CP-8811-K9 – Five-Line IP Phone – Gigabit Ethernet – Enhanced UCL
Why Layer23-Switch
Stocked, Shipped and Supported by One Team
Ships in 1 Business Day
In-stock orders leave our Hong Kong or U.S. warehouse within 1 business day after payment, with tracking by email.
LSCare Warranty
3years on enterprise equipment
Free CCIE Support
Certified engineers help before and after you buy. Reply within 1 business day by email or live chat.
Verify Before You Pay
100%factory-sealed
Get label and serial photos before shipment, and check every serial number with Cisco.
CP-8811-K9 Description
The CP-8811-K9 is a Cisco IP Phone 8811 desk phone for Cisco Unified Communications Manager environments that need a voice-only endpoint with five line keys. The phone has a 5-inch 800 x 480 grayscale display, five programmable line and feature keys, a two-port 10/100/1000 switch for a co-located PC and IEEE PoE Class 2 power. The phone does not support key expansion modules and registers to Cisco Unified Communications Manager 12.5 and later with an Enhanced User Connect License.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
CP-8811-K9 |
|
Product type |
Cisco IP Phone 8811 desk phone |
|
Programmable line and feature keys |
5 |
|
Display |
5 in. 800 x 480 grayscale widescreen display |
|
Integrated switch |
10/100/1000BASE-T with LAN and co-located PC connectivity |
|
Headset ports |
RJ-9 analog headset port and auxiliary EHS port |
|
PoE class |
IEEE Power over Ethernet Class 2 |
|
Power input rating |
0.917A, 48V DC |
|
CUCM license |
Enhanced User Connect License |
|
CUCM support |
Cisco Unified Communications Manager 12.5 and later |
|
Dimensions and weight |
9.02 x 10.13 x 1.57 in., 2.58 lb with handset |
Application Scenarios
An office worker on Cisco Unified Communications Manager gets five programmable line and feature keys on the desk, enough for a primary line plus a few shared or speed-dial keys.
Where one cable run serves the desk, the phone’s two-port 10/100/1000 switch passes the connection through to the user’s PC, so the phone and the PC share a single LAN drop.
In a wiring closet whose switch ports supply IEEE 802.3af or 802.3at power, the phone runs from PoE Class 2, and Cisco Power Cube 4 covers desks with no PoE at all.
Product Comparison
|
Parameter |
CP-8811-K9 | ||
|---|---|---|---|
|
Display |
5 in. 800 x 480 grayscale |
5 in. 800 x 480 color |
5 in. 800 x 480 color |
|
Programmable line and feature keys |
5 |
5 |
5 |
|
Bluetooth |
Not published |
Not published |
Bluetooth 3.0 EDR Class 1, up to 20 m |
|
USB |
Not published |
Not published |
Side USB port, 500 mA |
|
Key expansion module support |
Not supported |
Not supported |
Up to 2 Cisco IP Phone 8800 Key Expansion Modules |
|
Power over Ethernet |
IEEE 802.3af/at Class 2 |
IEEE 802.3af/at Class 2 |
Class 3 before hardware V08; Class 4 for V08 and later |
|
CUCM license |
Enhanced User Connect License |
Enhanced User Connect License |
Enhanced User Connect License |
CP-8811-K9 is the grayscale 5-inch model of the 8800 desk phones, while CP-8841-K9 keeps the same five line keys and Class 2 PoE but has a color display at the same 800 x 480 resolution. Desks that need USB, Bluetooth or a key expansion module move to CP-8851-K9: Cisco’s administration guide lists CP-8811-K9 as a phone without KEM support, and CP-8851-K9 takes up to two modules. CP-8851-K9 also raises the PoE requirement to Class 3 before hardware version V08 and Class 4 from V08, against Class 2 for CP-8811-K9, so the switch budget must be rechecked when moving up. All three connect to Cisco Unified Communications Manager with the Enhanced User Connect License.
