CP-8875-K9 – 7-inch Touchscreen Video Phone – 1080p Camera – 802.11ac Wi-Fi and Bluetooth 4.2
Why Layer23-Switch
Stocked, Shipped and Supported by One Team
Ships in 1 Business Day
In-stock orders leave our Hong Kong or U.S. warehouse within 1 business day after payment, with tracking by email.
LSCare Warranty
3years on enterprise equipment
Free CCIE Support
Certified engineers help before and after you buy. Reply within 1 business day by email or live chat.
Verify Before You Pay
100%factory-sealed
Get label and serial photos before shipment, and check every serial number with Cisco.
CP-8875-K9 Description
The CP-8875-K9 is a Cisco Video Phone 8875 touchscreen video desk phone in Carbon Black for hybrid-work desks that place calls and join video meetings. The phone pairs a 7-inch 1024 x 600 touchscreen with a 1080p camera that streams Full HD 1080p30 video, and it connects through an internal 2-port 10/100/1000BASE-T switch on IEEE PoE class 4 power. Line capacity depends on call control: up to 108 lines on Cisco Unified Communications Manager or Webex Dedicated Instance, and 16 on Webex Calling or BroadWorks.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
CP-8875-K9 |
|
Display |
7-inch 1024 x 600 IPS LCD touchscreen with virtual keyboard |
|
Camera and video |
1080p pivoting camera with privacy shutter; Full HD 1080p30 H.264 AVC video |
|
Maximum supported lines |
108 on CUCM and Webex DI; 16 on Webex Calling and BroadWorks |
|
Call control platforms |
Webex Calling Multi-tenant, Webex Calling Dedicated Instance, BroadWorks Release 24.0, Webex for BroadWorks, CUCM 12.5+ |
|
Ethernet switch |
Internal 2-port 10/100/1000BASE-T Cisco Ethernet switch |
|
Wi-Fi |
IEEE 802.11a/b/g/n/ac, 2.4 GHz and 5 GHz dual band |
|
Bluetooth |
Bluetooth 4.2 LE, EDR Class 1, up to 66 ft (20 m) |
|
Power |
IEEE PoE class 4 or Cisco Power Cube 4 |
Application Scenarios
In an office where hybrid workers book desks by the day, the phone registered to Webex Calling lets each user sign in natively or with a QR code and bring their own contacts, calendar and number to the shared device.
A manager who joins scheduled meetings from the desk uses One Button to Push from the calendar, with the 1080p camera, privacy shutter and noise removal handling the video and audio.
An administrative assistant on Cisco Unified Communications Manager can handle up to 108 lines from the touchscreen and watch the status of other lines from the swipe-down speed dial page.
Product Comparison
|
Parameter |
CP-8875-K9 | ||
|---|---|---|---|
|
Display |
7-inch 1024 x 600 IPS LCD touchscreen |
5-inch 800 x 480 24-bit color WVGA |
5-inch 800 x 480 color |
|
Programmable line keys |
Not applicable |
5 |
5 |
|
Maximum supported lines |
108 on CUCM and Webex DI; 16 on Webex Calling and BroadWorks |
Not published |
Not published |
|
Key expansion module support |
Not published |
Up to 3, expanding to 113 line buttons |
Not supported |
|
Video |
Full HD 1080p30, H.264 AVC |
720p HD encode and decode |
720p HD two-way, H.264/AVC |
|
Wi-Fi |
IEEE 802.11a/b/g/n/ac |
IEEE 802.11a/b/g/n/ac |
Not published |
|
Bluetooth |
Bluetooth 4.2 LE, EDR Class 1 |
Bluetooth 4.1 LE, EDR Class 1 |
Bluetooth 4.1 LE, EDR Class 1 |
|
PoE class |
IEEE PoE class 4 |
IEEE PoE class 4 |
IEEE PoE class 2 |
CP-8875-K9 and CP-8865-K9 split on line handling: the CP-8875-K9 touchscreen carries up to 108 lines on Cisco Unified Communications Manager, while CP-8865-K9 has five programmable line keys. Attendant desks that work from physical buttons fit CP-8865-K9, which reaches 113 buttons with up to three Key Expansion Modules. Where access ports cannot supply IEEE PoE class 4, CP-8845-K9 keeps 720p video at class 2 on the same 5-inch 800 x 480 display size as CP-8865-K9. Webex Calling and BroadWorks registrations stop at 16 lines on CP-8875-K9. Not every Unified Communications Manager 12.5 or later release supports CP-8875-K9 natively, so a device pack and device enabler (QED) file may be needed before registration.
