C1300-48P-4G Description
The C1300-48P-4G is a Cisco Catalyst 1300 Series managed Layer 3 PoE+ access switch for branch and small-business closets that power phones, access points and cameras. The switch shares a 375W PoE budget across 48 Gigabit PoE+ ports, uplinks through four 1G SFP slots and switches 104 Gbps on a single fan rated 37.3 dBA at 25°C. Routing between VLANs uses RIP v2 and policy-based routing, with OSPF reserved for the Catalyst 1300X line, and no Catalyst 1300 stacking family includes the model.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
C1300-48P-4G |
|
Downlink ports |
48 x 10/100/1000 RJ-45 PoE+ ports |
|
Uplink ports |
4 x 1G SFP |
|
PoE power budget |
375W |
|
Number of ports that support PoE |
48 |
|
Maximum power per PoE+ port |
30W |
|
PoE standards |
802.3at PoE+, 802.3af, Cisco pre-standard PoE |
|
Switching capacity |
104 Gbps |
|
Forwarding rate |
77.38 Mpps |
|
Fan modules |
1 fan, 37.3 dBA at 25°C |
|
Layer 3 routing |
RIP v2, policy-based routing, static routes |
|
Hardware stacking |
Not supported |
|
Power supply |
Internal universal AC, 100-240V 50-60 Hz |
Product Performance
Key Features
Each of the 48 copper ports supports 30W PoE+, and all of them draw from the same 375W pool. Support for 802.3af and Cisco pre-standard PoE alongside 802.3at lets older powered phones run on the same switch as newer PoE+ access points.
The SFP slots sit apart from the copper ports, so the switch offers 52 Gigabit ports with no combo pairs. Each uplink takes its own optic: MGBSX1 or GLC-SX-MMD for multimode runs, GLC-LH-SMD or GLC-EX-SMD for 10 km and 40 km single-mode links, or GLC-TE for copper.
A single fan cools the chassis and is rated at 37.3 dBA at 25°C. With PoE in full use the switch gives off 1537.68 BTU/hr, which is the figure to plan cabinet cooling around.
IPv4 and IPv6 traffic routes between VLANs at wire speed. RIP v2 learns routes from neighboring routers, policy-based routing steers selected flows, and the table holds up to 990 IPv4 routes across 128 IP interfaces.
Persistent PoE keeps phones and cameras powered while the switch reboots after a firmware change. Time-based PoE turns port power off and on by schedule, for example for access points in rooms that close at night.
IP phones land in a dedicated voice VLAN through Voice Services Discovery Protocol. Auto Smartports reads CDP and LLDP-MED from each attached device and applies a matching port configuration.
Application Scenarios
A company with one office floor can run all of its desk phones and ceiling access points from this 48-port switch in the floor closet, with the PoE+ ports powering both device types.
Along warehouse aisles, PoE+ IP cameras connect to the copper ports of a switch in the site cabinet, and a 1G fiber link from one SFP slot carries their video to the recording server in another building.
In the back-office rack of a larger store, the switch powers in-store access points and security cameras, then hands their traffic to the store router over a 1G SFP uplink.
Product Comparison
|
Parameter |
C1300-48P-4G | |||
|---|---|---|---|---|
|
RJ-45 ports |
48 x Gigabit Ethernet PoE+ |
48 x Gigabit Ethernet PoE+ |
48 x Gigabit Ethernet PoE+ |
48 x Gigabit Ethernet |
|
PoE power budget |
375W |
740W |
375W |
Not applicable |
|
Number of ports that support PoE |
48 |
48 |
48 |
Not applicable |
|
Uplink ports |
4 x 1G SFP |
4 x 1G SFP |
4 x 10G SFP+ |
4 x 1G SFP |
|
Switching capacity |
104 Gbps |
104 Gbps |
176 Gbps |
104 Gbps |
|
Fan modules |
1 fan, 37.3 dBA at 25°C |
1 fan, 48.7 dBA at 25°C |
1 fan, 37.3 dBA at 25°C |
1 fan, 29.7 dBA at 25°C |
|
Layer 3 routing |
RIP v2, policy-based routing |
RIP v2, policy-based routing |
RIP v2, policy-based routing |
RIP v2, policy-based routing |
|
Hardware stacking |
Not supported |
Not supported |
C1300 Family 1, up to 8 units |
Not supported |
C1300-48P-4G and C1300-48FP-4G both pair 48 PoE+ ports with four 1G SFP uplinks and 104 Gbps of switching, and the PoE budget is what separates them: 375W here against 740W. Once the planned endpoints draw more than 375W in total, or more than 12 of them need the full 30W, the closet moves to C1300-48FP-4G and its louder 48.7 dBA fan. C1300-48P-4X keeps the 375W budget but carries four 10G SFP+ uplinks, 176 Gbps and C1300 Family 1 stacking of up to eight units, which makes it the model for a 10G handoff or a stacked closet. Where nothing on the floor takes power from the switch, C1300-48T-4G keeps the same 48-port, 1G SFP layout without PoE, at 29.7 dBA.
