CS-KITPLPTZ4K-K9 Description
The CS-KITPLPTZ4K-K9 is a Cisco Room Kit Plus PTZ 4K integrator bundle for meeting rooms built around one pan-tilt-zoom camera. The Codec Plus provides three gigabit Ethernet ports, two HDMI outputs at 3840 x 2160 and 60 fps and up to 6 Mbps point to point, and the camera adds 240x total zoom. Microphones are optional hardware, and the kit runs on CE Software 9.14.5 or later or Cisco Webex RoomOS.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
CS-KITPLPTZ4K-K9 |
|
Cisco ordering description |
Webex Room Kit Plus PTZ 4K – bundle SKU |
|
Bundle components |
CS-CODEC-PLUS+, CS-CAM-PTZ4K+ and CS-T10-TS+ |
|
Camera zoom |
240x total, combining 20x optical and 12x digital |
|
Video outputs |
Two HDMI outputs up to 3840 x 2160 at 60 fps |
|
Network interfaces |
Three gigabit Ethernet ports splitting LAN, camera pairing and PoE controller pairing |
|
Audio inputs |
Three 4-pin mini-jack microphone inputs plus embedded audio on two HDMI inputs |
|
Bandwidth |
Up to 6 Mbps point to point |
|
Software compatibility |
CE Software 9.14.5 or later, or Cisco Webex RoomOS |
Product Performance
Key Features
The Codec Plus has one gigabit port for the LAN, a second for direct pairing and control of the camera, and a third with PoE dedicated to the Room Navigator. Camera control traffic never shares the room network.
Where no LAN drop reaches the codec, it can join the network over 802.11a/b/g/n/ac on 2.4 GHz and 5 GHz with 2×2 MIMO. Ethernet remains the preferred link for high performance, and the 5725 MHz to 5875 MHz channels work only with 802.11d enabled on the access point.
The PTZ 4K camera combines 20x optical and 12x digital zoom, pans plus or minus 170 degrees, tilts from -20 to +90 degrees and has a 70-degree horizontal field of view.
Two HDMI inputs take 4K at 30 fps and a third takes 1080p60, with EDID and CEC 2.0. Two HDMI outputs run at 3840 x 2160 and 60 fps, so the room needs no external switcher.
HDMI input one supports the Audio Return Channel, which lets a display send its own audio back to the codec over the same cable.
The codec also pairs with the Webex SpeakerTrack 60 camera or the Webex Quad Camera bar where speaker tracking and intelligent framing are wanted in place of a single pan-tilt-zoom head.
Application Scenarios
A meeting room that calls partner organizations outside the corporate firewall reaches them through Cisco Expressway, using H.460.18 and H.460.19 for traversal.
An integrator can mount the camera away from the codec and give it its own control run, because the codec has a dedicated Ethernet port for camera pairing.
In a lecture room with a marked speaking zone, PresenterTrack follows the speaker and holds the framing without an operator once it is enabled in the Codec Plus software and configured for the stage area.
Selection Guide
CS-KITPLPTZ4K-K9 suits integrator rooms built on the Codec Plus, with a codec-to-camera pairing port and bandwidth up to 6 Mbps point to point. Rooms that need up to 20 Mbps and four PoE++ ports for AV over IP peripherals use CS-KIT-EQ-4K-K9, which keeps the same PTZ 4K camera. It runs on CE Software 9.14.5 or later, or RoomOS.
Ordering Checklist
- Software options: Add L-KITPLUS-MS for embedded MultiSite and L-KIT-RM for remote monitoring. Both are ordered separately and are not part of the bundle.
- Camera power and mount: Add PSU-12VDC-40W2=, CS-PTZ4K-BRKT= and AIR-PWRINJ6 as needed. These are separate hardware options.
- Microphones: Add a Cisco Table Microphone or Cisco Ceiling Microphone for the three 4-pin mini-jack inputs. Microphones are optional components and are not in the box.