Ordering Checklist
- Power source: Desks without an IEEE PoE class 4 port need CP-PWR-CUBE-4= plus a country cord such as CP-PWR-CORD-NA= or CP-PWR-CORD-CE=. The cords are separate order lines from the power cube.
- Wall mount: Add CP-8875-VIDEO-WMK=, the wall mount kit listed for the Video Phone 8875, for every phone that will hang on a wall instead of standing on its kickstand.
Product Front
The following table describes the Cisco IP Phone 8800 Series Buttons.
The Cisco IP Phone 8800 Series has two distinct hardware types:
- Cisco IP Phones 8811, 8841, 8851, 8851NR, and 8861—do not have a camera.
- Cisco IP Phones 8845, 8865, and 8865NR—have a built-in camera.
|
1 |
Incoming call or voicemail indicator |
|
2 |
Camera (Cisco IP Phone 8845 and 8865) |
|
3 |
Feature and session buttons |
|
4 |
Softkeys |
|
5 |
Back, Navigation cluster, and Release |
|
6 |
Hold, Transfer, and Conference |
|
7 |
Headset, Speakerphone, and Mute |
|
8 |
Voicemail, Applications, and Directory |
|
9 |
Volume |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | CP-8875-K9 | Cisco ordering ID | CP-8875-K9= |
| Product type | Cisco Video Phone 8875 video desk phone | Color | Carbon Black |
| White version | CP-8875-L-K9= Cisco Video Phone 8875, First Light White | Non-Radio version | CP-8875NR-K9= Cisco Video Phone 8875 Non-Radio version, Carbon Black |
| Display | 7-inch LCD, 1024 x 600 resolution, IPS LED panel | Contrast ratio | 1200:1 (typical) |
| Viewing angle | +/-85° (typical) | Brightness | 350 cd/m2 |
| Color depth | 16.7M colors | Touch screen | Touch input with virtual keyboard for search and text entry |
| Camera | 1080p pivoting camera, 4MP 1/3-inch CMOS sensor up to 30 fps | Aperture | f/2.2 |
| Camera field of view | 72° horizontal, 45° vertical | Autofocus | Face detection-based automatic focus |
| Auto exposure | Face detection-based automatic exposure | White balance | Automatic |
| Focus distance | 20 cm to infinity | Camera privacy | Privacy shutter and front LED indicating camera status |
| Video | Full HD 1080p30 video stream, H.264 AVC | Audio frequency response | 150 Hz to 20 kHz full band |
| Audio processing | Acoustic echo cancellation, background noise reduction, automatic gain control, comfort noise generation, voice activity detection, packet loss concealment, adaptive jitter buffer | Wideband audio | TIA-920 WB/HD audio compliant |
| Audio codec support | G.711 a-law and mu-law, G.722, G.729a, iLBC, OPUS, iSAC | Maximum supported lines | 108 for CUCM and Webex DI; 16 for Webex Calling and BroadWorks |
| Hard keys | Hold/resume, transfer, conference, messaging, application, directory, keypad, volume, speakerphone, headset, mute, home and power | Handset | Wideband RJ-9 handset, hearing aid compatible |
| Speakerphone | Full-duplex speakerphone | Analog headset | Wideband RJ-9 headset port |
| AUX port | Electronic hookswitch control for a connected headset | USB | One USB-C port and one USB-A port |