PoE Power Planning
|
Planning Item |
Value or Check |
|---|---|
|
Power dedicated to PoE |
375W shared by 48 PoE-capable ports |
|
PoE standards |
802.3at PoE+, 802.3af and Cisco pre-standard PoE |
|
Ports at the full 30W PoE+ level |
Twelve ports use 360W; a thirteenth would need 390W in total |
|
All 48 ports powered at once |
Average draw must stay at 7.8W or less per port |
|
Endpoint count check |
Add the rated draw of every planned phone, camera and access point and keep the total at or under 375W |
|
Power consumption with PoE |
110V=450.65W; 220V=437.14W |
Ordering Checklist
- 1G SFP optics: Add one supported 1G SFP per uplink in use, such as GLC-SX-MMD for multimode or GLC-LH-SMD for single-mode fiber. The package holds no optics, so an uplink without its own module line stays unconnected.
- Power cord option: The switch ships with a power cord unless NO-POWER-CORD is selected on the order. Select that option only when cords for the site are supplied separately.
Optional Add-ons
|
Model |
Description |
|---|---|
|
CAB-CONSOLE-RJ45 |
Console cable, 6 feet, RJ-45 connector |
|
CAB-CONSOLE-USB-C |
USB-C console cable |
|
CAB-CONSOLE-USB-C= |
USB-C console cable, spare |
|
RCKMNT-1RU-1K= |
1 RU rack-mount kit for C1000, C1200 and C1300 24- and 48-port models |
|
1000 Mbps SFP, multimode fiber, 550 m | |
|
1000 Mbps SFP, single-mode fiber, 10 km | |
|
1000 Mbps SFP, single-mode fiber, 40 km | |
|
1000 Mbps SFP, single-mode fiber, 70 km | |
|
GLC-BX-U |
1000 Mbps bidirectional SFP, single-mode fiber, 10 km |
|
GLC-BX-D |
1000 Mbps bidirectional SFP, single-mode fiber, 10 km |
|
1000 Mbps copper SFP, UTP Cat 5e, 100 m | |
|
MGBSX1 |
1000 Mbps SFP, multimode fiber, 500 m |
|
MGBLX1 |
1000 Mbps SFP, single-mode fiber, 10 km |
|
MGBLH1 |
1000 Mbps SFP, single-mode fiber, 40 km |
|
MGBT1 |
1000 Mbps copper SFP, UTP Cat 5e, 100 m |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | C1300-48P-4G | Product type | Managed Layer 3 Gigabit Ethernet PoE+ switch |
| Total ports | 52 x Gigabit Ethernet | RJ-45 ports | 48 x 10/100/1000 PoE+ |
| Uplink ports | 4 x 1G SFP | Console port | Cisco standard RJ-45 console port and USB Type C port |
| USB port | USB Type C, for file and image management and console access | LEDs | System, Link/Act, PoE, Speed |
| Default PoE budget | 375W | Number of ports that support PoE | 48 |
| PoE standards | 802.3at PoE+, 802.3af, Cisco pre-standard PoE | PoE features | Time-based PoE, persistent PoE |
| Switching capacity | 104 Gbps, wire speed and nonblocking | Forwarding rate | 77.38 Mpps (64-byte packets) |
| Packet buffer | 1.5 MB, dynamically shared across all ports | MAC addresses | 16,000 entries |
| IPv4 routes | 990 (dynamic plus static) | IP interfaces | 128 |
| ACL rules | 1,024 | IGMP groups | 2,000 |
| VLANs | 4,094 (4078 to 4094 reserved for internal use) | Jumbo frames | Up to 9,000 bytes |
| Spanning tree | MSTP with 16 instances; PVST+ and Rapid PVST+ with 126 instances | Link aggregation | LACP, up to 8 groups with up to 8 ports each |
| Port mirroring | Up to 8 source ports to 1 destination port | Layer 3 routing | IPv4 and IPv6 wire-speed routing, RIP v2, policy-based routing |
| DHCP | DHCP server, DHCP relay, UDP relay | Voice | Voice VLAN with Voice Services Discovery Protocol, Auto Smartports |
| QoS | 8 hardware queues, strict priority and WRR scheduling | Security | 802.1X, web authentication, DHCP snooping, IP Source Guard, DAI, port security, storm control, RADIUS and TACACS+ |
| Hardware stacking | Not supported | Operating system | Customized Linux OS |
| Management | Cisco Business Dashboard, Cisco Business mobile app, web UI, SNMP v1/v2c/v3, CLI | Firmware upgrade | Dual images |
| CPU | ARM dual-core at 1.5 GHz | DRAM | 1 GB DDR4 |
| Flash | 1GB SLC | Default power supply | Internal universal, 100-240V 50-60 Hz |
| System power consumption | 110V=44.81W; 220V=43.93W | Power consumption with PoE | 110V=450.65W; 220V=437.14W |
| Idle power | 110V=21.03W; 220V=20.68W | Heat dissipation | 1537.68 BTU/hr |
| Fan modules | 1 | Acoustic noise | 37.3 dBA at 25°C |
| MTBF at 25°C | 1,662,884 hours | Cabling | UTP Cat 5e or better for 1000BASE-T |
| Dimensions (H x W x D) | 444.3 x 350 x 43.94 mm (17.49 x 13.78 x 1.73 in) | Weight | 5.43 kg (11.97 lb) |
| Mounting | Rack-mountable; 19-in mounting brackets included | Operating temperature | -5°C to 50°C (23°F to 122°F); cold start minimum 32°F (0°C) |
| Storage temperature | -25°C to 70°C (-13°F to 158°F) | Operating humidity | 10% to 90%, relative, noncondensing |
| Storage humidity | 10% to 90%, relative, noncondensing | Certifications | UL (UL 62368), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A |
