IE-4000-8GS4G-E Description
The IE-4000-8GS4G-E is a Cisco Industrial Ethernet 4000 Series switch for DIN-rail cabinets and field networks that need Gigabit fiber access. The switch has eight Gigabit Ethernet SFP downlinks, four Gigabit Ethernet combo uplinks, a redundant 9.6 to 60 VDC input and 42 W power consumption, and it operates from -40 to 70 C. It runs LAN Base and has no PoE ports, and the IP Services features need the L-IE4000-RTU= software upgrade.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
IE-4000-8GS4G-E |
|
Product type |
Industrial Ethernet switch |
|
Default software license |
LAN Base |
|
Total ports |
12 |
|
SFP fiber downlink ports |
8 x GE SFP |
|
GE combo uplink ports |
4 x GE combo uplink ports |
|
PoE ports |
No PoE ports listed for this PID |
|
DC input range |
Redundant DC input, nominal 9.6 to 60 VDC |
|
Maximum input current |
5.0 A |
|
Power consumption |
42 W, excluding powered-device load |
|
Memory and storage |
1 GB DRAM, 128 MB onboard flash, 1 GB removable SD card included |
|
Dimensions and weight |
6.12 x 6.12 x 5.09 in.; 6.35 lb / 2.88 kg |
Product Performance
Key Features
The downlinks are SFP cages that take LC fiber modules. Link speed and reach are set by the module installed in each cage.
Each uplink has a copper and a fiber physical interface, with only one active at a time. Media can therefore follow the cabling at each site.
LAN Base is the default feature set. The L-IE4000-RTU= license moves the switch to IP Services Layer 3 features without a hardware change.
The nominal 9.6 to 60 VDC range covers the common 12, 24 and 48 VDC cabinet supplies. Maximum input current is 5.0 A and power consumption is 42 W, excluding powered-device load.
CIP EtherNet/IP, PROFINET v2, IEEE 1588 PTP v2 and MODBUS TCP/IP are in the LAN Base feature table. The same switch can therefore carry control traffic from different automation vendors.
A 1 GB removable SD card is included, and SwapDrive uses it for zero-config replacement of a failed switch. Recovery then needs no networking expertise on site.
Application Scenarios
In a substation control building, the switch links protection and metering devices over LC fiber on its SFP downlinks and returns the traffic to the station network through the combo uplinks.
A roadside cabinet on a highway or tunnel run can use the combo uplinks as copper to a local device or as fiber toward the next cabinet, with the redundant DC input feeding the switch from two sources.
On a production floor with long runs between machine areas, the switch collects fiber links from remote cells and passes them upstream on one of its four Gigabit uplinks.
Product Comparison
|
Parameter |
IE-4000-8GS4G-E |
IE-4000-8S4G-E | |
|---|---|---|---|
|
Downlink ports |
8 x GE SFP |
8 x GE RJ45 copper |
8 x FE SFP |
|
Combo uplink ports |
4 x GE |
4 x GE |
4 x GE |
|
PoE ports |
0 |
0 |
0 |
|
Default PoE budget |
0 W |
0 W |
0 W |
|
Software license |
LAN Base |
LAN Base |
LAN Base |
|
Input voltage range |
Nominal 9.6 to 60 VDC |
Nominal 9.6 to 60 VDC |
Nominal 9.6 to 60 VDC |
|
Maximum input current |
5.0 A |
3.7 A |
5.0 A |
|
Power consumption |
42 W |
35 W |
42 W |
IE-4000-8GS4G-E carries eight Gigabit SFP fiber downlinks, while IE-4000-8GT4G-E has eight Gigabit copper downlinks, so cabinets that cable to RJ45 devices move to IE-4000-8GT4G-E. The copper model also draws less, at 35 W and 3.7 A maximum input current against 42 W and 5.0 A. IE-4000-8S4G-E keeps the SFP fiber layout but its eight downlinks are Fast Ethernet, so it suits only links that never need Gigabit speed, and IE-4000-8GS4G-E is the choice when fiber downlinks must run at 1 Gbps. None of the three lists PoE ports, so powered endpoints need a different IE 4000 model.
