CS-KITPRO-PTZ4K-K9 Description
The CS-KITPRO-PTZ4K-K9 is the Cisco Room Kit Pro ordered with the PTZ 4K Camera instead of the fixed Quad Camera, bundling the CS-CODEC-PRO Codec Pro, the Cisco PTZ 4K Camera and the CS-T10-TS-L Room Navigator on a table stand. The camera is motorized, covering a pan range of plus or minus 170 degrees and a tilt range of plus or minus 20 degrees across a 70-degree horizontal field of view, with 12x digital zoom, an f-value of 2.0 to 3.8 and focus from 1.0 m to infinity at the wide setting. Camera control runs Visca over IP through the LAN port while video arrives over HDMI 2.0, and focus, white balance and brightness can be driven manually or automatically for rooms that operate a camera position rather than relying entirely on automatic framing. Behind the camera sits the same integrator-grade Codec Pro found across the Room Kit Pro line: eight 48V phantom powered microphone inputs on Euroblock connectors with individual echo cancelers, up to eight Cisco IP microphones over PoE, three HDMI outputs and dedicated Ethernet ports for camera pairing and controller traffic. The system runs RoomOS 10.x or later with interoperability into Microsoft Teams, Zoom and Google Meet.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
CS-KITPRO-PTZ4K-K9 |
|
Bundle scope |
Codec Pro CS-CODEC-PRO, Cisco PTZ 4K Camera and Room Navigator CS-T10-TS-L |
|
Camera movement |
Motorized pan of plus or minus 170 degrees and tilt of plus or minus 20 degrees |
|
Camera optics |
70-degree horizontal field of view with 12x digital zoom at f/2.0 to f/3.8 |
|
Analog microphone inputs |
Eight 48V phantom powered Euroblock inputs with individual echo cancelers |
|
IP microphone support |
Up to eight Cisco IP microphones over PoE |
|
Video outputs |
Two HDMI up to 3840 x 2160 at 60 fps plus one HDMI up to 3840 x 2160 at 30 fps |
|
Network interface |
One LAN port, two camera pairing ports and two PoE ports for control and peripherals |
|
Software compatibility |
RoomOS 10.x or later with Microsoft Teams, Zoom and Google Meet interoperability |
Product Performance
Key Features
Motorized pan across plus or minus 170 degrees and tilt across plus or minus 20 degrees let the camera address a presenter position, a whiteboard or a side of the room that a fixed lens simply cannot include from its mounting point.
Focus, white balance and brightness can be set manually rather than left automatic, and Visca over IP control through the LAN port lets a control system or operator drive presets during a session that is being recorded or streamed.
Eight phantom powered Euroblock inputs, each with its own echo canceler and noise reduction and each settable to line level, attach ceiling and table microphones directly, so the camera choice does not change the room audio design.
Up to eight Cisco IP microphones over PoE run alongside the analog inputs, letting a refit keep existing wired microphones while adding IP devices on the same codec.
Two Ethernet ports handle direct camera pairing and two PoE ports serve the Room Navigator and IP peripherals, keeping camera control and room device traffic off the corporate LAN ports.
Two HDMI outputs at 3840 x 2160 at 60 fps and one at 30 fps drive a three-display room directly from the codec, avoiding an external distribution amplifier in the rack.
Application Scenarios
Installed where an instructor moves between a screen and a whiteboard, using the motorized camera to hold a framing that a fixed lens at the display line cannot reach.
Deployed in rooms producing recorded or streamed content, where camera presets and manual exposure control matter more than fully automatic group framing.
Placed in deep or L-shaped rooms where the useful camera target sits well off the axis of the display wall, with the 17.1-inch Codec Pro chassis mounted in the AV rack.
Product Comparison
|
Parameter |
CS-KITPRO-PTZ4K-K9 |
CS-KITPRO-C-K9 | |
|---|---|---|---|
|
Cisco ordering description |
Cisco Room Kit Pro with PTZ 4K Camera |
Cisco Room Kit Pro |
Cisco Room Kit Pro with Quad Camera Carbon Black |
|
Camera component |
Cisco PTZ 4K Camera |
CS-QUADCAM Quad Camera in First Light |
CS-QUADCAM2-C Quad Camera in Carbon Black |
|
Camera type |
Motorized pan and tilt |
Fixed four-sensor array with no moving optics |
Fixed four-sensor array with no moving optics |
|
Camera coverage |
70-degree horizontal field of view with pan of plus or minus 170 degrees |
83-degree wide lens plus three 50-degree tele-lenses |
83-degree wide lens plus three 50-degree tele-lenses |
|
Camera zoom |
12x digital zoom |
5x zoom |
5x zoom |
|
Codec component |
CS-CODEC-PRO |
CS-CODEC-PRO |
CS-CODEC-PRO |
|
Analog microphone inputs |
Eight 48V phantom powered Euroblock inputs |
Eight 48V phantom powered Euroblock inputs |
Eight 48V phantom powered Euroblock inputs |
- CS-KITPRO-PTZ4K-K9 is the only bundle in this group whose camera physically moves; its plus or minus 170 degree pan reaches targets outside the display axis, while CS-KITPRO-K9 and CS-KITPRO-C-K9 cover a wider 83-degree native frame from four fixed sensors and never mis-aim.
