IE-9310-16P8S4X-E – 16xGE PoE+ – 8xGE SFP + 4x10G SFP+ – 50W PoE Budget
Shop Expert-Recommended Accessories for the IE-9310-16P8S4X-E
Explore optics, stacking accessories, modules, and power supplies—all verified by our engineers for use with this model.-
SFP-10G-SR
10GBASE-SR SFP+ - 850nm MMF - 400m OM4Original price was: $1,213.85.$91.68Current price is: $91.68. -
SFP-10G-SR-X
10GBASE-SR SFP+ - Extended Temp - 400m OM4 MMFOriginal price was: $1,942.00.$298.70Current price is: $298.70. -
SFP-10G-LR
10GBASE-LR SFP+ - 1310nm SMF - 10km ReachOriginal price was: $4,873.66.$149.00Current price is: $149.00. -
SFP-10G-LR-X
10GBASE-LR SFP+ - Extended Temp - 10km SMFOriginal price was: $11,206.77.$306.00Current price is: $306.00. -
GLC-LH-SMD
1000BASE-LX/LH SFP - 10km SMF / 550m MMF - DOMOriginal price was: $1,260.58.$95.80Current price is: $95.80. -
GLC-TE
1000BASE-T SFP - RJ-45 Cat5 Copper - 100m ReachOriginal price was: $570.10.$70.00Current price is: $70.00. -
GLC-SX-MMD
1000BASE-SX SFP - MMF 850nm - DOMOriginal price was: $633.46.$59.00Current price is: $59.00. -
GLC-EX-SMD
1000BASE-EX SFP - 40km SMF - DOMOriginal price was: $2,527.49.$205.00Current price is: $205.00. -
PWR-RGD-AC-DC-250
250W AC/DC PSU - Cisco IE4010/IE5000/IE9300/IR8340Original price was: $1,707.92.$1,230.00Current price is: $1,230.00. -
PWR-RGD-AC-DC-H
150W AC/DC PSU - Cisco IE4010/IE5000/IE9300/IR8340Original price was: $853.95.$690.00Current price is: $690.00. -
PWR-RGD-LOW-DC-H
150W Low DC Power Supply - Hazardous Locations - PoE/PoE+Original price was: $886.83.$720.00Current price is: $720.00.
Why Layer23-Switch
Stocked, Shipped and Supported by One Team
Ships in 1 Business Day
In-stock orders leave our Hong Kong or U.S. warehouse within 1 business day after payment, with tracking by email.
LSCare Warranty
3years on enterprise equipment
Free CCIE Support
Certified engineers help before and after you buy. Reply within 1 business day by email or live chat.
Verify Before You Pay
100%factory-sealed
Get label and serial photos before shipment, and check every serial number with Cisco.
IE-9310-16P8S4X-E Description
The IE-9310-16P8S4X-E is a Cisco Catalyst IE9300 Rugged Series industrial Ethernet switch for rack-mounted cabinets that mix PoE+ endpoints with fiber downlinks. The switch has 16 Gigabit PoE+ copper ports, eight 100/1000M SFP downlinks and four 1/10G SFP+ uplinks, with a PoE budget of 50W to 480W set by the power modules and an operating range of -40°C to 75°C in a blower-equipped cabinet. The full 480W budget needs two 400W modules, and 150W or 250W modules cannot share load with a 400W module.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
IE-9310-16P8S4X-E |
|
Product type |
Rugged industrial Ethernet switch |
|
Default network license |
Network Essentials |
|
Minimum IOS XE support |
IOS XE 17.18.1 onward for IE-9310-16P8S4X-E and IE-9310-16P8S4X-A |
|
Total ports |
28 |
|
GE PoE+ copper downlinks |
16 x 10/100/1000M PoE+ ports |
|
GE SFP downlinks |
8 x 100/1000M SFP ports |
|
SFP+ uplinks |
4 x 1G/10G SFP+ ports |
|
Default PoE budget |
50 W to 480 W depending on installed power supplies |
|
Maximum PoE per copper port |
Up to 30 W on each copper GE downlink |
|
Stacking support |
No |
|
Power inputs |
Two field-replaceable redundant AC or DC power supplies |
|
Weight |
4.81 kg (10.6 lb) |
Product Performance
Key Features
The PoE budget steps from 50W on a single 150W module to 480W on two 400W modules. Sixteen PoE+ ports at 30W each add up to 480W, so only the dual 400W pair covers a fully loaded switch.
Sixteen PoE+ copper ports and eight 100/1000M SFP ports share a single rack unit. Powered devices stay on copper while distant cabinets connect over fiber.
The four SFP+ uplinks run at 1G or 10G, backed by 95.23 Mpps of forwarding rate and 128 Gbps of switching bandwidth. A 10G backhaul can be added without changing the downlink layout.
HSR, PRP and PTP over PRP run on this model, alongside REP and MRP rings. Protection and process traffic can follow duplicate paths or ring topologies without a reconvergence gap.
