C1200-24T-4G – 24x1G Data Ports – 4x1G SFP Uplinks – Fanless Catalyst 1200
8/mo Solds
Established Global IT Distributor
With over a decade of industry experience, we are a certified Cisco Partner delivering genuine enterprise networking hardware and trusted services to system integrators, ISPs, and enterprises worldwide.
C1200-24T-4G Description
C1200-24T-4G is a Cisco Catalyst 1200 Series managed Gigabit Ethernet switch for campus access deployments that need a data-only 24-port copper access layer with fiber uplinks. It provides 24 x 10/100/1000 downlink ports and 4 x Gigabit SFP uplink interfaces, with 56.0 Gbps switching capacity and a 41.66 Mpps forwarding rate for small and midsize network closets. This model uses an internal universal AC power supply, has a fanless design, and does not provide a PoE output budget, making it suitable where connected endpoints have separate power or do not require PoE from the switch.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
C1200-24T-4G |
|
Product type |
Managed Gigabit Ethernet switch |
|
Downlink ports |
24 x 10/100/1000 data ports |
|
Uplink interfaces |
4 x Gigabit SFP |
|
PoE profile |
No PoE output budget model with no PoE output budget |
|
Switching capacity |
56.0 Gbps |
|
Forwarding rate |
41.66 Mpps |
|
Packet buffer |
1.5 MB |
|
Internal power input |
Internal universal AC power |
|
Fan design |
Fanless |
|
Dimensions |
445 x 240 x 44 mm |
|
Unit weight |
2.63 kg |
Product Performance
Key Features
The order line is for 24 Gigabit copper data ports, so it should not replace a PoE+ Catalyst 1200 SKU when phones, cameras, access points, or other powered endpoints require switch power.
The 4 x Gigabit SFP uplink layout suits access closets that need fiber handoff or copper SFP handoff while staying on the 1G uplink tier.
Cisco identifies C1200-24T-4G as fanless, which matters for classrooms, retail back rooms, open offices, and other locations where access-switch noise is a placement constraint.
The switch uses internal 100 to 240V AC power, so the rack plan should match the supplied power cord and PDU rather than an external power-adapter expectation.
Catalyst 1200 documentation lists IPv4 and IPv6 static routing, up to 32 static routes, and up to 16 IP interfaces for simple inter-VLAN routing at the access layer.
Cisco documents web UI, CLI access, SNMP, Cisco Business Dashboard, and Cisco Business mobile app management options for Catalyst 1200 deployments.
Application Scenarios
C1200-24T-4G fits branch and small-office racks where the endpoint plan is data-only and the bill of materials needs 24 copper access ports with four 1G uplinks.
The fanless chassis and 445 x 240 x 44 mm form factor help when the switch is installed near users rather than in a separate equipment room.
Use this SKU where the upstream design is based on Gigabit SFP links and the buyer does not need the 10G SFP+ uplink class of C1200-24T-4X.
Product Comparison
|
Parameter |
C1200-24T-4G | |||
|---|---|---|---|---|
|
Product type |
Managed Gigabit Ethernet switch |
Managed Gigabit Ethernet switch |
Managed Gigabit Ethernet PoE+ switch |
Managed Gigabit Ethernet switch |
|
Downlink ports |
24 x 10/100/1000 data |
16 x 10/100/1000 data |
24 x 10/100/1000 PoE+ |
24 x 10/100/1000 data |
|
Uplink interfaces |
4 x Gigabit SFP |
2 x Gigabit SFP |
4 x Gigabit SFP |
4 x 10 Gigabit SFP+ |
|
PoE profile |
No PoE output budget |
No PoE output |
PoE+ with 195W budget |
No PoE output |
|
Switching capacity |
56.0 Gbps |
36.0 Gbps |
56.0 Gbps |
128.0 Gbps |
|
Forwarding rate |
41.66 Mpps |
26.78 Mpps |
41.66 Mpps |
95.23 Mpps |
|
Power supply |
Internal universal AC |
Internal universal AC |
Internal universal AC |
Internal universal AC |
|
Fan design |
Fanless |
Fanless |
Fanless |
Fanless |
|
Dimensions |
445 x 240 x 44 mm |
268 x 272 x 44 mm |
445 x 299 x 44 mm |
445 x 240 x 44 mm |
|
Unit weight |
2.63 kg |
1.78 kg |
3.53 kg |
2.78 kg |
- In a C1200-24T-4G vs C1200-16T-2G comparison, the difference is access scale: C1200-24T-4G moves to 24 data ports and four 1G SFP uplinks.
- The C1200-24T-4G vs C1200-24P-4G difference is PoE: both keep 24 copper ports and 4 x Gigabit SFP uplinks, but C1200-24P-4G adds a 195W PoE+ budget.
- For C1200-24T-4G vs C1200-24T-4X, the comparison is uplink tier and performance class: the 4X model uses 4 x 10 Gigabit SFP+ uplinks with 128.0 Gbps switching capacity.
