C9300-24U-A Description
C9300-24U-A is a Cisco Catalyst 9300 stackable access switch with 24 10/100/1000 UPOE copper ports, modular uplink support, an 830W PoE budget with the default 1100W AC supply, StackWise-480, StackPower, and Network Advantage.
The order fits access closets where 60W-class Cisco UPOE endpoints matter more than simply adding PoE+ ports. The closest same-port split is C9300-24U-E with Network Essentials, while C9300-24P-A keeps the 24-port Catalyst 9300 form factor but changes the powered-access profile to PoE+.
Procurement review should confirm the uplink network module, StackWise and StackPower cabling, second power supply plan, Catalyst Advantage software term, power cord region, availability, warranty support, and shipping destination against the final bill of materials.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
C9300-24U-A |
|
Product family |
Cisco Catalyst 9300 Series |
|
Product type |
Stackable access switch with modular uplinks |
|
Access ports |
24 x 10/100/1000 Cisco UPOE copper ports |
|
Uplink architecture |
Modular uplink slot for Cisco Catalyst 9300 network modules |
|
Network license |
Network Advantage |
|
Default power supply |
PWR-C1-1100WAC-P |
|
PoE budget with default supply |
830W |
|
Stacking architecture |
StackWise-480 |
|
StackPower |
Supported |
|
Cisco DNA subscription |
C9300-DNA-A-24 Advantage 24-port term license family |
|
Switching capacity |
208 Gbps standalone; 688 Gbps with stacking |
|
Forwarding rate |
154.76 Mpps standalone; 511.90 Mpps with stacking |
Product Performance
Key Features
The `24U` hardware profile identifies this as the 24-port 1G Cisco UPOE member of the modular-uplink Catalyst 9300 family, not a data-only or PoE+ access switch.
The `-A` suffix confirms Network Advantage, separating C9300-24U-A from the C9300-24U-E Essentials order line while keeping the same C9300-24U hardware profile.
C9300 modular-uplink switches do not include the uplink module in the default switch configuration, so the quote needs the selected C9300-NM module when uplink ports are required.
StackWise-480 support lets this model join Catalyst 9300 stack designs where stack members, cables, and license levels are planned together.
StackPower support allows the power design to include shared power cabling across compatible Catalyst 9300 stack members when the site standard calls for it.
The C9300-24U hardware profile is tied to a 1100W AC default supply, which is a key difference from lower-power 24-port data and PoE+ Catalyst 9300 models.
Application Scenarios
Use C9300-24U-A where the wiring closet must support a 24-port 1G access switch for endpoints that require Cisco UPOE rather than only PoE+.
The SKU fits a Catalyst 9300 campus standard that combines Network Advantage with StackWise-480 and StackPower planning across access-layer stack members.
The switch is suitable when downlink requirements are fixed at 24 UPOE ports but uplink speed still needs to be chosen through a C9300 network module.
Product Comparison
|
Parameter |
C9300-24U-A | |||
|---|---|---|---|---|
|
Product family |
Catalyst 9300 Series |
Catalyst 9300 Series |
Catalyst 9300 Series |
Catalyst 9300 Series |
|
Product type |
Stackable access switch |
Stackable access switch |
Stackable access switch |
Stackable access switch |
|
Access ports |
24 x 10/100/1000 UPOE |
24 x 10/100/1000 UPOE |
24 x 10/100/1000 PoE+ |
48 x 10/100/1000 UPOE |
|
Uplink architecture |
Modular uplink slot |
Modular uplink slot |
Modular uplink slot |
Modular uplink slot |
|
Network license |
Network Advantage |
Network Essentials |
Network Advantage |
Network Advantage |
|
Default power supply |
1100W AC |
1100W AC |
715W AC |
1100W AC |
|
PoE budget with default supply |
830W |
830W |
445W |
822W |
|
Stacking architecture |
StackWise-480 |
StackWise-480 |
StackWise-480 |
StackWise-480 |
|
StackPower |
Supported |
Supported |
Supported |
Supported |
|
Switching capacity |
208 Gbps standalone; 688 Gbps with stacking |
208 Gbps standalone; 688 Gbps with stacking |
208 Gbps standalone; 688 Gbps with stacking |
256 Gbps standalone; 736 Gbps with stacking |
|
Forwarding rate |
154.76 Mpps standalone; 511.90 Mpps with stacking |
154.76 Mpps standalone; 511.90 Mpps with stacking |
154.76 Mpps standalone; 511.90 Mpps with stacking |
190.47 Mpps standalone; 547.62 Mpps with stacking |
- In a C9300-24U-A vs C9300-24U-E comparison, the hardware profile, 24 UPOE ports, PoE budget, StackWise-480 support, and StackPower support align; the table difference is Network Advantage versus Network Essentials.