The switch operates from -40°C to 75°C in a blower-equipped cabinet, 70°C in a vented cabinet and 60°C in a sealed cabinet. It is fanless and rated IP30, so it belongs inside an enclosure.
Two field-replaceable, electrically isolated power modules cover AC, high-voltage DC or 24-60V low-voltage DC feeds. The chassis does not stack, so each switch is managed on its own.
Application Scenarios
In a rail station equipment room, the switch powers platform cameras and passenger information displays from its PoE+ ports and sends their traffic to the operations center over SFP+ uplinks.
A substation control building can connect bay-level protection devices over the SFP downlinks while HSR and PRP keep protection traffic on duplicate paths.
At a highway intelligent transportation hub, the switch feeds roadside cameras and signal controllers from PoE+ ports and aggregates fiber links from smaller cabinets along the route.
Product Comparison
|
Parameter |
IE-9310-16P8S4X-E |
IE-9310-16P8S4X-A |
IE-9320-16P8U4X-E | |
|---|---|---|---|---|
|
Downlinks |
16 ports 10/100/1000M PoE+ and 8 ports 100/1000M SFP |
16 ports 10/100/1000M PoE+ and 8 ports 100/1000M SFP |
16 ports 10/100/1000M PoE+ and 8 ports 100/1000/2500M 4PPoE (up to 90W/port) |
22 ports 100/1000M SFP and 2 ports Dual-Media (100/1000M SFP or 10/100/1000M RJ45) |
|
Uplinks (SFP/SFP+) |
4 ports 1/10G |
4 ports 1/10G |
4 ports 1/10G |
4 ports 1000M |
|
Software license (default) |
Network Essentials |
Network Advantage |
Network Essentials |
Network Essentials |
|
Default PoE budget |
50W (one 150W module) |
50W (one 150W module) |
70W (one 150W module) |
No PoE |
|
Maximum PoE budget |
480W (two 400W modules) |
480W (two 400W modules) |
720W (two 400W modules) |
No PoE |
|
Cisco StackWise ports |
Not supported |
Not supported |
2 stacking ports |
Not supported |
|
Power inputs |
Dual AC/DC power inputs |
Dual AC/DC power inputs |
Dual AC/DC power inputs |
Dual AC/DC power inputs |
|
Operating temperature |
-40° to 75°C (blower-equipped cabinet) |
-40° to 75°C (blower-equipped cabinet) |
-40° to 75°C (blower-equipped cabinet) |
-40° to 75°C (blower-equipped cabinet) |
|
Mounting |
Rack mount |
Rack mount |
Rack mount |
Rack mount |
IE-9310-16P8S4X-E and IE-9310-16P8S4X-A share one non-stackable chassis with 16 GE PoE+ copper ports, 8 SFP downlinks and four 1/10G SFP+ uplinks, so the only difference is the license, Network Essentials versus Network Advantage. A site that needs BGP, EIGRP, TrustSec over PRP or SD-Access Fabric Edge orders IE-9310-16P8S4X-A, or adds the perpetual IE9300-NW-A= to an Essentials unit later. Stacking, or 8 x 2.5G 4PPoE ports with a 720 W PoE budget, means IE-9320-16P8U4X-E, because this model has no stacking and tops out at 480 W with dual 400 W supplies. A site with no powered endpoints and all-fiber downlinks can use IE-9310-26S2C-E, with 24 GE SFP downlinks and 4 GE SFP uplinks.
PoE Power Planning
|
Planning item |
Cisco-confirmed value |
Procurement check |
|---|---|---|
|
PoE-capable ports |
16 copper GE downlinks with up to 30 W PoE output per port |
Confirm powered endpoints are assigned to the copper ports and not to SFP downlinks |
|
Maximum system PoE budget |
480 W with dual 400 W power supplies |
Use this only when the order includes the required 400 W PSU pair |
|
Lower PoE budget options |
50 W, 150 W, 170 W, 260 W, 300 W, or 350 W depending on installed PSU mix |
Size the powered-device list against the exact PSU combination rather than the chassis alone |
|
Software support |
IE-9310-16P8S4X-E PoE support starts with IOS XE 17.18.1 |
Check the software image before staging PoE configuration |
|
PoE management behavior |
Auto mode detects powered devices; policing and load shedding are documented PoE controls |
Decide port priority and power policing before field activation |
Ordering Checklist
- Power modules: Order two PWR-RGD modules: PWR-RGD-AC-DC-H (150W), PWR-RGD-AC-DC-250 (250W) or PWR-RGD-AC-DC-400 (400W) for 85-264V AC or 88-300V DC, or PWR-RGD-LOW-DC-H (150W) for 18-75V DC. The PoE budget follows the module mix, reaching 480W only with two PWR-RGD-AC-DC-400, and 150W or 250W modules cannot load-share with a 400W module.
