FPR4245-NGFW-K9 – 140G NGFW – 8x25G SFP28 Data + 2x25G SFP28 Mgmt – 4200 – NGFW Firewall
0/mo Solds
Established Global IT Distributor
With over a decade of industry experience, we are a certified Cisco Partner delivering genuine enterprise networking hardware and trusted services to system integrators, ISPs, and enterprises worldwide.
FPR4245-NGFW-K9 Description
FPR4245-NGFW-K9 is a Cisco Secure Firewall 4245 NGFW chassis in the Cisco Secure Firewall 4200 Series, built as a 1RU Threat Defense firewall appliance for high-throughput security edge and data center inspection roles. The SKU maps to the 4245 next generation firewall orderable identity, provides eight fixed 1/10/25G SFP28 fiber data ports plus two 1/10/25G SFP28 management ports, includes two hot-swappable network module slots, and is sized by Cisco for 140 Gbps FW + AVC + IPS throughput, 60 million concurrent sessions with AVC, and 140 Gbps IPsec VPN throughput.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
FPR4245-NGFW-K9 |
|
Product type |
Cisco Secure Firewall 4245 NGFW appliance |
|
Firewall model |
Secure Firewall 4245 |
|
Security software role |
Cisco Secure Firewall Threat Defense / NGFW |
|
Minimum Threat Defense release |
7.4.0 introduction for Secure Firewall 4215, 4225, and 4245 |
|
Management model |
Firewall Management Center or Cisco Defense Orchestrator |
|
Form factor |
1RU |
|
System memory |
1 TB |
|
Fixed data ports |
8 x 1/10/25-Gbps SFP28 fixed fiber ports |
|
Management ports |
2 x 1/10/25-Gbps SFP28 ports |
|
FW + AVC + IPS throughput |
140 Gbps |
|
IPsec VPN throughput |
140 Gbps |
|
Power input |
Dual 1900 W AC modules; 200 to 240 VAC high-line input for 4245 |
Product Performance
Key Features
The Cisco hardware guide identifies FPR4245-NGFW-K9 as the Secure Firewall 4245 next generation firewall chassis, which separates this order from ASA and NGIPS appliance PIDs.
The 4245 row provides 140 Gbps FW + AVC + IPS throughput, 60 million AVC sessions, and 140 Gbps IPsec VPN throughput for designs that outgrow the 4225 NGFW entry.
Cisco release notes introduced Secure Firewall 4215, 4225, and 4245 with Threat Defense 7.4.0 and state that these devices must be managed with Firewall Management Center instead of device manager.
The chassis starts with eight fixed 1/10/25-Gbps SFP28 fiber data ports plus two SFP28 management ports, which defines the base optics list before add-on modules are selected.
Two hot-swappable network module slots allow Cisco-listed 1G, 10G, 25G, 40G, 100G, 200G, 400G, and hardware-bypass module choices when the release plan supports them.
The 4245 hardware specification uses dual 1900 W AC power modules and high-line 200 to 240 VAC input, making rack power verification part of the purchase approval.
Application Scenarios
Select FPR4245-NGFW-K9 when the design calls for the Secure Firewall 4245 NGFW appliance and the approved sizing worksheet needs the 140 Gbps Threat Defense row.
Use this SKU when operations are standardized on Firewall Management Center and the firewall plan does not call for an ASA orderable appliance.
Deploy this model when the base appliance must begin with eight 25G-capable SFP28 data ports and still reserve two module bays for approved high-speed or fail-to-wire interfaces.