- The trade is coverage style against mechanism: the PTZ bundle starts from a narrower 70-degree field and relies on movement and 12x digital zoom, whereas the Quad Camera bundles resolve the whole room at once and have no motors to service.
- For deciding which SKU to order, ask whether anything worth framing sits outside a fixed camera’s view; if not, CS-KITPRO-K9 or the Carbon-finish CS-KITPRO-C-K9 delivers the same codec and audio capability without moving optics.
Selection Guide
1. Motorized Reach Justifies The PTZ Bundle
CS-KITPRO-PTZ4K-K9 earns its place when a presenter position, whiteboard or side wall sits outside what a camera at the display line can frame; a room where everyone is seated at a table gains nothing from the motor and gives up the wider 83-degree native coverage of CS-KITPRO-K9.
2. Manual Camera Control For Produced Rooms
Visca over IP control with manual focus, white balance and brightness suits rooms that run presets during recorded sessions; rooms that only ever use automatic framing will not exercise this capability and can stay on a fixed-camera bundle.
3. Camera Power Path Differs From Quad Bundles
The PTZ 4K Camera runs from 12V at 3A or line voltage and is PoE+ compatible under IEEE802.3at, but Cisco specifies FSP040-RHAN3, Phihong POE29U-1AT(PL) or Microsemi PD-9001GR/AT/AC, so an arbitrary PoE+ switch port sits outside the supported set even though the camera itself is 802.3at compatible.
Ordering Checklist
|
Check Item |
What to Confirm |
Why It Matters |
|---|---|---|
|
Camera power source |
Confirm the supply is FSP040-RHAN3, Phihong POE29U-1AT(PL) or Microsemi PD-9001GR/AT/AC when the camera is not on its own adapter. |
Cisco names these specific sources, so an untested PoE+ injector or switch port is outside the supported set. |
|
Camera control path |
Confirm the LAN port carrying Visca over IP is reachable from the control system or codec position. |
Camera control runs over IP rather than a serial cable, so an isolated camera VLAN silently blocks preset control. |
|
HDMI camera run |
Confirm an HDMI 2.0 run is provisioned between the camera position and the codec. |
Video from this camera arrives over HDMI, so a camera position planned for Ethernet alone has no video path. |
|
Euroblock microphone wiring |
Confirm field terminations match the Euroblock connector and the per-channel phantom power setting. |
Each input is individually configurable, and a phantom power mismatch damages or mutes a line-level source. |
|
Display output mix |
Confirm which display takes the 30 fps output when three screens are used. |
Two outputs run at 60 fps and one at 30 fps, so assigning the wrong screen degrades the main video position. |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | CS-KITPRO-PTZ4K-K9 | Bundle scope | CS-CODEC-PRO Codec Pro, Cisco PTZ 4K Camera and CS-T10-TS-L Room Navigator table stand |
| Camera movement | Motorized pan of plus or minus 170 degrees and tilt of plus or minus 20 degrees | Camera field of view | 70 degrees horizontal |
| Camera zoom | 12x digital zoom | Camera aperture | F-value 2.0 to 3.8 |
| Camera focus distance | 1.0 m to infinity at the wide setting | Camera adjustment | Focus, white balance and brightness set manually or automatically |
| Camera control | Visca over IP through the LAN port | Camera video interface | HDMI 2.0 |
| Camera power | 12V at 3A or 100 to 120 and 200 to 240 VAC at 50/60 Hz, PoE+ compatible under IEEE802.3at | Supported camera power supplies | FSP040-RHAN3, Phihong POE29U-1AT(PL) or Microsemi PD-9001GR/AT/AC |
| Video outputs | Two HDMI up to 3840 x 2160 at 60 fps and one HDMI up to 3840 x 2160 at 30 fps, all with CEC 2.0 | Analog audio inputs | Eight 48V phantom powered microphone inputs on Euroblock connectors, each with separate echo cancelers and noise reduction and each settable to balanced line level |
| Digital audio inputs | Three HDMI digital stereo inputs and two USB-A digital stereo inputs | IP audio inputs | Up to eight Cisco IP microphones over PoE, which may require an external PoE switch |
| Third-party audio | Connectivity with third-party audio systems over AES67 | Network interface | One Ethernet RJ-45 10/100/1000 for LAN, two for direct camera pairing and control, and two with PoE for Room Navigator and IP room peripherals |
| Wireless | Wi-Fi 802.11a/b/g/n/ac on 2.4 GHz and 5 GHz at 2×2 MIMO, absent in non-radio versions | Bandwidth | Up to 20 Mbps |
| Call control | Cisco Collaboration Cloud and Webex | Software compatibility | RoomOS 10.x or later with Microsoft Teams over VIMT and WebRTC, Zoom over SIP, Google Meet over WebRTC, plus Microsoft Teams Rooms on Android |
| Codec Pro dimensions | 17.1 x 2.6 x 9.1 in (43.6 x 6.6 x 23.1 cm) at 7.3 lb (3.3 kg) |