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | CS-KITPLPTZ4K-K9 | Cisco ordering description | Webex Room Kit Plus PTZ 4K – bundle SKU |
| Network interfaces | One Ethernet RJ-45 at 10/100/1000 for LAN, one Ethernet RJ-45 at 10/100/1000 for direct pairing with the camera for camera control, and one Ethernet RJ-45 at 10/100/1000 with PoE dedicated to direct pairing with the Webex Room Navigator | Other interfaces | One USB A port, USB-B, micro USB and a factory reset pinhole |
| Camera optics | f/2.0 to f/3.8, focusing from 1.0 m to infinity at the wide end, with focus, white balance and brightness selectable as manual or automatic | Bandwidth | Up to 6 Mbps point to point, with H.264 minimums of 768 kbps for 720p30, 1152 kbps for 720p60, 1472 kbps for 1080p30 and 2560 kbps for 1080p60 |
| Bundle components | Webex Codec Plus as CS-CODEC-PLUS+, Webex PTZ 4K Camera as CS-CAM-PTZ4K+ and Webex Room Navigator control unit as CS-T10-TS+ | Firewall traversal | Cisco Expressway technology with H.460.18 and H.460.19 |
| Video standards | H.264 and H.265, with H.263 for TANDBERG MXP interoperability only | Video inputs | One HDMI input up to 1080p60 and two HDMI inputs up to 4K (3840 x 2160) at 30 fps including 1080p60, with EDID and CEC 2.0 |
| Video outputs | Two HDMI outputs up to 3840 x 2160 at 60 fps with CEC 2.0 | Main video | Full HD 1080p60 |
| Presentation channel | UHD 4K 2160p5, including 1080p30 and 720p60 | Audio standards | G.711, G.722, G.722.1, G.729, AAC-LD and Opus |
| Audio features | High-quality 20 kHz audio, prepared for inductive loop on line out, automatic gain control, automatic noise reduction and active lip synchronization | Audio inputs | Three microphone inputs on 4-pin mini-jack, plus embedded audio on two HDMI inputs |
| Audio outputs | One stereo line out mini-jack on the Codec Plus, embedded audio on one HDMI output, and Audio Return Channel support on HDMI input one | PresenterTrack | Intelligent face and upper-body detection and tracking, configured on the Codec Plus system for a defined stage area; once the presenter enters the trigger zone the pan-tilt-zoom camera follows with best overview, framing and zoom level while they move inside the defined stage area |
| Alternative camera pairing | Compatible with the Webex SpeakerTrack 60 Camera and the Webex Quad Camera bar for intelligent framing and speaker tracking | Wireless | Wi-Fi 802.11a/b/g/n/ac on 2.4 GHz and 5 GHz with 2×2 MIMO; 802.11d must be enabled on the access point for operation between 5725 MHz and 5875 MHz, and Ethernet is preferred for high performance |
| Camera resolution | 1920 x 1080 at 60 fps and 3840 x 2160 at 30 fps | Camera zoom | 240x total, from a 20x optical stage and 12x digital zoom |
| Camera pan range | Plus or minus 170 degrees | Camera tilt range | -20 degrees to +90 degrees |
| Camera field of view | 70 degrees horizontal | Camera control | Visca over IP on the LAN port |
| Locking mechanism | Kensington security lock | Security | X.509 digital certificates in DER encoded binary, with DER and Base-64 formats accepted for client and server certificates and key sizes of 1024, 2048 and 4096 supported |
| Optional hardware components | Cisco Table Microphone, Cisco Ceiling Microphone, wall mount for the Codec Plus and assorted cables | Hardware options ordered separately | PSU-12VDC-40W2= camera power supply, CS-PTZ4K-BRKT= camera wall mount bracket and AIR-PWRINJ6 power injector |
| Spare part numbers | CS-CODEC-PLUS= for the Codec Plus and CS-CAM-PTZ4K= for the PTZ 4K Camera | Regulatory approvals | Directive 2011/65/EU, Directive 2002/96/EU, NRTL approval, FCC Listed for radio equipment, radio standards EN 300 328, EN 301 893 and EN 300 440, EMC standards EN 301 489-1 and -17, EN 55032 Class A and EN 55024, safety standards EN 60950-1, EN 62479 and EN 62311, and FCC CFR 47 Part 15B Class A, Part 15C and Part 15E |
| Software compatibility | Cisco Collaboration Endpoint (CE) Software Version 9.14.5 or later, or Cisco Webex RoomOS | Software options ordered separately | L-KIT-RM remote monitoring and L-KITPLUS-MS embedded MultiSite |
| Power supply | 100 to 240 VAC at 50/60 Hz with 12V DC input, averaging 20 W at a 70 W peak | Dimensions | Codec dimensions: 14.1 x 1.7 x 5.6 in (35.9 x 4.3 x 14.3 cm) Camera dimensions: 6.3 in wide by 7.0 in high at maximum tilt by 8.0 in deep (15.8 x 17.7 x 20.0 cm) |
| Operating temperature | 0°C to 35°C (32°F to 95°F) ambient | Storage temperature | -20°C to 60°C (-4°F to 140°F) |
| Operating humidity | 10% to 90% relative humidity | Storage humidity | 10% to 90% relative humidity, noncondensing |
| Component compliance models | TTC7-25 for the Codec Plus, EVI-X200C for the PTZ 4K Camera and TTC5-15 for the Room Navigator; Cisco publishes no compliance model for the bundle SKU |