Ordering Checklist
- SD card: Add SD-IE-1GB= only if a spare card is wanted. A 1-GB removable SD card is included with IE 4000 switches and SD-IE-1GB= is the spare PID, so adding it duplicates the card already in the box.
- DIN rail kit: Add STK-RACK-DINRAIL=, the 19 in. DIN rail mount kit. It is a separate accessory PID, not part of the switch order.
- MRP ring role: Add LIC-MRP-Manager= for the ring manager and LIC-MRP-Client= for each client switch. MRP ring roles are separate license PIDs and are not added by the switch order.
Optional Add-ons
|
Model |
Description |
|---|---|
|
50 W AC or high-voltage DC DIN-rail power supply listed for Cisco IE 4000 Series switches | |
|
50 W AC DIN-rail power supply option listed for Cisco IE 4000 Series switches | |
|
L-IE4000-RTU= |
Electronic software license upgrade from LAN Base Layer 2 to IP Services Layer 3 features |
|
IE-LICENSE-SPARE |
Spare license for software upgrade from Layer 2 to Layer 3 features or MRP protocols |
|
LIC-MRP-Manager= |
MRP ring manager license |
|
LIC-MRP-Client= |
MRP ring client license |
|
STK-RACK-DINRAIL= |
19 in. DIN-rail mount kit |
|
IE 1 GB SD memory card spare | |
|
GLC-SX-MM |
Cisco-listed 1000BASE-SX multimode SFP option for IE4000 fiber ports |
|
GLC-LH-SM |
Cisco-listed 1000BASE-LX/LH SFP option for IE4000 fiber ports |
Front Panel Overview
The illustrations in this section provide an overview of the variety of components available on the various switch models in this product family. Not all models are illustrated.|
1 |
SFP module slots (uplink ports) |
6 |
Power connector DC-B |
|
2 |
10/100/1000 Ethernet ports (downlink ports) |
7 |
Power connector DC-A |
|
3 |
Flash memory card slot |
8 |
RJ-45 console port |
|
4 |
Alarm connector |
9 |
USB mini-Type B (console) port1 |
|
5 |
Protective ground connection |
10 |
Dual-purpose ports (uplink ports) |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | IE-4000-8GS4G-E | Product type | Industrial Ethernet switch |
| Default software license | LAN Base | License upgrade path | L-IE4000-RTU= for LAN Base Layer 2 to IP Services Layer 3 features |
| Total ports | 12 | GE combo uplink ports | 4 |
| SFP fiber downlink ports | 8 x GE SFP | PoE ports | No PoE ports listed for this PID |
| Combo port media rule | One copper and one fiber physical interface, with only one active at a time | SFP connector planning | Fiber-optic SFP modules use LC connectors |
| Power input design | Redundant DC input | Input voltage range | Nominal 9.6 to 60 VDC |
| Maximum input current | 5.0 A | Power consumption | 42 W, excluding powered-device load |
| DRAM | 1 GB | Flash | 128 MB |
| Removable storage | 1 GB removable SD card included | Console port | Mini-USB connector and RJ45 connector |
| Alarm I/O | 2 alarm inputs and 1 alarm output relay | Alarm output rating | 1.0 A at 24 VDC or 0.5 A at 48 VDC |
| Forwarding rate | Line rate for all ports and all packet sizes | Egress queues | 4 |
| MAC addresses | 16000 | IGMP multicast groups | 1000 |
| VLANs | 1000 | IPv4 MAC security ACEs | 1000 with default TCAM template |
| NAT translation | 128 unique subnet NAT translation entries | Industrial protocols | CIP EtherNet/IP, PROFINET v2, IEEE 1588 PTP v2, and MODBUS TCP/IP |
| Dimensions | 6.12 x 6.12 x 5.09 in. (155.4 x 155.4 x 129.2 mm) | Weight | 2.88 kg (6.35 lb) |
| Mounting | DIN rail | Operating temperature | -40 to 70 C |
| Management options | Cisco Network Assistant, Device Manager, and Cisco IOS CLI | Software support example | Cisco IOS Release 15.2(2)EA2 runs on all Cisco IE 4000 switches |
