec tunnels | 700 | IPv4 ACLs | 3000 |
| IPv4 ACEs | 15,000 | NAT sessions | 1.5M |
| VRF instances | 4000 | Dimensions (H x D x W) | 1.61 x 8.5 x 12.7 in. (4.09 x 21.59 x 32.26 cm) |
| Rack units (RU) | Desktop | Dimensions with rack-mount tray | 2.835 x 12 x 17.56 in. (7.20 x 30.48 x 44.60 cm) with the tray holding the power supply |
| Chassis weight | 5 lb (2.27 kg) | Operating temperature | 0 to 45 degrees C at sea level, or 0 to 40 degrees C with the dust and liquid cover fitted |
| Storage temperature | -40 to 70 degrees C | Relative humidity | 5 to 85 percent operating; 5 to 95 percent non-operating and storage |
| Minimum device OS | Cisco IOS XE Release 26.1.2 and later | Minimum SD-WAN Manager release | Cisco Catalyst SD-WAN Release 26.1.2 and later |
Get More Information
Need pricing, stock, or shipping details for the C8225-G2 ? Layer23-Switch can help you check current availability, lead time, and delivery options for this. Send us the part number, quantity, and destination country via live chat or email sales@layer23-switch.com for a fast quotation.
Quality Certifications
Customer Reviews
Questions & Answers
-
What do I gain by choosing C8225-G2 instead of C8221-G2?
-
Does C8225-G2 improve IPsec throughput over the lower-memory model?
-
What is included in the C8225-G2 threat-protection benchmark?
-
Does a C8225-G2 hardware order include all security subscriptions?
-
Can C8225-G2 directly serve 2.5G PoE access points?
-
Can I expand C8225-G2 with a NIM or cellular module?
-
Is C8225-G2 ready for an existing IOS XE 17.18 deployment?