- Optics: Select industrial-grade SFP and SFP+ such as GLC-SX/LX/ZX-RGD, SFP-10G-SR-I or SFP-10G-LR-X. Non-industrial SFPs need temperature derating.
- Software license: Network Essentials is the default; add IE9300-NW-A= for Network Advantage, and an IE9300-DNA-E term (3Y, 5Y or 7Y) only if Catalyst Center is used. The Advantage upgrade is a separate perpetual PID.
- SD card: Add SD-IE-16GB= (16GB). The optional card holds configuration backup for switch replacement.
- Rack kit: Order RM-RGD-19IN= (19-inch), RM-RGD-23IN= (23-inch NEBS) or RM-RGD-ETSI= (ETSI) to match the rack standard.
Optional Add-ons
|
Model |
Description |
|---|---|
|
SD-IE-16GB= |
16GB SD memory card for IE |
|
RM-RGD-19IN= |
Spare 19IN rack-mount kit |
|
RM-RGD-23IN= |
23IN NEBS rack-mount kit |
|
RM-RGD-ETSI= |
ETSI rack-mount kit |
|
Hazloc Power Supply High AC/DC 85-264VAC or 88-300VDC | |
|
Hazloc Power Supply Low DC 24-60V/10A | |
|
Hazloc Power Supply 100-240VAC or 100-250VDC | |
|
PWR-RGD-AC-DC-400 |
Hazloc Power Supply 100-240VAC or 100-250VDC, 400W |
|
IE9300-NW-A= |
Network Advantage License for IE9300, Perpetual |
|
IE9300-DNA-E-3Y |
IE 9300 Cisco Catalyst Center DNA Essentials, 3 Year Term license |
|
IE9300-DNA-A-3Y |
IE 9300 Cisco Catalyst Center DNA Advantage, 3 Year Term license |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | IE-9310-16P8S4X-E | Product type | Rugged industrial Ethernet switch |
| Default network license | Network Essentials | Minimum IOS XE support | IOS XE 17.18.1 onward for IE-9310-16P8S4X-E and IE-9310-16P8S4X-A |
| Total ports | 28 | GE PoE+ copper downlinks | 16 x 10/100/1000M PoE+ ports |
| GE SFP downlinks | 8 x 100/1000M SFP ports | SFP+ uplinks | 4 x 1G/10G SFP+ ports |
| Maximum PoE per copper port | 30 W | Maximum PoE budget | 480 W with dual 400 W power supplies |
| PSU-dependent PoE budgets | 50 W to 480 W depending on power supply combination | Power inputs | Two field-replaceable redundant AC or DC power supplies |
| 150 W high AC/DC PSU | PWR-RGD-AC-DC-H, 85-264VAC or 88-300VDC | 150 W low DC PSU | PWR-RGD-LOW-DC-H, 24-60V/10A |
| 250 W AC/DC PSU | PWR-RGD-AC-DC-250, 100-240VAC or 100-250VDC | 400 W AC/DC PSU | PWR-RGD-AC-DC-400, 100-240VAC or 100-250VDC |
| Power consumption | 105 W chassis-only power consumption | Mounting | Rack mount |
| Weight | 4.81 kg (10.6 lb) | Depth with 150 W PSU | 1.72 x 17.5 x 14.0 in. |
| Depth with 250 W PSU | 1.72 x 17.5 x 15.18 in. | Depth with 400 W PSU | 1.72 x 17.5 x 15.57 in. |
| Stacking support | No | GNSS | No |
| IRIG-B | No | DRAM | 4 GB |
| Onboard flash memory | 8 GB | User-accessible flash | 2.5 GB |
| Removable storage | SD card slot | USB host | USB Type A connector |
| Console port | 1 RS-232 RJ-45 console and 1 Micro USB console | Alarm I/O | 4 dry-contact alarm inputs and 1 dry-contact Form-C relay output |
| Forwarding rate | 95.23 Mpps | Forwarding bandwidth | 64 Gbps |
| Switching capacity | 128 Gbps full-duplex capacity | Queues per port | 8 egress |
| MAC addresses | 24000 | IGMP multicast groups | 1000 |
| VLAN IDs | 4096 | Active VLANs | 1024 |
| IPv4 direct routes | 8192 | IPv4 indirect routes | 7000 |
| IPv6 indirect routes | 3500 | ACL entries | 1536 PACL, VACL, or RACL entries |
| MTBF | 265,827 hours | IP rating | IP30 |
Quality Certifications
Customer Reviews
Questions & Answers
-
What operating temperature range does IE-9310-16P8S4X-E support?
-
What input voltage does IE-9310-16P8S4X-E need for its full 480 W PoE budget?
-
Is Meraki cloud management supported on IE-9310-16P8S4X-E?
-
What alarm and console connections does IE-9310-16P8S4X-E provide?
-
How deep is IE-9310-16P8S4X-E with a 150W, 250W or 400W power module installed?
-
How much memory and removable storage does IE-9310-16P8S4X-E have?
