CS-KIT-EQ-4K-K9 Description
The CS-KIT-EQ-4K-K9 is the Cisco Room Kit EQ PTZ 4K, a three-part bundle of the Codec EQ computing engine at compliance model TTC6-15, the Cisco PTZ 4K Camera at EVI-X200C and the table-stand Room Navigator at TTC5-15. It is the long-reach configuration of the Room Kit EQ platform: where the Quad Camera bundle covers a wide room from four fixed sensors reaching 7x total zoom, this one drives a motorised head with 20x optical zoom compounding to 240x total, panning plus or minus 170 degrees and tilting from -20 to +90 degrees, with PresenterTrack following a speaker through digital cropping. The codec underneath is unchanged and is the reason the bundle scales: three HDMI inputs and one USB-C input feed it, three HDMI outputs drive displays at 3840 x 2160 at 60 fps, and four PoE++ Ethernet ports carry up to three 1080p60 video-over-IP streams or a single 4K30 stream while also serving audio over IP for as many as eight Cisco IP microphones. Audio runs 20 kHz full-band with AI adaptive noise removal, and AES67 attachment to third-party systems is available under the AV Integrator License. Main video encodes at 1920 x 1080 at 60 fps with a 3840 x 2160 at 15 fps presentation channel, inside a 20 Mbps ceiling.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
CS-KIT-EQ-4K-K9 |
|
Cisco ordering description |
Cisco Room Kit EQ PTZ 4K with Codec EQ, Cisco PTZ 4K Camera and table-stand Room Navigator |
|
Bundle components |
CS-CODEC-EQ-K9, CS-CAM-PTZ4K and CS-T10-TS-L |
|
Camera zoom |
240x total, combining 20x optical and 12x digital |
|
Camera movement |
Plus or minus 170 degrees pan with -20 to +90 degrees tilt and PresenterTrack |
|
Video outputs |
Three HDMI outputs up to 3840 x 2160 at 60 fps |
|
Ethernet ports |
Four PoE++ at 1 Gb carrying video over IP and audio over IP |
|
IP microphone capacity |
Up to eight Cisco IP microphones |
|
Bandwidth |
Up to 20 Mbps, with 1080p60 from 2560 kbps |
Product Performance
Key Features
The PTZ 4K Camera trades the Quad Camera’s 83-degree wide lens and 7x total zoom for a 20x optical stage reaching 240x through a narrower 70-degree field, framing people who sit too far back for the wider optic to resolve.
Pan across plus or minus 170 degrees and tilt from -20 to +90 degrees serve both manual operation and recalled presets, with PresenterTrack following a speaker by digital cropping inside a configured zone.
The codec’s four 1 Gb PoE++ Ethernet ports support up to three 1920 x 1080 at 60 fps video-over-IP streams or one 3840 x 2160 at 30 fps stream, and the same ports carry audio over IP.
Audio input scales to eight Cisco IP microphones alongside three mini-jack analogue inputs, three HDMI inputs and USB-C and USB-A audio, covering rooms too large for a single array.
Three HDMI outputs at 3840 x 2160 at 60 fps pair with three HDMI inputs plus a USB-C input, so a room can present from several sources across several screens without an external switcher.
Connection to third-party audio systems runs over AES67, and the full Audio API with the Audio Console application unlocks under an AV Integrator option key.
Application Scenarios
Specified where the back row sits well beyond the useful reach of a wide-angle camera and only the 20x optical stage keeps remote participants able to read faces.
Deployed where a speaker works across a defined stage area and PresenterTrack holds the frame without an operator.
Used in large boardrooms cabled with several Cisco IP microphones over the codec’s PoE++ ports rather than relying on a single table array.
