CP-8845-K9 Description
The CP-8845-K9 is a Cisco IP Phone 8800 Series video desk phone for offices that take calls with 720p video from the desk. The phone has five programmable line and feature keys, a 5-inch 800 x 480 color display with 720p H.264/AVC video and a two-port Gigabit Ethernet switch, and it supports Bluetooth 4.1 LE. The phone runs on IEEE PoE Class 2 and does not support Key Expansion Modules.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
CP-8845-K9 |
|
Product type |
Cisco IP Phone 8845 video desk phone |
|
Color |
Charcoal |
|
Programmable line and feature keys |
5 |
|
Display |
5 in. 800 x 480 24-bit color WVGA display |
|
Video |
720p HD video with H.264/AVC encoding and decoding |
|
Integrated switch |
Internal 2-port 10/100/1000BASE-T Cisco Ethernet switch |
|
Bluetooth |
Bluetooth 4.1 LE, EDR Class 1 up to 66 ft (20 m) |
|
PoE class |
IEEE Power over Ethernet Class 2 |
|
Local power option |
Cisco IP Phone Power Cube 4 with corresponding AC country cord |
|
CUCM license |
Enhanced User Connect License |
Application Scenarios
Staff who join video calls on Cisco Unified Communications Manager can do so from the desk phone, using its 720p H.264/AVC video and 5-inch color display.
A desk with one access-switch drop connects the phone and a co-located PC through the internal two-port Gigabit Ethernet switch.
Desks where staff pair a wireless headset use the phone’s Bluetooth 4.1 LE radio, a Class 1 device with a range of up to 66 ft (20 m).
Product Comparison
|
Parameter |
CP-8845-K9 |
CP-8845-W-K9 | |
|---|---|---|---|
|
Display |
5 in. 800 x 480 24-bit color WVGA |
5 in. 800 x 480 24-bit color WVGA |
5 in. 800 x 480 24-bit color WVGA |
|
Programmable line and feature keys |
5 |
5 |
5 |
|
Video |
720p HD H.264/AVC |
720p HD H.264/AVC |
720p HD H.264/AVC |
|
Integrated switch |
10/100/1000BASE-T, 2-port |
10/100/1000BASE-T, 2-port |
10/100/1000BASE-T, 2-port |
|
Bluetooth |
Bluetooth 4.1 LE, EDR Class 1 |
Bluetooth 4.1 LE, EDR Class 1 |
Bluetooth 4.1 LE, EDR Class 1 |
|
PoE class |
IEEE Power over Ethernet Class 2 |
IEEE Power over Ethernet Class 2 |
IEEE Power over Ethernet Class 4 |
|
Wi-Fi |
Not published |
Not published |
802.11a/b/g/n/ac |
|
USB |
Not published |
Not published |
2 |
|
Key expansion module support |
Not supported |
Not supported |
Up to 3 |
CP-8845-K9 and CP-8865-K9 both have a 5 in. color display, 720p H.264 video and Bluetooth 4.1, but CP-8845-K9 is a PoE Class 2 phone while CP-8865-K9 is Class 4, and the Cisco 8865 datasheet adds 802.11a/b/g/n/ac Wi-Fi, two USB ports and support for up to three Key Expansion Modules, none of which Cisco lists for CP-8845-K9. A desk that needs Wi-Fi or a KEM must therefore use CP-8865-K9, because CP-8845-K9 does not support KEMs. CP-8845-W-K9 is the white version of CP-8845-K9 with the same specifications. If video is not needed, CP-8841-K9 is the non-video color model.
Ordering Checklist
- Unified CM license: Add an Enhanced User Connect License for each CP-8845-K9 registering to Cisco UCM. Without it the video phone cannot be added to Cisco UCM.
- Power source: Use PoE Class 2 from the switch, or CP-PWR-CUBE-4 plus one cord from CP-PWR-CORD-{AP,AR,AU,BZ,CE,CN,JP,NA,SW,UK}=. A non-PoE desk has no power, and Power Cube 4 needs a country cord.
- Video-model mounting parts: Order CP-8800-VIDEO-WMK= for wall mounting and CP-8800-B-VID-BEZEL= or CP-8800-S-VID-BEZEL= for the bezel, not CP-8800-WMK= or CP-8800-B-BEZEL=. The 8845 has separate VIDEO/VID spare parts, so the standard parts are the wrong order.
Product Front
The following table describes the Cisco IP Phone 8800 Series Buttons.
The Cisco IP Phone 8800 Series has two distinct hardware types:
- Cisco IP Phones 8811, 8841, 8851, 8851NR, and 8861—do not have a camera.
- Cisco IP Phones 8845, 8865, and 8865NR—have a built-in camera.
|
1 |
Incoming call or voicemail indicator |
|
2 |
Camera (Cisco IP Phone 8845 and 8865) |
|
3 |
Feature and session buttons |
|
4 |
Softkeys |
|
5 |
Back, Navigation cluster, and Release |
|
6 |
Hold, Transfer, and Conference |
|
7 |
Headset, Speakerphone, and Mute |
|
8 |
Voicemail, Applications, and Directory |
|
9 |
Volume |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | CP-8845-K9 | Cisco ordering ID | CP-8845-K9= |
| Product type | Cisco IP Phone 8845 video desk phone | Color | Charcoal |
| Same-model color SKU | CP-8845-W-K9= is Cisco IP Phone 8845, White | Related video phone SKU | CP-8865-K9= is Cisco IP Phone 8865, Charcoal |
| Programmable keys | 5 | Display | 5 in. 800 x 480 24-bit color WVGA display |
| Video | 720p HD video with H.264/AVC encoding and decoding | Wideband audio | G.722 on handset, speakerphone, and headset |
| Ethernet switch | Internal 2-port 10/100/1000BASE-T Cisco Ethernet switch | PC connectivity | Single LAN connection for phone and co-located PC |
| Bluetooth | Bluetooth 4.1 LE, EDR Class 1 up to 66 ft (20 m) | Bluetooth profiles | Hands-Free Profile and Phone Book Access Profile |
| Headset ports | RJ-9 analog headset port and auxiliary port | Electronic hookswitch | Third-party headset control through auxiliary port |
| PoE class | IEEE Power over Ethernet Class 2 | PoE standards | Compatible with IEEE 802.3af and IEEE 802.3at switch blades |
| Local power option | Cisco IP Phone Power Cube 4 for non-PoE deployments | Local power requirement | Matching AC country cord required with Power Cube 4 |
| CUCM support | 8.5.1 non-secured mode only, 8.6.2, 9.1.2, 10.5.2, 11.0 and later | BE 6000 support | 8.6.2, 9.1.2, 10.5.2, 11.0 and later |
| HCS support | 8.6.2 and later using supported UCM versions | CUCM license | Enhanced User Connect License |
| Signaling protocol | Session Initiation Protocol | Codec support | G.711a-law and mu-law, G.722, G.729a, iLBC, and iSAC |
| QoS | 802.1Q/p | Discovery protocols | Cisco Discovery Protocol, LLDP-MED |
| Switch speed | Auto-negotiation | Mobile integration | Call-history and contact synchronization through Cisco Intelligent Proximity |
| Foot-stand positions | 35 degrees and 50 degrees | Wall mounting | Optional wall-mount kit orderable separately |
| Dimensions | 9.01 x 10.13 x 3.87 in. excluding foot stand | Weight | 1.35 kg (2.97 lb) |
| Operating temperature | 0°C to 40°C (32°F to 104°F) | Operating humidity | 10% to 90%, noncondensing |
| Phone casing composition | Polycarbonate ABS textured plastic | Security slot | Kensington Security Slot compatible |