- The which model to choose check should start with data-only versus PoE endpoints, then confirm whether the uplink handoff is 1G SFP or 10G SFP+.
Selection Guide
1. Select it for 24-port data access
Choose C1200-24T-4G when the site needs 24 non-PoE Gigabit copper ports and four dedicated 1G SFP uplinks.
2. Stay with C1200-16T-2G for smaller closets
Use C1200-16T-2G when 16 copper data ports and two 1G SFP uplinks cover the endpoint count without adding unused rack width.
3. Move to C1200-24P-4G for powered endpoints
Specify C1200-24P-4G when the same 24-port 1G-uplink layout must power phones, cameras, access points, or other PoE+ endpoints.
4. Change to C1200-24T-4X for 10G uplinks
Use C1200-24T-4X when the copper access count stays at 24 ports but the uplink design requires 10 Gigabit SFP+ interfaces.
Ordering Checklist
|
Order Area |
Confirmation Needed |
Procurement Risk |
|---|---|---|
|
PID lock |
Use C1200-24T-4G for the 24-port data Catalyst 1200 line item |
Avoids mixing the data model with PoE or 10G-uplink PIDs |
|
Endpoint power plan |
Attached copper devices are self-powered or do not require switch-supplied PoE |
Prevents a non-PoE switch from being placed in a powered endpoint bill |
|
Uplink bill |
Four Gigabit SFP ports match the selected Cisco-listed 1G optics or copper SFPs |
Keeps the optic order aligned to the 4G model rather than SFP+ hardware |
|
AC power design |
The rack uses internal 100 to 240V AC input and the proper power cord |
Removes the risk of planning around an external adapter |
|
Operations access |
Web UI, CLI, SNMP, Cisco Business Dashboard, or mobile app fits the support workflow |
Aligns the switch with the expected management method |
Optional Add-ons
|
Model |
Description |
|---|---|
|
CAB-CONSOLE-RJ45 |
Cisco console cable with RJ-45 connector for Catalyst 1200 models |
|
CAB-CONSOLE-USB-C |
Cisco USB-C console cable option for Catalyst 1200 models |
|
CAB-CONSOLE-USB-C= |
Cisco USB-C console cable spare option for Catalyst 1200 models |
|
PWR-CLP |
Cisco power cable restraining clip for Catalyst 1200 models |
|
RCKMNT-1RU-1K= |
Rack-mount kit for 1RU C1000, C1200, and C1300 24-port and 48-port models |
|
MGBSX1 |
Cisco-listed 1000 Mbps multimode fiber SFP option |
|
MGBLH1 |
Cisco-listed 1000 Mbps single-mode fiber SFP option up to 40 km |
|
MGBLX1 |
Cisco-listed 1000 Mbps single-mode fiber SFP option up to 10 km |
|
MGBT1 |
Cisco-listed 1000 Mbps UTP Cat 5e SFP option up to 100 m |
|
GLC-SX-MMD |
Cisco-listed 1000BASE-SX multimode SFP option with DOM |
|
GLC-LH-SMD |
Cisco-listed 1000BASE-LX/LH single-mode SFP option with DOM |
|
GLC-TE |
Cisco-listed 1000BASE-T copper SFP option |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | C1200-24T-4G | Product type | Managed Gigabit Ethernet switch |
| Downlink ports | 24 x 10/100/1000 data ports | Uplink interfaces | 4 x Gigabit SFP |
| Total system ports | 28 x Gigabit Ethernet | PoE profile | Data-only model with no PoE output budget |
| Switching capacity | 56.0 Gbps | Forwarding rate | 41.66 Mpps |
| Packet buffer | 1.5 MB | MAC address table | 8,000 addresses |
| Jumbo frame | Up to 9000 bytes | Active VLANs | Up to 255 |
| Static routing | Up to 32 static routes | Layer 3 interfaces | Up to 16 IP interfaces |
| ACL scale | Up to 512 rules | QoS queues | 8 hardware queues |
| Management | Web UI, CLI, Cisco Business Dashboard, mobile app, SNMP | Operating software | Customized Linux OS software |
| Console port | Cisco Standard RJ-45 console and USB Type C port | Flash memory | 512 MB |
| Power supply | Internal universal AC | AC input | 100 to 240V, 50 to 60 Hz |
| System power consumption | 110V=13.9W; 220V=14.2W | Idle power | 110V=4.7W; 220V=4.9W |
| Heat dissipation | 48.4 BTU/hr | Fan design | Fanless |
| MTBF | 2,026,793 hours at 25 C | Dimensions | 445 x 240 x 44 mm |
| Unit weight | 2.63 kg | Operating temperature | 23 to 122 F (-5 to 50 C) |
| Storage temperature | -13 to 158 F (-25 to 70 C) | Warranty | Limited lifetime |
| Package contents | Switch, power cord, mounting kit, pointer card | Minimum Ethernet cable | Category 5e or higher for 1000BASE-T |