- The C9300-24U-A difference from C9300-24P-A is the powered-access profile and default power supply: C9300-24U-A is the UPOE model with an 830W budget, while C9300-24P-A is the PoE+ model with a 715W AC default supply.
- For C9300-24U-A vs C9300-48U-A, the comparison is port density and platform capacity: the 48U model has 48 UPOE ports and higher listed switching and forwarding figures.
- The which model to choose check should start with UPOE versus PoE+, Network Advantage versus Essentials, and 24-port versus 48-port access density because those are the confirmed differences in the comparison table.
Selection Guide
1. Select it for 24-port UPOE access
Choose C9300-24U-A when the bill of materials needs a 24-port Catalyst 9300 UPOE switch with Network Advantage and modular uplink selection.
2. Keep Essentials separate
Use C9300-24U-E only when the same 24-port UPOE hardware should be ordered with Network Essentials instead of Network Advantage.
3. Avoid PoE+ substitution
Move to C9300-24P-A only when the deployment requirement is PoE+ access, because it changes the powered-port profile and default power supply plan.
4. Step up for 48 UPOE ports
Specify C9300-48U-A when the access layer needs 48 UPOE downlink ports in one Catalyst 9300 chassis rather than the 24-port C9300-24U profile.
PoE Power Planning
|
Planning Item |
Cisco Confirmed Value |
Order Impact |
|---|---|---|
|
Default PoE budget |
C9300-24U is listed with 830W available PoE and a PWR-C1-1100WAC-P default supply |
Match the endpoint count and power draw to the 830W switch-level budget |
|
Power supply slots |
Catalyst 9300 switches use two internal power supply module slots |
Decide whether the second slot needs a redundant supply or a blank module |
|
UPOE versus PoE+ |
C9300-24U is the Cisco UPOE model, while C9300-24P is the PoE+ model |
Prevent a lower-power PoE+ order line from replacing a UPOE requirement |
|
StackPower |
C9300-24U supports StackPower |
Add StackPower cables only when the stack power design requires shared power |
Ordering Checklist
|
Check Item |
What to Confirm |
Why It Matters |
|---|---|---|
|
Order identity |
C9300-24U-A with Network Advantage |
Prevents a C9300-24U-E Essentials substitution while preserving the same 24-port UPOE hardware profile |
|
UPOE endpoint plan |
24 x 10/100/1000 Cisco UPOE ports and endpoint power draw |
Confirms the order is for Cisco UPOE access instead of a PoE+ switch such as C9300-24P-A |
|
Uplink selection |
Selected C9300-NM module or C9300-NM-BLANK when uplink ports are not installed |
Keeps the modular uplink slot and airflow requirement explicit in the bill of materials |
|
Power bay plan |
PWR-C1-1100WAC-P default supply, 830W PoE budget, and second power-supply slot contents |
Aligns the powered-access budget with the physical power-supply configuration |
|
Stack integration |
StackWise-480 cable length and StackPower cable requirement |
Matches stack data and shared-power accessories to the intended Catalyst 9300 stack design |
|
Subscription alignment |
C9300-DNA-A-24 term length if Cisco DNA Advantage software is ordered |
Keeps the Advantage software entitlement tied to the 24-port copper Catalyst 9300 order |
Optional Add-ons
|
Model |
Description |
|---|---|
|
C9300-NM-4G |
Catalyst 9300 4 x 1GE SFP network module |
|
C9300-NM-8X |
Catalyst 9300 8 x 10G/1G SFP+ network module |
|
C9300-NM-2Q |
Catalyst 9300 2 x 40GE QSFP network module |
|
C9300-NM-2Y |
Catalyst 9300 2 x 25G/10G/1G SFP28 network module |
|
C9300-NM-4M |
Catalyst 9300 4 x 10G/mGig copper network module |
|
PWR-C1-1100WAC-P= |
1100W AC Platinum-rated power supply spare |
|
PWR-C1-1900WAC-P= |
1900W AC Platinum-rated power supply spare |
|
STACK-T1-50CM= |
Cisco StackWise-480/1T 50 cm stacking cable spare |
|
STACK-T1-1M= |
Cisco StackWise-480/1T 1 m stacking cable spare |
|
CAB-SPWR-30CM= |
Cisco Catalyst StackPower cable 30 cm spare |
|
CAB-SPWR-150CM= |
Cisco Catalyst StackPower cable 150 cm spare |
Specifications
