C9200L-48P-4G-A Description
The C9200L-48P-4G-A is a Cisco Catalyst 9200L Series fixed-uplink stackable access switch for wiring closets that power phones, access points and cameras over Gigabit copper. The switch has 48 Gigabit PoE+ ports, four 1G SFP uplinks, a 740W PoE budget on the default PWR-C5-1KWAC supply and 104 Gbps of switching capacity. The -A suffix carries Network Advantage, which adds EIGRP, HSRP and VRF segmentation over Network Essentials, and the fixed uplinks cannot be swapped for modules.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
C9200L-48P-4G-A |
|
Product type |
Fixed-uplink stackable access switch |
|
Downlink ports |
48 x 1G PoE+ copper ports |
|
Uplink ports |
4 x 1G SFP fixed uplink ports |
|
Network license |
Network Advantage |
|
Stacking architecture |
StackWise-80 |
|
Stack bandwidth |
80 Gbps |
|
Switching capacity |
104 Gbps standalone; 184 Gbps with stacking |
|
Forwarding rate |
77.38 Mpps standalone; 137 Mpps with stacking |
|
Default PoE budget |
740W with one PWR-C5-1KWAC |
|
Expanded PoE budget |
1440W with a second PWR-C5-1KWAC |
|
Default power supply |
PWR-C5-1KWAC |
Product Performance
Key Features
One PWR-C5-1KWAC gives 740W for PoE, about 15W per port if all 48 ports draw power at once. A second PWR-C5-1KWAC raises the budget to 1440W, enough for 30W on every port.
Four SFP slots carry 1G optics to the distribution layer. The uplinks are part of the chassis, so the switch takes no uplink network module and its upstream speed stays at 1G.
Up to eight C9200L switches at the same license level form one stack over 80 Gbps of stack bandwidth and are managed as a single switch. Modular Catalyst 9200 models cannot join the stack.
The tier adds EIGRP, HSRP, IS-IS and VRF, VXLAN, LISP and SGT segmentation on top of Network Essentials, which suits closets doing routed access for several tenants or traffic classes.
Perpetual PoE keeps endpoints powered while the switch reloads, and Fast PoE restores power after an outage before the operating system finishes loading. Phones and cameras come back sooner after a closet power event.
The PWR-C5-715WDC= DC supply is available as a spare and needs Cisco IOS XE 17.8.1 or later. It provides 485W of PoE with one supply and 970W with two.
Application Scenarios
In an office floor closet, the switch powers IP phones, Wi-Fi access points and cameras from its 48 PoE+ ports and hands their traffic to the distribution layer over 1G SFP fiber.
A branch office that keeps guest, voice and device traffic in separate VRFs can run routed access on this switch, since Network Advantage supports that segmentation at the edge.
When a closet outgrows its ports, this switch can join an existing C9200L stack at the same license level and be managed with the other members as one switch.
Product Comparison
|
Parameter |
C9200L-48P-4G-A |
C9200L-48PL-4G-A | ||
|---|---|---|---|---|
|
Downlinks total 10/100/1000 or PoE+ copper ports |
48 ports full PoE+ |
48 ports full PoE+ |
48 ports full PoE+ |
48 ports, partial PoE+ |
|
Uplink configuration |
4 x 1G fixed |
4 x 1G fixed |
4 x 1/10G fixed |
4 x 1G fixed |
|
Default power supply |
PWR-C5-1KWAC (1000W) |
PWR-C5-1KWAC (1000W) |
PWR-C5-1KWAC (1000W) |
PWR-C5-600WAC (600W) |
|
Default available PoE power |
740W |
740W |
740W |
370W |
|
Maximum PoE power with secondary power supply |
1440W |
1440W |
1440W |
740W |
|
Network license |
Network Advantage |
Network Essentials |
Network Advantage |
Network Advantage |
|
Stack bandwidth |
80 Gbps |
80 Gbps |
80 Gbps |
80 Gbps |
|
Switching capacity |
104 Gbps |
104 Gbps |
176 Gbps |
104 Gbps |
C9200L-48P-4G-A and C9200L-48P-4X-A share the 48 PoE+ ports, the PWR-C5-1KWAC supply and the 740W default budget, but the 4G model has four fixed 1G uplinks and 104 Gbps of switching capacity, while C9200L-48P-4X-A has 10G fixed uplinks and 176 Gbps, so a 10G handoff to the aggregation layer needs C9200L-48P-4X-A. C9200L-48P-4G-E runs the same hardware on Network Essentials; a closet without EIGRP, HSRP or VRF requirements can drop to it and loses those Advantage features. C9200L-48PL-4G-A has partial PoE support and cuts the default budget to 370W on a PWR-C5-600WAC, which suits only closets with a light powered load.
