IE-1000-8P2S-LM – 8x100M PoE+ Ports – 2x1G SFP Uplinks – 180W PoE Budget
Cisco IE-1000-8P2S-LM Compatible Accessories, Modules & Spare Parts
Find compatible network modules, power supplies, fans, optics, cables and spare parts for the Cisco IE-1000-8P2S-LM. These accessories support fiber connectivity, hardware replacement, spare inventory and network maintenance projects.-
GLC-LH-SMD
1000BASE-LX/LH SFP - 10km SMF / 550m MMF - DOMOriginal price was: $2,658.11.$95.80Current price is: $95.80. Condition: New Factory Sealed -
GLC-TE
1000BASE-T SFP - RJ-45 Cat5 Copper - 100m ReachOriginal price was: $1,202.16.$70.00Current price is: $70.00. Condition: New Factory Sealed -
GLC-SX-MMD
1000BASE-SX SFP - MMF 850nm - DOMOriginal price was: $1,335.73.$57.00Current price is: $57.00. Condition: New Factory Sealed -
GLC-EX-SMD
1000BASE-EX SFP - 40km SMF - DOMOriginal price was: $5,329.57.$205.00Current price is: $205.00. Condition: New Factory Sealed
-
PWR-IE240W-PCAC-L
240W AC PSU - 54V PoE Output - Hardwired DIN-RailOriginal price was: $4,407.90.$814.00Current price is: $814.00. Condition: New Factory Sealed -
PWR-IE480W-PCAC-L
480W AC PSU - 54V PoE Output - DIN-RailOriginal price was: $6,665.30.$1,388.49Current price is: $1,388.49. Condition: New Factory Sealed
Established Global IT Distributor
With over a decade of industry experience, we are a certified Cisco Partner delivering genuine enterprise networking hardware and trusted services to system integrators, ISPs, and enterprises worldwide.
IE-1000-8P2S-LM Description
The IE-1000-8P2S-LM is the ten-port PoE model at the top of the Cisco Industrial Ethernet 1000 Series, combining 8 Fast Ethernet PoE/PoE+ copper downlinks under a 180W budget with 2 Gigabit SFP uplinks that carry fiber runs up to 50 miles (80 km). It belongs to Cisco's lightly managed industrial line, so a web device manager with SNMP v2/v3 and syslog handles port power, VLANs, IGMP snooping, and Sticky-MAC port security without any command-line work, and Plug-and-Play brings a replacement unit back with its configuration applied automatically. Powered from a 48-54V feed with redundant voltage inputs, equipped with a top-panel alarm output, and rated from -40°C to +70°C in a vented enclosure with hazardous-location compliance behind a cabinet, the switch concentrates the camera, wireless access point, and sensor drops of an outdoor cabinet or dense automation zone into a single DIN rail device.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
IE-1000-8P2S-LM |
|
Downlink ports |
8x 10/100M copper, PoE/PoE+ (IEEE 802.3af/at) |
|
Uplink ports |
2x 1G SFP |
|
PoE power budget |
180W |
|
Maximum fiber uplink reach |
80 km (50 miles) |
|
Management model |
Web device manager GUI, SNMP v2/v3, syslog |
|
Input voltage |
48-54V, redundant voltage feeds |
|
Power consumption |
10.6W without PoE; 134.4-205.2W with PoE load |
|
Switching bandwidth (series maximum) |
5.6 Gbps |
|
Operating temperature |
-40°C to +70°C (vented enclosure) |
|
Memory |
128 MB DRAM, 160 MB onboard flash |
|
Mounting |
DIN rail |
Product Performance
Key Features
The 180W budget spans all 8 PoE/PoE+ downlinks, so a full cabinet of cameras, access points, and sensors lands on one switch instead of two smaller PoE units and their extra supply.
Ten total ports make this the largest IE 1000, giving lightly managed installations a per-cabinet ceiling before the design has to step up to a fully managed industrial family.
Both SFP slots take industrial optics for runs up to 80 km, and the second slot can hold a redundant or corridor-facing path where surveillance and ITS backbones daisy-chain between cabinets.
The top-panel alarm output (1.0A at 24VDC, 0.5A at 48VDC) surfaces switch faults on the cabinet’s existing dry-contact monitoring, keeping remote sites observable without SNMP polling infrastructure.
Per-port PoE, VLANs, and access control run from the web device manager, so the operations team that services traffic cabinets and pole enclosures can run the switch without network engineers on site.
A -40°C vented-enclosure floor plus Class 1 Div 2 and ATEX/IECEx Zone 2 compliance (with cabinet enclosure) covers unheated northern deployments and classified process areas with one PID.
Application Scenarios
Deployed at camera aggregation points where up to eight PTZ and fixed IP cameras draw PoE+ from one cabinet, with dual fiber uplinks closing a ring back to the video head end.
Installed along ITS corridors as the per-intersection node, powering detection and monitoring devices while the two SFP uplinks chain intersection cabinets over single-mode fiber.
