C1200-8T-E-2G Description
The C1200-8T-E-2G is a Cisco Catalyst 1200 Series managed access switch for small offices and shop back rooms that connect data-only Gigabit endpoints. The switch has eight 10/100/1000 RJ-45 ports with no PoE output, two Gigabit copper/SFP combo uplinks and 20 Gbps of switching capacity in a fanless chassis fed by an external supply. Layer 3 is static routing only, up to 32 IPv4/IPv6 routes, so routing protocols remain on an upstream router.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
C1200-8T-E-2G |
|
RJ-45 ports |
8 x Gigabit Ethernet (10/100/1000) |
|
Combo ports |
2 x Gigabit Ethernet combo (RJ-45 + SFP) |
|
Power over Ethernet |
Data only, no PoE output |
|
Switching capacity |
20 Gbps |
|
Forwarding rate |
14.88 Mpps (64-byte packets) |
|
Packet buffer |
1.5 MB |
|
Layer 3 routing |
IPv4/IPv6 static routing, up to 32 static routes |
|
Power supply |
External, 100 to 240V 50 to 60 Hz |
|
Power consumption (worst case) |
10.63W at 110V |
|
Fan modules |
Fanless |
|
Mounting |
Rack-mountable, 268 x 185 x 44 mm |
Product Performance
Key Features
Each of the two uplinks pairs an RJ-45 port with a Gigabit SFP slot, and only one side of the pair is active at a time. A fiber run can therefore use GLC-SX-MMD for up to 550 m on multimode or GLC-LH-SMD for up to 10 km on single-mode, while the other uplink stays on copper.
The switch has no fan and draws at most 10.63W at 110V, releasing 36.33 BTU/hr of heat. That makes it workable on an open shelf or in a small cabinet where fan noise or heat would be a problem.
Up to 32 static routes across 16 IP interfaces let the switch route between local VLANs at wire speed, with DHCP relay passing address requests to a server on another subnet.
Application Scenarios
In a small office, the switch connects desktop PCs, printers and a file server over its eight Gigabit ports and links to the office router through one of its combo uplinks.
A retail store can wire its point-of-sale terminals and the back-office PC to the switch and keep the payment devices on a VLAN of their own.
Where a classroom or library is cabled to the main building over fiber, a 1G SFP in one combo uplink terminates the run, and the fanless chassis stays quiet inside the room.
Product Comparison
|
Parameter |
C1200-8T-E-2G | |||
|---|---|---|---|---|
|
RJ-45 ports |
8 x Gigabit Ethernet |
8 x Gigabit Ethernet PoE+ |
16 x Gigabit Ethernet |
8 x Gigabit Ethernet |
|
Power dedicated to PoE |
Not applicable |
67W |
Not applicable |
Not applicable |
|
Uplink ports |
2 x Gigabit copper/SFP combo |
2 x Gigabit copper/SFP combo |
2 x Gigabit SFP |
2 x Gigabit copper/SFP combo |
|
Switching capacity |
20 Gbps |
20 Gbps |
36 Gbps |
20 Gbps |
|
Fan modules |
Fanless |
Fanless |
Fanless |
Fanless |
|
Layer 3 routing |
IPv4/IPv6 static routing |
IPv4/IPv6 static routing |
IPv4/IPv6 static routing |
Static routing, RIP v2, policy-based routing |
|
IPv4 routing scale |
32 static routes, 16 IP interfaces |
32 static routes, 16 IP interfaces |
32 static routes, 16 IP interfaces |
990 dynamic and static routes, 128 IP interfaces |
C1200-8T-E-2G and C1200-8P-E-2G share eight Gigabit ports, two combo uplinks and 20 Gbps of switching, but C1200-8T-E-2G is data only, while C1200-8P-E-2G supplies PoE+ from a 67W budget for phones, access points or cameras powered from the switch. When eight copper ports are not enough, C1200-16T-2G doubles them to 16 with 36 Gbps of switching, although its two uplinks are SFP slots rather than combo ports. Every Catalyst 1200 model in the table stops at 32 static routes. Sites that exchange routes with a neighbor router need C1300-8T-E-2G, which keeps the same port layout and fanless chassis but adds RIP v2 and policy-based routing with up to 990 routes.
Ordering Checklist
- Rack bracket: Add RCKMNT-CMPCT-1K= when the switch will sit in a 19-in. rack. Only 24-port and 48-port Catalyst 1200 models ship with 19-in. brackets, so an 8-port order without it arrives with no rack hardware.
