CP-8865NR-K9 Description
The CP-8865NR-K9 is a Cisco IP Phone 8865NR no-radio video desk phone in the 8800 Series for desks where site policy bars Bluetooth and Wi-Fi. The phone has five line keys in Session Line Mode or up to 10 in Enhanced Line Mode, a 5 in. 800 x 480 color display, 720p HD video, two USB ports and an internal 2-port Gigabit Ethernet switch. The phone has no Bluetooth or Wi-Fi radio and connects only over wired Ethernet.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
CP-8865NR-K9 |
|
Product type |
Cisco IP Phone 8865NR no-radio video desk phone |
|
Color |
Charcoal |
|
Radio profile |
No Bluetooth radio and no Wi-Fi radio |
|
Programmable line and feature keys |
5 in Session Line Mode or up to 10 in Enhanced Line Mode |
|
Display and video |
5 in. 800 x 480 24-bit color WVGA display with 720p HD video |
|
USB |
Two USB ports |
|
Integrated switch |
Internal 2-port 10/100/1000BASE-T Cisco Ethernet switch |
|
Key expansion module support |
Up to three Cisco IP Phone 8800 Key Expansion Modules |
|
PoE and local power |
IEEE PoE Class 4 or Cisco IP Phone Power Cube 4 with matching AC country cord |
|
CUCM license |
Enhanced User Connect License |
Application Scenarios
In an office where policy excludes endpoint radios, the phone carries 720p HD video calls over wired Ethernet with no Bluetooth or Wi-Fi radio present.
At an attendant or shared-line desk, Enhanced Line Mode offers up to 10 line keys, and up to three key expansion modules extend the key count further.
Where one access-switch drop serves the phone and a co-located PC, the internal 2-port Gigabit Ethernet switch passes the PC connection through the phone.
Product Comparison
|
Parameter |
CP-8865NR-K9 |
CP-8865-W-K9 | |
|---|---|---|---|
|
Color |
Charcoal |
Charcoal |
White |
|
Programmable line and feature keys |
5 in Session Line Mode, up to 10 in Enhanced Line Mode |
5 |
5 |
|
Display |
5 in. 800 x 480 24-bit color WVGA |
5 in. 800 x 480 24-bit color WVGA |
5 in. 800 x 480 24-bit color WVGA |
|
Video |
720p HD H.264/AVC |
720p HD H.264/AVC |
720p HD H.264/AVC |
|
Wireless LAN |
No Wi-Fi radio |
IEEE 802.11a/b/g/n/ac |
IEEE 802.11a/b/g/n/ac |
|
Bluetooth |
No Bluetooth radio |
Bluetooth 4.1 LE, EDR Class 1 |
Bluetooth 4.1 LE, EDR Class 1 |
|
Key expansion module support |
Up to three Cisco IP Phone 8800 Key Expansion Modules |
Up to three Cisco IP Phone 8800 Key Expansion Modules |
Up to three Cisco IP Phone 8800 Key Expansion Modules |
|
PoE class |
IEEE PoE Class 4 |
IEEE PoE Class 4 |
IEEE PoE Class 4 |
CP-8865NR-K9 and CP-8865-K9 differ in radios: CP-8865NR-K9 has no Bluetooth and no Wi-Fi, while CP-8865-K9 includes 802.11a/b/g/n/ac Wi-Fi and Bluetooth 4.1. Desks that need a Bluetooth headset or a wireless connection move to CP-8865-K9, or to CP-8865-W-K9 when a white finish is wanted. CP-8865NR-K9 offers 5 line keys, or up to 10 in Enhanced Line Mode, against 5 on the other two. All three phones take up to three key expansion modules, and two or three modules need 802.3at PoE or a CP-PWR-CUBE-4 power cube.
Ordering Checklist
- Power source: Use IEEE 802.3at or UPOE PoE, or CP-PWR-CUBE-4 with a country cord. A desk without PoE has no power, and the cube is not powered without its country cord.
