C9300L-48PF-4G-E – 48x1G PoE+ Ports – 4x1G Fixed Uplinks – 890W PoE Budget
3/mo Solds
Cisco C9300L-48PF-4G-E Compatible Accessories, Modules & Spare Parts
Find compatible network modules, power supplies, fans, optics, cables and spare parts for the Cisco C9300L-48PF-4G-E. These accessories support fiber connectivity, hardware replacement, spare inventory and network maintenance projects.
Optics & Cables Compatible with Cisco C9300L-48PF-4G-E
-
GLC-LH-SMD
1000BASE-LX/LH SFP - 10km SMF / 550m MMF - DOMOriginal price was: $2,658.11.$95.80Current price is: $95.80. Condition: New Factory Sealed -
GLC-TE
1000BASE-T SFP - RJ-45 Cat5 Copper - 100m ReachOriginal price was: $1,202.16.$62.50Current price is: $62.50. Condition: New Factory Sealed -
GLC-SX-MMD
1000BASE-SX SFP - MMF 850nm - DOMOriginal price was: $1,335.73.$57.00Current price is: $57.00. Condition: New Factory Sealed -
GLC-EX-SMD
1000BASE-EX SFP - 40km SMF - DOMOriginal price was: $5,329.57.$205.00Current price is: $205.00. Condition: New Factory Sealed -
GLC-ZX-SMD
1000BASE-ZX SFP - 70km SMF - EXT DOMOriginal price was: $10,672.47.$215.70Current price is: $215.70. Condition: New Factory Sealed
Power Supplies & Fans Compatible with Cisco C9300L-48PF-4G-E
-
PWR-C1-1100WAC-P
1100W AC PSU - Catalyst 9300 C1 - Platinum RatedOriginal price was: $2,317.88.$635.40Current price is: $635.40. Condition: New Factory Sealed
Established Global IT Distributor
With over a decade of industry experience, we are a certified Cisco Partner delivering genuine enterprise networking hardware and trusted services to system integrators, ISPs, and enterprises worldwide.
C9300L-48PF-4G-E Description
C9300L-48PF-4G-E is a Cisco Catalyst 9300L fixed-uplink stackable access switch for campus access networks that need 48 1G PoE+ copper ports with four integrated 1G uplinks. This Network Essentials model uses the PWR-C1-1100WAC-P power supply, provides an 890W default PoE budget for powered endpoints, supports StackWise-320 stacking, and runs from the Cisco IOS XE Gibraltar 16.12.2 release family, making it a high-PoE Catalyst 9300L option for edge access closets that keep uplinks at 1G.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
C9300L-48PF-4G-E |
|
Product type |
Fixed-uplink stackable access switch |
|
Access ports |
48 x 10/100/1000 Mbps PoE+ copper ports |
|
Uplink ports |
4 x 1G fixed uplink ports |
|
Network license |
Network Essentials |
|
Default power supply |
PWR-C1-1100WAC-P |
|
Default PoE budget |
890W with 1100W AC power supply |
|
Expanded PoE budget |
1440W with supported secondary power supply configuration |
|
Stacking architecture |
StackWise-320 |
|
Switching capacity |
104 Gbps standalone; 424 Gbps with stacking |
|
Forwarding rate |
77.38 Mpps standalone; 315.48 Mpps with stacking |
|
Introductory release |
Cisco IOS XE Gibraltar 16.12.2 |
Product Performance
Key Features
The `-E` suffix maps this high-PoE fixed-uplink switch to Network Essentials instead of the Network Advantage level used by C9300L-48PF-4G-A.
PF ordering gives the 48-port PoE+ model an 890W default power profile, while the adjacent C9300L-48P-4G-E profile is listed at 505W.
The 4G base hardware uses fixed 1G uplinks, separating it from 4X models that use 10G/1G SFP+ fixed uplinks.
C9300L fixed-uplink switches use StackWise-320 with up to eight stack members and C9300L stack kit options.
Cisco lists PWR-C1-1100WAC-P as the default supply for the C9300L-48PF-4G profile, so power-supply matching is part of the SKU check.
The Catalyst 9300L fixed-uplink design does not use the modular C9300 network-module selection path, keeping uplink choice tied to the base SKU.
Application Scenarios
C9300L-48PF-4G-E fits branch or campus access closets where Network Essentials is enough but the endpoint mix needs more than the 505W default PoE profile of the non-PF C9300L-48P model.
Use this model when the closet design is based on four fixed 1G uplinks and does not require the 10G/1G SFP+ uplink profile of the 4X variant.