PoE Power Planning
|
Planning Item |
Cisco Confirmed Value |
Order Impact |
|---|---|---|
|
PoE standard |
IEEE 802.3at PoE+ up to 30W per port on Catalyst 9200 Series switches |
Compare powered endpoint count and endpoint draw against the available switch power budget |
|
PoE budget with default supply |
PWR-C5-1KWAC provides 740W available PoE power on C9200L-48P-4G-A |
Keep the PoE design within the single-supply limit if no second supply is ordered |
|
PoE with secondary supply |
A second PWR-C5-1KWAC raises available PoE power to 1440W |
Add the second supply when the access design needs more PoE headroom or power redundancy |
|
DC spare option |
PWR-C5-715WDC= is spare-only and supported on C9200L PoE models with IOS XE 17.8.1 and later |
Treat DC power as a software-release and spare-part compatibility check |
Ordering Checklist
- Subscription term: Select a 48-port Advantage term such as C9200L-DNA-A-48-3Y, -5Y or -7Y (or the C9200L-DNX-A-48 Cisco Catalyst equivalent) under a Smart Account. The configurator defaults to a 3-year Cisco DNA term, and the tier must match the -A suffix on C9200L-48P-4G-A.
- Second power supply: Add a second PWR-C5-1KWAC to raise the PoE budget from 740W to 1440W. One PWR-C5-1KWAC ships by default, so the second supply is added only on the order or later as a spare.
- Stack kit: Add C9200L-STACK-KIT (two data stack adapters and one 0.5 m cable), plus STACK-T4-1M or STACK-T4-3M for longer runs. The kit does not ship with the switch, and StackWise-80 stacks only C9200L members of the same license tier.
- Power cords: Order one country-specific CAB-TA cord per installed supply, rated 15A for the 1KW supply. The configurator requires a cord for an AC supply, and the 1000W supply needs the higher-rated cord.
Optional Add-ons
|
Model |
Description |
|---|---|
|
Stack kit for C9200L SKUs with two data stack adapters and one data stack cable | |
|
50 cm data stack cable supplied as the default cable with the stack kit | |
|
1 m data stack cable for Catalyst 9200 Series stacking | |
|
3 m data stack cable for Catalyst 9200 Series stacking | |
|
1000W AC power supply used as the default and secondary AC supply for C9200L-48P-4G-A | |
|
715W DC power supply spare supported on C9200L PoE models with IOS XE 17.8.1 and later | |
|
C9200L-DNA-A-48-3Y |
C9200L Cisco DNA Advantage 48-port 3-year term license |
|
C9200L-DNA-A-48-5Y |
C9200L Cisco DNA Advantage 48-port 5-year term license |
|
C9200L-DNA-A-48-7Y |
C9200L Cisco DNA Advantage 48-port 7-year term license |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | C9200L-48P-4G-A | Product type | Fixed-uplink stackable access switch |
| Network license | Network Advantage | Downlink ports | 48 x 1G PoE+ copper ports |
| Uplink ports | 4 x 1G SFP fixed uplink ports | Modular uplinks | No for C9200L fixed-uplink models |
| Power supply slots | 2 slots | Default power supply | PWR-C5-1KWAC |
| Fan design | 2 fixed fans with redundancy support | Stacking architecture | StackWise-80 |
| Stack bandwidth | 80 Gbps | Supported stack members | Other C9200L models with the same license level |
| Switching capacity | 104 Gbps standalone; 184 Gbps with stacking | Forwarding rate | 77.38 Mpps standalone; 137 Mpps with stacking |
| PoE standards | IEEE 802.3at PoE+ up to 30W per port | Default PoE budget | 740W with PWR-C5-1KWAC |
| PoE budget with second supply | 1440W with second PWR-C5-1KWAC | Optional DC power supply | PWR-C5-715WDC= spare supported on C9200L PoE models with IOS XE 17.8.1 and later |
| DRAM | 2 GB | Flash | 4 GB |
| MAC addresses | 16,000 | IPv4 routes | 11,000 total with 8,000 direct and 3,000 indirect routes |
| Packet buffer | 6 MB for 24- or 48-port Gigabit Ethernet C9200L models | Flexible NetFlow entries | 16,000 flows on 24- and 48-port Gigabit Ethernet models |
| Dimensions | 1.73 x 17.5 x 11.3 in. (4.4 x 44.5 x 28.8 cm) | Installed dimensions | 1.73 x 17.5 x 12.9 in. (4.4 x 44.5 x 32.9 cm) |
| Weight | 4.80 kg (10.58 lb) with one power supply installed | MTBF | 347,760 hours |
Get More Information
Need pricing, stock, or shipping details for the C9200L-48P-4G-A ? Layer23-Switch can help you check current availability, lead time, and delivery options for this. Send us the part number, quantity, and destination country via live chat or email [email protected] for a fast quotation.
Quality Certifications
Customer Reviews
Questions & Answers
-
How is the 80 Gbps stack bandwidth of C9200L-48P-4G-A divided across its rings?
-
How many ACL entries does C9200L-48P-4G-A support?
-
What happens to C9200L-48P-4G-A if one of its two fans fails?
-
What output does a PWR-C5-1KWAC supply give C9200L-48P-4G-A, and can a DC supply share the chassis?
-
Does C9200L-48P-4G-A support MACsec-256 with Network Advantage?