Positioned in warehouse and plant-perimeter enclosures where wireless access points, badge readers, and sensors cluster past the four-drop mark and local power outlets are scarce.
Product Comparison
|
Parameter |
IE-1000-8P2S-LM | ||
|---|---|---|---|
|
Total ports |
10 |
6 |
8 |
|
Downlink ports |
8x 10/100M PoE/PoE+ |
4x 10/100M PoE/PoE+ |
6x 10/100M copper |
|
Uplinks |
2x 1G SFP |
2x 1G SFP |
2x 10/100M copper |
|
PoE power budget |
180W |
120W |
Not a PoE switch (data only) |
|
Input voltage |
48-54V |
48-54V |
12-24V |
|
Power consumption with PoE load |
134.4-205.2W |
72-140.4W |
5.3W, no PoE |
|
Operating floor (vented) |
-40°C |
-40°C |
-20°C |
|
Weight |
1.85 lb (0.84 kg) |
1.70 lb (0.77 kg) |
1.25 lb (0.57 kg) |
- The IE-1000-8P2S-LM against IE-1000-4P2S-LM is a pure scale call inside the same PoE design: identical fiber uplinks, input class, and -40°C floor, with the order deciding between 8 drops under 180W and 4 drops under 120W, so the powered-device count and summed wattage at the cabinet pick the PID.
- IE-1000-6T2T-LM sits nearby on total ports but in a different class: it is a 12-24V data-only copper unit with a -20°C floor and no SFP slots, which serves tempered panels full of locally powered devices but cannot take over any camera, AP, or fiber-backhaul role from the IE-1000-8P2S-LM.
- For deciding which SKU to order, count powered drops first: five or more PoE endpoints, or a combined draw beyond 120W, lands on IE-1000-8P2S-LM; four or fewer fits IE-1000-4P2S-LM; and only an all-data-only cabinet should drop to IE-1000-6T2T-LM and its lighter supply class.
Selection Guide
1. Past Four Drops Or 120W
When the cabinet’s powered-device list reaches five endpoints, or the summed PoE draw of fewer devices pushes beyond 120W, this model’s 8 drops and 180W budget absorb the load; below both thresholds, IE-1000-4P2S-LM does the same job in a narrower power envelope.
2. Budget Headroom Planning
The 180W budget averages just over 22W per port across all eight drops, so a full cabinet of 802.3at class-4 endpoints cannot all draw maximum power at once; keep the summed device classes inside 180W or split heavy loads across cabinets.
3. Where Data-Only Still Wins
An eight-port class cabinet whose devices are all locally powered can run on IE-1000-6T2T-LM from a 12-24V rail at a fraction of the consumption, provided the -20°C floor and copper-only uplinks match the site.
4. Supply Class Locks The Budget
Delivering the full 180W requires an external supply sized for switch plus PoE, which points at the 240W PoE-capable unit (or 480W with expansion headroom); the 65W and 170W supplies cap usable PoE below the model’s budget.
PoE Power Planning
|
Planning Item |
Value or Check |
|---|---|
|
PoE standards |
IEEE 802.3af (PoE) and 802.3at (PoE+) on all 8 downlinks |
|
PoE power budget |
180W shared across powered downlinks |
|
Powered-device count |
Up to 8 PDs; sum the per-device class draw against the 180W budget |
|
Input voltage for PoE |
48-54V feed required |
|
Total draw with PoE load |
134.4-205.2W measured switch consumption range |
|
External supply sizing |
Switch consumption plus PoE budget must stay within supply wattage; the 240W PoE-capable supply carries the full 180W budget |
Ordering Checklist
|
Check Item |
What to Confirm |
Why It Matters |
|---|---|---|
|
Full-budget supply |
Order PWR-IE240W-PCAC-L= (or PWR-IE480W-PCAC-L=) when the design uses the whole 180W budget; smaller PoE supplies cap the usable budget. |
An undersized supply drops or refuses PoE loads during peak draw, which reads as random camera reboots in the field. |
|
Classified-area parts |
For Class 1 Div 2 sites, note that the 240W/480W -L supplies carry no hazardous-location certification; use certified supplies and the required cabinet enclosure. |
Mixing an -L supply into a classified cabinet fails site acceptance even though the switch itself is compliant. |
|
Optic temperature grade |
Keep uplink optics on -RGD industrial parts in unheated or hot cabinets; COM/EXT-grade SFPs derate the switch’s operating range. |
The -40°C envelope that justified the model quietly narrows with a commercial optic installed. |
|
Fiber plant match |
Verify SFP reach and mode per run (SX 220-550 m MMF, LX 10 km, ZX up to 70 km, BX single-strand 10-80 km). |
A reach or mode mismatch at the far end only appears at turn-up, after cabinets are sealed. |
|
Enclosure thermal tier |
Match the enclosure tiers: -40°C to +70°C vented, +60°C sealed, -34°C to +75°C with forced airflow. |
Sealed cabinets in summer heat exceed the derated ceiling despite the winter-driven purchase. |
|
Rack adaptation |
Add STK-RACK-DINRAIL= only for 19-inch rack installs. |
The native mount is DIN rail; rack builds stall without the kit. |
Optional Add-ons
|
Model |
Description |
|---|---|
|
240W PoE-capable DIN rail power supply, AC input, IP20 light-duty variant | |
|
480W PoE-capable DIN rail power supply, AC input, IP20 light-duty variant | |
|
170W PoE-capable DIN rail power supply, AC 100-240V or DC 125-250V input | |
|
Industrial-grade 1000BASE-SX SFP, multimode fiber, 220-550 m | |
|
GLC-LX-SM-RGD= |
Industrial-grade 1000BASE-LX/LH SFP, 550 m multimode / 10 km single-mode |
|
GLC-ZX-SM-RGD= |
Industrial-grade 1000BASE-ZX SFP, single-mode fiber, up to 70 km |
|
STK-RACK-DINRAIL= |
19-inch rack mount kit for DIN rail Industrial Ethernet switches |
Cisco IE 1000 Switch Rear Panel
The rear panel of the switch has a latch for installation on a DIN rail. See photo. The latch is spring-loaded to move down to position the switch over a DIN rail and return to the original position to secure the switch to a DIN rail.