The SKU can be planned as a C9300L StackWise-320 member when the stack hardware, cable length, and Network Essentials license level match the existing access stack.
Product Comparison
|
Parameter |
C9300L-48PF-4G-E | |||
|---|---|---|---|---|
|
Product type |
Fixed-uplink access switch |
Fixed-uplink access switch |
Fixed-uplink access switch |
Fixed-uplink access switch |
|
Access ports |
48 x 10/100/1000 Mbps PoE+ |
48 x 10/100/1000 Mbps PoE+ |
48 x 10/100/1000 Mbps PoE+ |
48 x 10/100/1000 Mbps PoE+ |
|
Uplink ports |
4 x 1G fixed |
4 x 1G fixed |
4 x 1G fixed |
4 x 10G/1G SFP+ fixed |
|
Network license |
Network Essentials |
Network Advantage |
Network Essentials |
Network Essentials |
|
Default power supply |
PWR-C1-1100WAC-P |
PWR-C1-1100WAC-P |
PWR-C1-715WAC-P |
PWR-C1-1100WAC-P |
|
Default PoE budget |
890W |
890W |
505W |
890W |
|
Expanded PoE budget |
1440W with supported secondary power supply configuration |
1440W with supported secondary power supply configuration |
1440W with supported secondary power supply configuration |
1440W with supported secondary power supply configuration |
|
Stacking architecture |
StackWise-320 |
StackWise-320 |
StackWise-320 |
StackWise-320 |
|
Switching capacity |
104 Gbps standalone; 424 Gbps with stacking |
104 Gbps standalone; 424 Gbps with stacking |
104 Gbps standalone; 424 Gbps with stacking |
176 Gbps standalone; 496 Gbps with stacking |
|
Forwarding rate |
77.38 Mpps standalone; 315.48 Mpps with stacking |
77.38 Mpps standalone; 315.48 Mpps with stacking |
77.38 Mpps standalone; 315.48 Mpps with stacking |
130.95 Mpps standalone; 369.05 Mpps with stacking |
|
Introductory release |
Cisco IOS XE Gibraltar 16.12.2 |
Cisco IOS XE Gibraltar 16.12.2 |
Cisco IOS XE Gibraltar 16.11.1c |
Cisco IOS XE Gibraltar 16.12.2 |
- In a C9300L-48PF-4G-E vs C9300L-48PF-4G-A comparison, the hardware profile and 890W PoE budget match; the difference is Network Essentials versus Network Advantage.
- The C9300L-48PF-4G-E difference from C9300L-48P-4G-E is the power profile, because the PF model uses the 1100WAC-P supply with 890W PoE while the C9300L-48P model uses the 715WAC-P supply with 505W PoE.
- For C9300L-48PF-4G-E vs C9300L-48PF-4X-E, the comparison is uplink speed and bandwidth: 4G stays at fixed 1G uplinks, while 4X moves to fixed 10G/1G SFP+ uplinks and higher listed switching and forwarding values.
- The which model to choose question should be decided by Network Essentials versus Advantage, PF versus C9300L-48P-4G-E PoE budget, and 1G versus 10G uplink requirement.
Selection Guide
1. Pick it for Essentials high-PoE access
Choose C9300L-48PF-4G-E when the bill of materials needs 48 PoE+ copper ports, Network Essentials, fixed 1G uplinks, and the 890W PF power profile.
2. Use the A model for Advantage only
Move to C9300L-48PF-4G-A when the same C9300L-48PF-4G hardware should ship with Network Advantage and the matching Advantage term license.
3. Avoid the C9300L-48P model when PoE budget is tight
C9300L-48P-4G-E is the lower-budget neighbor, so keep the PF SKU when endpoint planning depends on the 890W default PoE value.
4. Select 4X for 10G aggregation
Use C9300L-48PF-4X-E only when the access design requires fixed 10G/1G SFP+ uplinks or the higher 4X switching and forwarding values.