Product Comparison
|
Parameter |
FPR4245-NGFW-K9 | ||
|---|---|---|---|
|
Cisco PID description |
Secure Firewall 4245 next generation firewall chassis 1RU |
Secure Firewall 4225 next generation firewall chassis 1RU |
Secure Firewall 4245 ASA chassis 1RU |
|
Firewall model |
Secure Firewall 4245 |
Secure Firewall 4225 |
Secure Firewall 4245 |
|
Security software role |
Threat Defense / NGFW |
Threat Defense / NGFW |
Cisco Secure ASA |
|
Form factor |
1RU |
1RU |
1RU |
|
System memory |
1 TB |
512 GB |
1 TB |
|
Fixed data ports |
8 x 1/10/25-Gbps SFP28 |
8 x 1/10/25-Gbps SFP28 |
8 x 1/10/25-Gbps SFP28 |
|
Management ports |
2 x 1/10/25-Gbps SFP28 |
2 x 1/10/25-Gbps SFP28 |
2 x 1/10/25-Gbps SFP28 |
|
Network module slots |
2 |
2 |
2 |
|
Storage |
Two 1.8 TB SSDs in RAID1 |
Two 1.8 TB SSDs in RAID1 |
Two 1.8 TB SSDs |
|
FW + AVC + IPS throughput |
140 Gbps |
80 Gbps |
Not an ASA table metric |
|
NGIPS throughput |
140 Gbps |
80 Gbps |
Not an ASA table metric |
|
Maximum concurrent sessions with AVC |
60 million |
30 million |
Not an ASA table metric |
|
New connections per second with AVC |
800K |
600K |
Not an ASA table metric |
|
IPsec VPN throughput |
140 Gbps |
80 Gbps |
70 Gbps under ASA table |
|
Maximum VPN peers |
30000 |
25000 |
30000 |
|
Management model |
Firewall Management Center or Cisco Defense Orchestrator |
Firewall Management Center or Cisco Defense Orchestrator |
Cisco Security Manager, Cisco Defense Orchestrator, or ASDM |
|
AC input voltage |
200 to 240 VAC high line |
100 to 120 VAC or 200 to 240 VAC |
200 to 240 VAC high line |
|
AC maximum input power |
1380 W |
870 W |
1380 W |
- In a FPR4245-NGFW-K9 vs FPR4225-NGFW-K9 comparison, both use the 1RU 4200 Series layout, but FPR4245-NGFW-K9 raises memory to 1 TB, FW + AVC + IPS throughput to 140 Gbps, AVC sessions to 60 million, and IPsec VPN throughput to 140 Gbps.
- The FPR4245-NGFW-K9 difference from FPR4245-ASA-K9 is the software role and performance table: FPR4245-NGFW-K9 follows the Threat Defense / NGFW rows, while FPR4245-ASA-K9 follows ASA rows for firewall and VPN metrics.
- For buyers comparing FPR4245-NGFW-K9 vs FPR4225-NGFW-K9, which model to choose should follow the required 4200 Series capacity tier and the high-line AC power plan.
- In a FPR4245-NGFW-K9 vs FPR4245-ASA-K9 comparison, keep the same 4245 hardware tier only when the approved operating model changes from Threat Defense to Cisco Secure ASA.
Selection Guide
1. Lock the Threat Defense orderable role
Choose FPR4245-NGFW-K9 when the bill of materials names a Secure Firewall 4245 NGFW appliance for Cisco Secure Firewall Threat Defense.
2. Use the 4245 NGFW row for capacity approval
Select this SKU when the design needs 140 Gbps FW + AVC + IPS throughput, 60 million AVC sessions, 800K new connections per second with AVC, or 140 Gbps IPsec VPN throughput.
3. Keep ASA substitution out of the quote
Use FPR4245-ASA-K9 only when the firewall design explicitly calls for Cisco Secure ASA management and ASA performance metrics instead of Threat Defense.
4. Verify power and interface choices together
Confirm 200 to 240 VAC high-line input, supported optics, selected network modules, Firewall Management Center planning, and subscription licensing before quote approval.
Ordering Checklist
|
Review Area |
Required Decision |
Source-Based Risk |
|---|---|---|
|
Exact NGFW PID |
Confirm FPR4245-NGFW-K9 rather than FPR4245-ASA-K9 or FPR4245-NGIPS-K9 |
Cisco separates 4245 orderable identities by security software role |
|
Threat Defense release |
Confirm the deployment is planned for the Secure Firewall 4200 Threat Defense release path |
Cisco introduced Secure Firewall 4215, 4225, and 4245 with Threat Defense 7.4.0 |
|
Management method |
Confirm Firewall Management Center or approved centralized management |
Cisco states 4200 Threat Defense devices must be managed with Firewall Management Center and do not support device manager |
|
Fixed-port optics |
Match SFP, SFP+, SFP28, DAC, or AOC media to supported Cisco transceiver tables |
Fixed data and management ports are 1/10/25-Gbps SFP28 interfaces |
|
Network modules |