Product Comparison
|
Parameter |
CS-KIT-EQ-4K-K9 |
CS-CODEC-EQ-K9 | |
|---|---|---|---|
|
Camera supplied |
Cisco PTZ 4K Camera (CS-CAM-PTZ4K) |
Cisco Quad Camera (CS-QUADCAM2) |
No camera in this order |
|
Camera compliance model |
EVI-X200C |
TTC8-10 |
Not applicable to a codec-only order |
|
Camera field of view |
70 degrees horizontal |
83 degrees horizontal on the wide lens and 50 degrees on three tele-lenses |
Set by whichever camera is ordered separately |
|
Camera total zoom |
240x, from 20x optical and 12x digital |
7x, from 5x native optical zoom with digital enhancement |
Set by whichever camera is ordered separately |
|
Camera movement |
Motorised pan plus or minus 170 degrees and tilt -20 to +90 degrees |
No motorised head; four fixed CMOS sensors with machine-intelligent switching |
Set by whichever camera is ordered separately |
|
Codec supplied |
Cisco Codec EQ (CS-CODEC-EQ-K9) |
Cisco Codec EQ (CS-CODEC-EQ-K9) |
Cisco Codec EQ (CS-CODEC-EQ-K9) |
|
Controller supplied |
Table-stand Room Navigator (CS-T10-TS-L) |
Table-stand Room Navigator (CS-T10-TS-L) |
No controller in this order |
- CS-KIT-EQ-4K-K9 and CS-KIT-EQ-K9 carry the same Cisco Codec EQ and the same table-stand Room Navigator, so every difference between those two part numbers is a camera decision.
- The PTZ 4K Camera in CS-KIT-EQ-4K-K9 reaches 240x total zoom on a motorised head, against 7x and no moving parts on the Quad Camera in CS-KIT-EQ-K9, which is what makes CS-KIT-EQ-4K-K9 the choice where room depth outruns the wider optic.
- CS-CODEC-EQ-K9 is the same codec ordered on its own with neither camera nor controller, which suits rooms that already hold a compatible camera or that will take one specified separately.
Selection Guide
1. The Codec Is Identical, So Decide On Optics
CS-KIT-EQ-4K-K9 and CS-KIT-EQ-K9 both ship the Codec EQ at compliance model TTC6-15 and the same table-stand Room Navigator at TTC5-15, so port counts, stream capacity, audio inputs, bandwidth ceiling and software behaviour are the same in either bundle; only the camera changes. Choose this bundle when room depth outruns the Quad Camera’s 7x reach, and the Quad Camera bundle when seating fits inside its 83-degree wide lens and no moving parts are wanted.
2. Camera Power Is A Separate Decision
The PTZ 4K Camera runs on 12V at 3A or PoE+ under IEEE 802.3at, and Cisco names FSP040-RHAN3, Phihong POE29U-1AT(PL) and Microsemi PD-9001GR/AT/AC as the qualified supplies, with PSU-12VDC-40W2= listed as optional. Wall and ceiling brackets, CS-PTZ4K-BRKT and CS-PTZ4K-CLNGMNT, are separate line items, and ordering CS-CAM-PTZ4K alongside this bundle yields a second camera rather than a spare part for the one supplied.
3. Non-Radio And TAA Variants Change The Codec PID
CS-KIT-EQ-4K-NRK9 substitutes the non-radio Codec EQ for sites that prohibit wireless, and CS-KIT-EQ-4K-K9++ is the TAA configuration; both keep the same PTZ 4K Camera and Room Navigator.
4. Integrator Features Sit Behind Licences
AES67 attachment to third-party audio systems requires the AV Integrator License, and the full Audio API with the Audio Console application unlocks with an AV Integrator option key. Remote monitoring, embedded MultiSite and the AV integrator pack are ordered separately as L-ROOM-RM, L-KITEQ-MS and L-KITEQ-AV.