| USB charging | Side USB-A port up to 2.1A at 5V (10.5W) | Ethernet switch | Internal 2-port 10/100/1000BASE-T (IEEE 802.3i/802.3u/802.3ab), RJ-45, single LAN connection for phone and co-located PC |
| VLAN IDs | Separate IEEE 802.1Q VLANs for PC and phone | Wi-Fi | IEEE 802.11a/b/g/n/ac, 2.4 GHz and 5 GHz dual band |
| Antenna type | Dipole (on-board) | Antenna gain | 1.79 dBi at 2.4 GHz, 2.27 dBi at 5 GHz |
| Wi-Fi authentication | WPA, WPA2, EAP-FAST, PEAP-MSCHAPv2, PEAP-GTC | Wi-Fi standards | IEEE 802.11d, 802.11r, 802.11e, 802.11h; Call Admission Control |
| Bluetooth | Bluetooth 4.2 LE, EDR Class 1, up to 66 ft (20 m) | Bluetooth profile | Hands-Free Profile (HFP) |
| Power | IEEE Power over Ethernet class 4 | Input rating | 1.041A, 48VDC |
| Networked standby power consumption | 5.92W | Standby mode power | 0.17W |
| Local power option | CP-PWR-CUBE-4= Cisco Power Cube 4 with country power cord | Platform support | Webex Calling Multi-tenant, BroadWorks Release 24.0, Webex for BroadWorks, Cisco Unified Communications Manager 12.5+, Webex Calling Dedicated Instance |
| CUCM device support | Some CUCM 12.5+ releases need a device pack and device enabler file (QED) | Firmware | PhoneOS, one firmware load for all supported platforms |
| Webex cloud features | Unified call history, unified directory, One Button To Push, hot desking, in-meeting control | Network features | SIP, SDP, IPv4 and IPv6, DHCP or static, DNS, TFTP, HTTPS, RTP/RTCP, Cisco Discovery Protocol, LLDP-MED, switch speed auto-negotiation, MRA via activation code |
| Security | Secure boot, SIP OAuth, SUDI, 802.1x EAP-FAST and EAP-TLS, TLS signaling, SRTP media, TLS 1.0 disabled, FIPS 140-2 compliant | Physical dimensions (H x W x D) | 10.79 x 10.139 x 4.32 in. (273.58 x 258.85 x 109.62 mm) excluding foot stand |
| Weight | 1310 g | Kickstand | Adjustable by 20 degrees |
| Phone-casing composition | Polycarbonate ABS textured plastic | Operating temperature | 0°C to 40°C (32°F to 104°F) |
| Nonoperating temperature shock | -10°C to 60°C (14°F to 140°F) | Operating humidity | Operating 10% to 90%, nonoperating 10% to 95%, noncondensing |
| Wall mount kit | CP-8875-VIDEO-WMK= | Safety certifications | UL 62368-1, CAN/CSA 62368-1, EN 62368, IEC 62368-1, AS/NZS 62368 |
| EMC emissions | FCC Part 15 Class B, CISPR32 Class B, EN 55032 Class B, ICES003 Class B, VCCI Class B | EMC immunity | EN 55035:2017+A11:2020 Class B |
| Telecom | FCC Part 68 HAC, CS-03-HAC, TIA 810, TIA 920, IEEE 802.3af and 802.3at | Radio | FCC Part 15.247 and 15.407, RSS-247, EN 300 328, EN 301 893, EN 301 489 |
Quality Certifications
Customer Reviews
Questions & Answers
-
Which call control platforms does CP-8875-K9 register to?
-
What power does CP-8875-K9 need?
-
Which calendar does One Button to Push use on CP-8875-K9 under each call control?
-
Who sets the custom wallpaper and logo on CP-8875-K9?
-
What Wi-Fi antenna gain does CP-8875-K9 have?
-
Which EMC and safety standards are listed for CP-8875-K9?
-
Is there a non-radio or TAA version of CP-8875-K9?
-
What audio bandwidth does CP-8875-K9 support?