Packaging weight and dimensions included:| Weight | 19.43 kg |
|---|---|
| Dimensions | 56 × 54 × 24 cm |
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Brand | Cisco | Product family | Cisco Catalyst 9300 Series |
| Product ID | C9300-24U-A | Base hardware model | C9300-24U |
| Product type | Stackable access switch with modular uplinks | Network license | Network Advantage |
| Access ports | 24 x 10/100/1000 Cisco UPOE copper ports | Cisco DNA subscription | C9300-DNA-A-24 Advantage 24-port term license family |
| PoE budget with default supply | 830W | Default power supply | PWR-C1-1100WAC-P |
| Minimum software release | Cisco IOS XE Everest 16.5.1a | Power supply slots | 2 internal power supply module slots |
| Uplink architecture | Optional hot-swappable Cisco Catalyst 9300 network module | Network module included | Default switch configuration does not include the network module |
| Supported network modules | C9300-NM-4G, C9300-NM-8X, C9300-NM-2Q, C9300-NM-2Y, C9300-NM-4M | Fan modules | 3 field-replaceable fans |
| Stacking architecture | StackWise-480 | StackPower | Supported |
| Switching capacity | 208 Gbps standalone | Switching capacity with stacking | 688 Gbps |
| Forwarding rate | 154.76 Mpps standalone | Forwarding rate with stacking | 511.90 Mpps |
| DRAM | 8 GB | Flash | 16 GB |
| MAC addresses | 32,000 | IPv4 routes | 32,000 |
| VLAN IDs | 4094 | Jumbo frames | 9198 bytes |
| Dimensions | 1.73 x 17.5 x 19.2 in. (4.4 x 44.5 x 48.8 cm) | Weight | 16.63 lb (7.54 kg) |
Get More Information
Need pricing, stock, or shipping details for the C9300-24U-A ? Layer23-Switch can help you check current availability, lead time, and delivery options for this. Send us the part number, quantity, and destination country via live chat or email sales@layer23-switch.com for a fast quotation.
Quality Certifications
Customer Reviews
Questions & Answers
-
Who needs C9300-24U-A for 1G copper UPOE and Network Advantage?
-
What does the A suffix mean in C9300-24U-A?
-
Can C9300-24U-A power high-draw access devices?
-
How is C9300-24U-A different from C9300-24H-A?
-
Does C9300-24U-A fit Network Advantage routed access with UPOE?
-
Can C9300-24U-A use StackPower?
-
When is C9300-24U-A the wrong SKU?
-
What Network Advantage and StackPower details matter for C9300-24U-A?
Warranty
Layer23-Switch.com offers genuine, high-quality ICT products at competitive wholesale prices—ensuring exceptional value without compromising quality.
All items are brand new, original, and factory-sealed.
Upon request, each unit can be fully tested and verified by a Cisco CCIE-certified engineer to ensure perfect working condition before shipment.
Our Cisco CCIE-certified experts provide free professional support via phone, email, online chat, or remote login—helping you deploy and troubleshoot with confidence.
If you are not satisfied with your purchase, you may request an exchange or full refund. Our customer service team will guide you through the return process quickly and smoothly. Visit Return Policy page for more information.
We support multiple secure payment and logistics options, backed by industry-leading verification:
Visit How to Pay page for more information
Extended, Worry-Free Warranty Coverage Factory New Sealed Enterprise Hardware:
· 3 Years Factory New Sealed
Visit Warranty Policy page for more information
Device Authenticity & Lifecycle Verification
Verify Cisco hardware by serial number and check lifecycle status before deployment.
Standard Services
Personalized Service, Superior Product Maintenance for Ultimate Satisfaction.
- Projects and Technical Support
- Easy Purchasing Supply
- Product Lifecycle Protection
- Exclusive F3 Team Support
Customized Support for Your Needs with CCIE, HCIE, HPE ASE, etc.
We checked the product carefully on arrival. No issues found.
We’ve never had a reorder go wrong with Layer23. That’s saying something.
Layer23 shipped ahead of the quoted lead time. Pleasant surprise.
Verified genuine. We only buy authentic gear.
Solid shipping. No damage. Reliable.