Select only Cisco-listed 4200 Series network modules and check release support for high-speed options |
Module selection affects interface speed, optics, and hardware-bypass behavior |
|
Power input |
Confirm 200 to 240 VAC high-line rack power and country-specific cords |
The 4245 hardware row lists high-line AC input and 1380 W system input power |
Optional Add-ons
|
Model |
Description |
|---|---|
|
FPR4K-XNM-8X10G |
8-port 1/10-Gbps SFP+ network module |
|
FPR4K-XNM-8X25G |
8-port 1/10/25-Gbps SFP+ network module |
|
FPR4K-XNM-4X40G |
4-port 40-Gbps QSFP/QSFP+ network module |
|
FPR4K-XNM-2X100G |
2-port 100-Gbps QSFP56/QSFP28/QSFP network module |
|
FPR4K-XNM-4X200G |
4-port 40/100/200-Gbps QSFP28/QSFP network module |
|
FPR4K-XNM-2X400G |
2-port 200/400-Gbps QSFP-DD network module |
|
FPR4K-XNM-8X1GF |
8-port copper 1-Gbps 1000Base-T hardware bypass network module |
|
FPR4K-XNM-6X1SXF |
6-port 1-Gbps SFP SX multimode hardware bypass network module |
|
FPR4K-XNM-6X10SRF |
6-port 10-Gbps SFP SR multimode hardware bypass network module |
|
FPR4K-XNM-6X10LRF |
6-port 10-Gbps SFP LR single-mode hardware bypass network module |
|
FPR4K-XNM-6X25SRF |
6-port 25-Gbps SFP SR multimode hardware bypass network module |
|
FPR4K-XNM-6X25LRF |
6-port 25-Gbps SFP LR single-mode hardware bypass network module |
|
FPR4200-PWR-AC |
Cisco Secure Firewall 4200 Series 1900 W AC power supply module |
|
FPR4200-SSD1800 |
Cisco Secure Firewall 4200 Series 1.8 TB SSD |
|
FPR4200-FAN |
Dual fan module |
|
FPR4200-SLD-RAILS |
Slide rail kit |
|
FPR4200-CBL-MGMT |
Cable management brackets |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | FPR4245-NGFW-K9 | Product Type | Cisco Secure Firewall 4245 NGFW appliance |
| Firewall Model | Secure Firewall 4245 | Security Software Role | Cisco Secure Firewall Threat Defense / NGFW |
| Minimum Threat Defense Release | 7.4.0 introduction for Secure Firewall 4215, 4225, and 4245 | Management Model | Firewall Management Center or Cisco Defense Orchestrator |
| Device Manager Support | Not supported for Secure Firewall 4200 Threat Defense | Form Factor | 1RU |
| Rack Mount | 4-post EIA-310-D rack with slide rails | Airflow | Front to rear; I/O side to non-I/O side |
| System Memory | 1 TB | Storage | Two 1.8 TB NVMe SSD slots; ships with two 1.8 TB SSDs in RAID1 |
| Fixed Data Ports | 8 x 1/10/25-Gbps SFP28 fixed fiber ports | Fixed Port Names | Ethernet 1/1 through Ethernet 1/8 |
| Management Ports | 2 x 1/10/25-Gbps SFP28 ports | Threat Defense Management Port Names | Management 0 and Management 1 |
| Network Module Slots | 2 hot-swappable slots | Supported Module Speeds | 1G 10G 25G 40G 100G 200G and 400G module options |
| Console Port | 1 x RJ-45 serial port | FW + AVC Throughput | 140 Gbps |
| FW + AVC + IPS Throughput | 140 Gbps | NGIPS Throughput | 140 Gbps |
| Maximum Concurrent Sessions with AVC | 60 million | New Connections Per Second with AVC | 800K |
| TLS Hardware Decryption Throughput | 45 Gbps | IPsec VPN Throughput | 140 Gbps |
| Maximum VPN Peers | 30000 | Multi-Instance Count | 15 |
| High Availability | Active/active with clustering and active/standby | Clustering | Up to 16 chassis |
| Application Visibility and Control | Standard; supports more than 4000 applications | Cisco Secure IPS | Available |
| Cisco Malware Defense | Available | URL Filtering Categories | More than 120 |
| URL Filtering Database | More than 280 million categorized URLs | Power Supplies | Dual 1900 W AC power supply modules |
| Redundancy | 1+1 | AC Input Voltage | 200 to 240 VAC high line |
| AC Frequency | 50/60 Hz nominal | System Input Power | 1380 W for 4245 |
| AC Efficiency | More than 90 percent Platinum | Fan Modules | Three dual fan modules; hot-swappable |
| Chassis Weight | 46 lb (20.8 kg) with 2 power supplies, 2 network modules, and 3 fan modules | Chassis Dimensions | 1.73 x 16.89 x 32.0 in. (4.39 x 42.9 x 81.28 cm) |
| Operating Temperature | 32 to 104F (0 to 35C) at sea level | Operating Humidity | 5 to 90% noncondensing |
| Operating Altitude | 0 to 10000 ft (0 to 3048 m) | Sound Pressure | <=78 dBA typical; <=84 dBA maximum |
| Sound Power | <=87 dB typical; <=92 dB maximum |