PoE Power Planning
|
Planning Item |
Cisco Confirmed Value |
Order Impact |
|---|---|---|
|
PoE access profile |
48 x 10/100/1000 Mbps PoE+ ports |
Match powered endpoint count and per-device draw to the 48-port PF access profile |
|
Default PoE budget |
890W with PWR-C1-1100WAC-P |
Treat the 1100W AC Platinum supply as the baseline for this SKU |
|
Secondary power supply options |
1240W with 350W secondary supply; 1440W with 715W or 1100W secondary supply |
Confirm whether redundancy or higher PoE capacity is required before quoting accessories |
|
StackPower boundary |
C9300L fixed-uplink models do not support StackPower |
Plan power per switch rather than through a shared StackPower pool |
Ordering Checklist
|
Check Item |
What to Confirm |
Why It Matters |
|---|---|---|
|
Exact SKU suffix |
C9300L-48PF-4G-E |
Identifies the high-PoE PF hardware with Network Essentials |
|
Uplink class |
Fixed 4 x 1G uplinks |
Prevents an accidental 4X order when 10G uplinks are not part of the design |
|
License tier |
Network Essentials and C9300L DNA Essentials 48-port term |
Keeps the software order aligned with the `-E` suffix |
|
PoE baseline |
890W available PoE with PWR-C1-1100WAC-P |
Separates this model from 505W C9300L-48P-4G-E planning |
|
Stack accessories |
C9300L stack kit or Stack Kit2 plus selected Type 3 or Type 3A cable length |
Ensures the physical StackWise-320 build matches the C9300L accessory family |
|
Power and media accessories |
Regional AC cord, redundant supply need, and 1G uplink optics |
Keeps site power and fiber handoff items tied to the verified 4G model |
Optional Add-ons
|
Model |
Description |
|---|---|
|
Stack kit for C9300L SKUs with two stack adapters and one stack cable | |
|
C9300L-STACK-KIT2 |
Stack Kit 2 for C9300L and C9300LM fixed-uplink stack builds with two stack adapters and one stack cable |
|
50 cm Type 3 stacking cable for C9300L Stack Kit builds | |
|
1 m Type 3 stacking cable for C9300L Stack Kit builds | |
|
STACK-T3-3M |
3 m Type 3 stacking cable for C9300L Stack Kit builds |
|
50 cm Type 3A stacking cable for C9300L Stack Kit2 builds | |
|
1 m Type 3A stacking cable for C9300L Stack Kit2 builds | |
|
3 m Type 3A stacking cable for C9300L Stack Kit2 builds | |
|
C9300L Cisco DNA Essentials 48-port 3-year term license | |
|
C9300L-DNA-E-48-5Y |
C9300L Cisco DNA Essentials 48-port 5-year term license |
|
C9300L-DNA-E-48-7Y |
C9300L Cisco DNA Essentials 48-port 7-year term license |
Switch Rear Panel
The switch rear panel includes StackWise connectors, StackPower or XPS connectors, ports, fan modules, and power supply modules.
Components Delivered in the Shipping Box
The shipping box contains the model of the switch you ordered and other components needed for installation. Some components are optional, depending on your order.
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | C9300L-48PF-4G-E | Product type | Fixed-uplink stackable access switch |
| Network license | Network Essentials | Introductory release | Cisco IOS XE Gibraltar 16.12.2 |
| Access ports | 48 x 10/100/1000 Mbps PoE+ copper ports | Uplink ports | 4 x 1G fixed uplink ports |
| Modular uplinks | Fixed uplinks built into the SKU | StackPower | Not supported on C9300L fixed-uplink models |
| Default power supply | PWR-C1-1100WAC-P | Default PoE budget | 890W with 1100W AC power supply |
| Secondary PoE with 350W supply | 1240W | Secondary PoE with 715W or 1100W supply | 1440W |
| Stacking architecture | StackWise-320 | Stack member limit | Up to 8 switches |
| Supported stack members | Catalyst 9300L and 9300LM models with the same license level | Stack kit options | C9300L-STACK-KIT or C9300L-STACK-KIT2 |
| Switching capacity | 104 Gbps standalone | Switching capacity with stacking | 424 Gbps |
| Forwarding rate | 77.38 Mpps standalone | Forwarding rate with stacking | 315.48 Mpps |
| MAC addresses | 32,000 | IPv4 routes | 32,000 total with 24,000 direct and 8,000 indirect routes |
| Packet buffer | 16 MB for C9300L 24- and 48-port Gigabit Ethernet models | Flexible NetFlow entries | 64,000 flows on C9300L 24- and 48-port Gigabit Ethernet models |
| DRAM | 8 GB | Flash | 16 GB |
| VLAN IDs | 4094 | Jumbo frames | 9198 bytes |
| Dimensions | 1.73 x 17.5 x 19.2 in. (4.4 x 44.5 x 48.8 cm) | Weight | 15.48 lb (7.03 kg) |
| MTBF | 303,660 hours | Power connector | Internal auto-ranging AC power supply input |