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | IE-1000-8P2S-LM | Product type | Lightly managed industrial PoE switch, IE 1000 Series |
| Downlink ports | 8x 10/100M copper, PoE/PoE+ (802.3af/at) | Uplink ports | 2x 1G SFP, fiber reach up to 80 km |
| PoE power budget | 180W | Supported SFP types | GLC-SX-MM-RGD, GLC-LX-SM-RGD, GLC-ZX-SM-RGD, GLC-T/GLC-TE copper, BX single-strand series |
| Connectors | RJ-45, 4-pair Category 5 UTP; SFP (LC fiber) | Management | Web device manager GUI, SNMP v2/v3, syslog |
| Provisioning | Plug-and-Play, zero-touch IP discovery, DHCP; 50-second cold boot | Layer 2 features | VLANs, MSTP, STP PortFast, LLDP, CDP aware, IGMP snooping and querier, EtherChannel (LACP), SPAN, storm control, Smartport macros |
| Security | 802.1x single-host with MAB, Sticky-MAC port security, DHCP snooping, BPDU guard, TACACS+/RADIUS | Industrial protocol | EtherNet/IP (CIP) with EDS support |
| Forwarding bandwidth (series maximum) | 2.8 Gbps | Switching bandwidth (series maximum) | 5.6 Gbps |
| Memory | 128 MB DDR2 DRAM, 160 MB onboard flash | MTBF (series) | 374,052 hours |
| Input voltage | 48-54V, redundant voltage feeds | Power consumption | 10.6W without PoE; 134.4-205.2W with PoE load |
| Alarm output | Top-panel connector, 1.0A at 24VDC or 0.5A at 48VDC | Operating altitude | Up to 13,800 ft |
| Operating temperature | -40°C to +70°C vented; -40°C to +60°C sealed; -34°C to +75°C with forced airflow | Storage environment | -40°C to +85°C, up to 15,000 ft; humidity 5% to 95% non-condensing |
| Dimensions (H x W x D) | 5.0 x 1.8 x 5.3 in (127 x 45.7 x 134 mm), including DIN rail | Weight | 1.85 lb (0.84 kg) |
| Safety | UL/CSA 60950-1, EN 60950-1, IEC 60950-1 CB, UL/CSA/IEC/EN 61010-2-201, CE | Hazardous locations | ANSI/ISA 12.12.01 Class 1 Div 2 A-D; ATEX and IECEx Class 1 Zone 2 (cabinet enclosure required) |
| EMC and industry | FCC Part 15 Class A, EN 55022 Class A, EN 61000-4 series immunity, EN 61000-6-1/-2/-4, EN 61131-2, EN 61326-1, NEMA TS-2, Marine TAC, IP30 | Environmental compliance | RoHS, China RoHS, EU WEEE |
| Mounting | DIN rail; 19-inch rack via STK-RACK-DINRAIL= | Warranty | 5-year limited hardware warranty (all IE-1000 PIDs and listed IE power supplies) |
Get More Information
Need pricing, stock, or shipping details for the IE-1000-8P2S-LM ? Layer23-Switch can help you check current availability, lead time, and delivery options for this. Send us the part number, quantity, and destination country via live chat or email sales@layer23-switch.com for a fast quotation.
Quality Certifications
Customer Reviews
Questions & Answers
-
Why do IE-1000-8P2S-LM users ask about GUI versus CLI?
-
What PoE capacity does IE-1000-8P2S-LM have?
-
When does IE-1000-8P2S-LM justify the larger PoE model?
-
What PoE recovery issue appears on IE-1000-8P2S-LM sites?
-
Can IE-1000-8P2S-LM handle heavy PoE loads on all ports?
-
What uplink planning matters on IE-1000-8P2S-LM?
-
What management limitation matters for IE-1000-8P2S-LM?
-
What purchase boundary keeps IE-1000-8P2S-LM from overlapping IE2000 pages?