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | CS-KIT-EQ-4K-K9 | Cisco ordering description | Cisco Room Kit EQ PTZ 4K with Cisco Codec EQ, Cisco PTZ 4K Camera and Cisco Room Navigator for Table (First Light) |
| Bundle components | CS-CODEC-EQ-K9+, CS-CAM-PTZ4K+ and CS-T10-TS-L+ | Compliance model numbers | TTC6-15 for the Codec EQ, EVI-X200C for the PTZ 4K Camera and TTC5-15 for the Room Navigator |
| Camera resolution | 1920 x 1080 at 60 fps and 3840 x 2160 at 30 fps | Camera zoom | 240x total, from a 20x optical stage and 12x digital zoom |
| Camera pan range | Plus or minus 170 degrees, used for manual control and presets | Camera tilt range | -20 degrees to +90 degrees, used for manual control and presets |
| Camera field of view | 70 degrees horizontal | Camera f-value | 2.0 to 3.8, focusing from 1.0 m to infinity at the wide end |
| Camera control | Visca over IP on the LAN port, with video over HDMI 2.0 | Presenter tracking | PresenterTrack with digital cropping |
| Camera power | 12V at 3A from 100 to 120 or 200 to 240 VAC at 50/60 Hz, or PoE+ compatible with IEEE 802.3at, using FSP040-RHAN3, Phihong POE29U-1AT(PL) or Microsemi PD-9001GR/AT/AC | Camera mounting | Wall mount or upside-down ceiling mount, using CS-PTZ4K-BRKT or CS-PTZ4K-CLNGMNT |
| Video inputs | One USB-C up to 3840 x 2160 at 30 fps on USB 3.2 gen1 at up to 5 Gbps, three HDMI up to 3840 x 2160 at 30 fps including 1920 x 1080 at 60 fps with HDCP 1.4 on one input, and four PoE++ 1 Gb Ethernet ports carrying up to three 1920 x 1080 at 60 fps video-over-IP streams or one 3840 x 2160 at 30 fps stream, with EDID and CEC 2.0 | Video outputs | Three HDMI up to 3840 x 2160 at 60 fps with CEC 2.0 and interactive touch screen connectivity via HDMI out and USB-A |
| Main video | 1920 x 1080 at 60 fps | ||
| Presentation channel | 3840 x 2160 at 15 fps | Video standards | H.264, H.265, H.263 and AV1 |
| Bandwidth | Up to 20 Mbps, with minimums of 768 kbps for 720p30, 1152 kbps for 720p60, 1472 kbps for 1080p30 and 2560 kbps for 1080p60 | Firewall traversal | Cisco Expressway technology with H.460.18 and H.460.19 |
| USB passthrough | One USB 3.2 gen1 at up to 5 Gbps providing camera, microphone and speakers over a single USB-C cable with simultaneous content sharing and 3840 x 2160 at 30 fps display extension, requiring Alt-mode DisplayPort on the computer | USB-C power output | 15W maximum |
| Audio standards | G.711, G.722, G.722.1, G.729, AAC-LD and Opus | Audio features | High-quality 20 kHz full-band audio, prepared for inductive loop on line out, acoustic echo cancellation, active lip synchronization, AI-powered adaptive noise removal, automatic gain control, full duplex, Self-Hear and ultrasound technology |
| Audio inputs | Three mini-jack analogue inputs, three HDMI inputs, one USB-C, one USB-A, four PoE++ Ethernet for audio over IP, connectivity with up to eight Cisco IP microphones, and third-party audio systems over AES67 with the AV Integrator License | Audio outputs | One analogue line out, three HDMI audio outputs, one USB-A, one USB-C and four PoE++ Ethernet |
| Codec dimensions | 18.6 x 1.7 x 8 in (47.3 x 4.4 x 20.2 cm) | Codec weight | 5.1 lb (2.33 kg) |
| Operating temperature | Codec EQ and Room Navigator 0 to 40 degrees C (32 to 104 degrees F) | Operating humidity | 10% to 90% relative humidity |
| Storage temperature | -20 to 60 degrees C (-4 to 140 degrees F) | Storage humidity | 10% to 90% relative humidity, noncondensing |
| Locking mechanism | Kensington security lock on the Codec EQ | Software options ordered separately | L-ROOM-RM remote monitoring, L-KITEQ-MS embedded MultiSite and L-KITEQ-AV AV integrator pack |
| Codec spare parts | CS-CODEC-EQ-RCK= rack ears, CS-CODEC-EQ-WMK= wall-mount kit and CS-CODEC-EQ-ANT= antennas | Bundle variants | CS-KIT-EQ-4K-NRK9 non-radio and CS-KIT-EQ-4K-K9++ TAA, both retaining the PTZ 4K Camera and table-stand Room Navigator |