- Uplink optics: Add a supported 1G SFP such as GLC-SX-MMD, GLC-LH-SMD or GLC-TE for each combo uplink that will run on an SFP. The package contains only the switch, power cord or adapter, mounting kit and pointer card.
Optional Add-ons
|
Model |
Description |
|---|---|
|
RCKMNT-CMPCT-1K= |
19-in. rack-mount bracket for C1000, C1200 and C1300 8-port and 16-port models |
|
CAB-CONSOLE-RJ45 |
6 ft console cable with RJ-45 connector |
|
CAB-CONSOLE-USB-C |
USB-C console cable |
|
CAB-CONSOLE-USB-C= |
USB-C console cable, spare |
|
PWR-CLP |
Power cable restraining clip |
|
1000BASE-SX SFP, multimode fiber, 550 m | |
|
1000BASE-LX/LH SFP, single-mode fiber, 10 km | |
|
GLC-BX-U |
1000BASE-BX SFP upstream, single-mode fiber, 10 km |
|
GLC-BX-D |
1000BASE-BX SFP downstream, single-mode fiber, 10 km |
|
1000BASE-T copper SFP, UTP Cat 5e, 100 m | |
|
MGBSX1 |
Gigabit SFP, multimode fiber, 500 m |
|
MGBLX1 |
Gigabit SFP, single-mode fiber, 10 km |
|
MGBLH1 |
Gigabit SFP, single-mode fiber, 40 km |
|
MGBT1 |
Gigabit copper SFP, UTP Cat 5e, 100 m |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | C1200-8T-E-2G | Operating system | Customized Linux OS software |
| Downlink ports | 8 x Gigabit Ethernet | Total ports | 10 x Gigabit Ethernet |
| Combo ports | 2 x Gigabit Ethernet combo, one side active at a time | Copper cabling | UTP Category 5e or better for 1000BASE-T |
| Console port | Cisco Standard RJ-45 console and USB Type C port | Switching capacity | 20 Gbps, wire speed and nonblocking |
| Forwarding rate | 14.88 Mpps (64-byte packets) | Packet buffer | 1.5 MB, dynamically shared across all ports |
| CPU | Dual-core ARM at 1.4 GHz | DRAM | 1 GB DDR4 |
| Flash | 512 MB | MAC addresses | 8,000 addresses |
| Active VLANs | Up to 255 | IP interfaces | Up to 16 |
| Static routes | Up to 32 | ACL entries | Up to 512 rules, ingress and egress, time-based |
| Link aggregation | IEEE 802.3ad LACP, up to 4 groups, up to 8 ports per group | Port mirroring | Up to 4 source ports to 1 destination port |
| Jumbo frames | Up to 9,000 bytes (default MTU 2,000 bytes) | Layer 2 features | 802.1D STP, 802.1w RSTP, MSTP 8 instances, PVST+/RPVST+ 126 instances |
| Layer 3 features | Wire-speed IPv4 and IPv6 static routing; DHCP relay and UDP relay at Layer 3 | Multicast features | IGMP v1/v2/v3, 255 multicast groups; MLD v1/v2 snooping |
| QoS features | 8 hardware queues, strict priority and WRR, 802.1p/DSCP classification | Security features | 802.1X authenticator, SSH/SSL, port security, storm control, DoS prevention, RADIUS |
| Management features | On-device web UI, Cisco Business Dashboard, Cisco Business mobile app, Cisco PnP, SNMP v1/v2c/v3, text view CLI | Default power supply | External |
| AC input voltage | 100 to 240V | AC input frequency | 50 to 60 Hz |
| Power consumption | 10.63W at 110V / 10.65W at 220V worst case; 4.58W at 110V / 4.72W at 220V idle | Heat dissipation | 36.33 BTU/hr |
| Energy efficiency | IEEE 802.3az EEE on all copper Gigabit ports, energy detect, cable length detection | Fan modules | Fanless |
| Dimensions (H x W x D) | 1.73 x 10.56 x 7.28 in. (44 x 268 x 185 mm) | Mounting | Rack-mountable; 19-in. bracket RCKMNT-CMPCT-1K= ordered separately |
| Operating temperature | -5°C to 50°C (23°F to 122°F) | Storage temperature | -25°C to 70°C (-13°F to 158°F) |
| Operating humidity | 10% to 90% noncondensing | Storage humidity | 10% to 90% noncondensing |
| MTBF | 2,171,669 hours at 25°C | Safety certifications | UL 62368, CSA 22.2, CE mark |
| EMC certifications | FCC Part 15 (CFR 47) Class A |