- Key expansion module PID: The 8865NR data sheet lists CP-BEKEM= (Charcoal); the 8865 and expansion module data sheets list CP-8800-V-KEM=. The documents write different PIDs for the module and do not say they are interchangeable.
- Module count and power: Up to three modules are supported; with two or three use 802.3at or a power cube. The rear USB fast charge is lost on 802.3at with two or three modules unless the port is UPOE.
- Wall mount: Order CP-8800-VID-WMK= for the video phone. Wall placement needs the video mount on the order.
Product Front
The following table describes the Cisco IP Phone 8800 Series Buttons.
The Cisco IP Phone 8800 Series has two distinct hardware types:
- Cisco IP Phones 8811, 8841, 8851, 8851NR, and 8861—do not have a camera.
- Cisco IP Phones 8845, 8865, and 8865NR—have a built-in camera.
|
1 |
Incoming call or voicemail indicator |
|
2 |
Camera (Cisco IP Phone 8845 and 8865) |
|
3 |
Feature and session buttons |
|
4 |
Softkeys |
|
5 |
Back, Navigation cluster, and Release |
|
6 |
Hold, Transfer, and Conference |
|
7 |
Headset, Speakerphone, and Mute |
|
8 |
Voicemail, Applications, and Directory |
|
9 |
Volume |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | CP-8865NR-K9 | Cisco ordering ID | CP-8865NR-K9= |
| Product type | Cisco IP Phone 8865NR no-radio video desk phone | Color | Charcoal |
| No-radio profile | No Bluetooth radio and no Wi-Fi radio | Standard charcoal comparison | CP-8865-K9= is Cisco IP Phone 8865, Charcoal |
| White comparison | CP-8865-W-K9= is Cisco IP Phone 8865, White | Programmable line keys | 5 in Session Line Mode or up to 10 in Enhanced Line Mode |
| Display | 5 in. 800 x 480 24-bit color WVGA display | Video | 720p HD video with H.264/AVC encoding and decoding |
| Wideband audio | G.722 audio codec support | Audio ports | 3.5 mm stereo line in/out jack and RJ-9 analog headset jack |
| USB port | Side USB and back USB ports | USB output | Side USB up to 500 mA at 5 V and back USB 500 mA upgradable to 2.1 A at 5 V |
| Ethernet switch | Internal 2-port 10/100/1000BASE-T Cisco Ethernet switch | PC connectivity | Single LAN connection for phone and co-located PC |
| KEM support | Up to three Cisco IP Phone 8800 Key Expansion Modules | Expansion button range | From 5 to 113 line buttons with KEMs |
| PoE class | IEEE PoE Class 4 | PoE standards | IEEE 802.3af, IEEE 802.3at, and Cisco UPOE switch blade compatibility |
| Local power option | Cisco IP Phone Power Cube 4 with corresponding AC country cord | CUCM support | 9.1.2, 10.5.2, 11.0 and later |
| BE 6000 support | 9.1.2, 10.5.2, 11.0 and later | HCS support | 9.1.2 and later using supported Cisco UCM versions |
| CUCM license | Enhanced User Connect License | Signaling protocol | Session Initiation Protocol |
| Codec support | G.711, G.722, G.729a, iLBC, and iSAC | QoS | 802.1Q/p |
| Discovery protocols | Cisco Discovery Protocol, LLDP-MED | Switch speed | Autonegotiation |
| Security features | Secure boot, device authentication, TLS signaling, SRTP media, HTTPS, SSH, and SSL VPN client | Security slot | Kensington Security Slot compatible |
| Foot-stand positions | 35 degrees and 50 degrees | Wall mounting | Optional wall-mount kit available separately |
| Dimensions | 9.01 x 10.13 x 3.87 in. excluding foot stand | Weight | 1.35 kg (2.97 lb) |
| Operating temperature | 0°C to 40°C (32°F to 104°F) | Operating humidity | 10% to 90%, noncondensing |
| Phone casing composition | Polycarbonate ABS textured plastic |