Ordering Checklist
- Color variant: Order CP-8811-K9= for Charcoal or CP-8811-W-K9= for White. The color is set by the PID, and the wrong one cannot be changed after delivery.
- Call-control license: Add an Enhanced User Connect License for each phone registered to Cisco Unified Communications Manager. The phone hardware does not carry the calling entitlement.
- Power: Provide IEEE class 2 PoE from the switch, or add CP-PWR-CUBE-4= (CP-PWR-CUBE-4-S= with switch) plus a country power cord. Without PoE the phone has no power, and the cube ships without a cord.
- Expansion module: Leave CP-8800-A-KEM= off the order, since the administration guide lists the 8811 as unsupported. A module added to this phone cannot be attached.
Product Front
The following table describes the Cisco IP Phone 8800 Series Buttons.
The Cisco IP Phone 8800 Series has two distinct hardware types:
- Cisco IP Phones 8811, 8841, 8851, 8851NR, and 8861—do not have a camera.
- Cisco IP Phones 8845, 8865, and 8865NR—have a built-in camera.
|
1 |
Incoming call or voicemail indicator |
|
2 |
Camera (Cisco IP Phone 8845 and 8865) |
|
3 |
Feature and session buttons |
|
4 |
Softkeys |
|
5 |
Back, Navigation cluster, and Release |
|
6 |
Hold, Transfer, and Conference |
|
7 |
Headset, Speakerphone, and Mute |
|
8 |
Voicemail, Applications, and Directory |
|
9 |
Volume |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | CP-8811-K9 | Cisco ordering ID | CP-8811-K9= |
| Product type | Cisco IP Phone 8811 desk phone | Color | Charcoal |
| Programmable keys | 5 | Display | 5 in. 800 x 480 grayscale widescreen display |
| Ethernet switch | 10/100/1000BASE-T with two-port Cisco Ethernet switch | PC connectivity | Single LAN connection for phone and co-located PC |
| PoE class | IEEE Power over Ethernet Class 2 | PoE standards | Compatible with IEEE 802.3af and 802.3at switch blades |
| Power input rating | 0.917A, 48V DC | Local power option | Cisco IP Phone Power Cube 4 for non-PoE deployments |
| CUCM support | Cisco Unified Communications Manager 12.5 and later | Unified CME support | 10.0 and later through fast track |
| BE 6000 support | 8.6.2, 9.1.2, 10.5.2, 11.0 and later | HCS support | 8.6.2 and later using supported UCM versions |
| CUCM license | Enhanced User Connect License | Signaling protocol | Session Initiation Protocol |
| Codec support | G.711, G.722, G.722.2, G.729ab, iLBC, iSAC, OPUS | QoS | 802.1Q/p |
| Discovery protocols | Cisco Discovery Protocol, LLDP-MED | Handset | Wideband-capable RJ-9 handset |
| Analog headset | Wideband-capable RJ-9 audio port | AUX port | Electronic hookswitch control with a third-party headset |
| Speakerphone | Full-duplex speakerphone | Foot-stand positions | 35 degrees and 50 degrees |
| Wall mounting | Optional wall-mount kit available separately | Dimensions | 9.02 x 10.13 x 1.57 in. excluding foot stand |
| Weight | 2.58 lb with handset | Operating temperature | 0°C to 40°C (32°F to 104°F) |
| Operating humidity | 10% to 90%, noncondensing | Phone casing composition | Polycarbonate ABS textured plastic |
| Security slot | Kensington Security Slot compatible |
Quality Certifications
Customer Reviews
Questions & Answers
-
Which call platforms does CP-8811-K9 register to?
-
What PoE class does CP-8811-K9 need, and what powers it without PoE?
-
Which Cisco IOS releases support CP-8811-K9 on Unified CME and SRST?
-
Which firmware file installs release 14.4(1)SR1 on CP-8811-K9?
-
Which audio codecs does CP-8811-K9 support?
-
What temperature and humidity range does CP-8811-K9 operate in?
