C1300-48T-4X – 48x1G Data Ports – 4x10G SFP+ Uplinks – Stackable Access Switch
Shop Expert-Recommended Accessories for the C1300-48T-4X
Explore optics, stacking accessories, modules, and power supplies—all verified by our engineers for use with this model.-
SFP-10G-SR-S
10GBASE-SR SFP+ - S-Class - 400m OM4 MMFOriginal price was: $853.95.$52.00Current price is: $52.00. -
SFP-10G-LR-S
10GBASE-LR SFP+ - S-Class - 10km SMFOriginal price was: $2,439.88.$150.00Current price is: $150.00. -
GLC-SX-MMD
1000BASE-SX SFP - MMF 850nm - DOMOriginal price was: $633.46.$59.00Current price is: $59.00. -
GLC-LH-SMD
1000BASE-LX/LH SFP - 10km SMF / 550m MMF - DOMOriginal price was: $1,260.58.$95.80Current price is: $95.80.
Why Layer23-Switch
Stocked, Shipped and Supported by One Team
Ships in 1 Business Day
In-stock orders leave our Hong Kong or U.S. warehouse within 1 business day after payment, with tracking by email.
LSCare Warranty
3years on enterprise equipment
Free CCIE Support
Certified engineers help before and after you buy. Reply within 1 business day by email or live chat.
Verify Before You Pay
100%factory-sealed
Get label and serial photos before shipment, and check every serial number with Cisco.
C1300-48T-4X Description
The C1300-48T-4X is a Cisco Catalyst 1300 Series managed Layer 3 switch for branch and small-business wiring closets whose 48 wired endpoints need no PoE. The switch pairs 48 Gigabit RJ-45 ports with four 10G SFP+ uplinks, switches 176 Gbps at 130.94 Mpps, and cools with one fan rated 29.7 dBA at 25°C. Hardware stacking joins up to eight C1300 Family 1 switches, and dynamic routing stops at RIP v2 because OSPF runs only on C1300X models.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
C1300-48T-4X |
|
RJ-45 ports |
48 x 10/100/1000 Gigabit Ethernet |
|
Uplink ports |
4 x 10G SFP+ |
|
Total ports |
48 x Gigabit Ethernet + 4 x 10G |
|
Power dedicated to PoE |
No PoE output (data-only switch) |
|
Switching capacity |
176 Gbps |
|
Forwarding rate |
130.94 Mpps (64-byte packets) |
|
Packet buffer |
1.5 MB, shared across all ports |
|
Hardware stacking |
Up to 8 units, C1300 Family 1 only |
|
Dynamic routing |
RIP v2 and policy-based routing |
|
Power supply |
Internal universal, 100-240V 50-60 Hz |
|
Fan modules |
1 fan, 29.7 dBA at 25°C |
|
Weight |
4.35 kg (9.59 lb) |
Product Performance
Key Features
The four SFP+ slots carry 10G uplinks until the switch joins a stack. Stacking turns selected slots into stack ports that carry only traffic between members, and at least two must be enabled. A stacked unit therefore keeps no more than two SFP+ slots for uplinks.
Up to eight C1300 Family 1 switches run as one system with a single IP address and hardware failover. Eight units of this model would bring 416 ports including uplinks, which is more than the 400 ports one stack can manage.
Worst-case draw is 40.01W at 110V, with 136.50 BTU/hr of heat for the closet to remove. A single fan cools the chassis at 29.7 dBA at 25°C.
Application Scenarios
In a branch office, the switch connects up to 48 desktop PCs, printers and docking stations over Gigabit copper and sends their traffic to the site core on a 10G SFP+ uplink.
A small business that fills one closet and adds a second can stack the new C1300 Family 1 switch with the first, and both are then managed through one IP address.
Hotels and office waiting rooms place wired guest ports in a Guest VLAN while staff ports use 802.1X or web authentication. Visitors and employees then share the switch but not a network segment.
Product Comparison
|
Parameter |
C1300-48T-4X | |||
|---|---|---|---|---|
|
RJ-45 ports |
48 x Gigabit Ethernet |
48 x Gigabit Ethernet, 30W PoE+ |
48 x Gigabit Ethernet |
48 x Gigabit Ethernet |
|
Power dedicated to PoE |
Not applicable |
375W |
Not applicable |
Not applicable |
|
Uplink ports |
4 x 10G SFP+ |
4 x 10G SFP+ |
4 x 1G SFP |
4 x SFP28 (10G uplink, 25G for stacking only) |
|
Switching capacity |
176 Gbps |
176 Gbps |
104 Gbps |
176 Gbps |
|
Forwarding rate |
130.94 Mpps |
130.94 Mpps |
77.38 Mpps |
130.95 Mpps |
|
Acoustic noise |
1 fan, 29.7 dBA at 25°C |
1 fan, 37.3 dBA at 25°C |
1 fan, 29.7 dBA at 25°C |
1 fan, 21.6 dBA at 25°C |
|
Dynamic routing |
RIP v2 |
RIP v2 |
RIP v2 |
RIP v2, OSPF v2 and v3 |
|
Hardware stacking |
C1300 Family 1, up to 8 units |
C1300 Family 1, up to 8 units |
Not supported |
C1300X Family, up to 8 units |
C1300-48T-4X and C1300-48P-4X share 48 Gigabit copper ports, four 10G SFP+ uplinks and 176 Gbps of switching, but C1300-48T-4X has no PoE output, while C1300-48P-4X shares 375W across 48 PoE+ ports for phones, cameras or access points. Where the aggregation link runs at 1G, C1300-48T-4G keeps the same 48 copper ports on four 1G SFP uplinks at 104 Gbps, but it cannot join a hardware stack. When the design needs OSPF v2 or v3 rather than RIP v2, C1300X-48T-4X adds it on four SFP28 slots that run 10G uplinks; because it stacks only within the C1300X Family, it cannot join an existing C1300 Family 1 stack.
Ordering Checklist
- Stack members: Order stack partners from C1300 Family 1 only, such as C1300-24T-4X, C1300-48P-4X or C1300-48FP-4X, up to eight units. A C1300X or C1300 Family 2 switch on the same order cannot join the stack.
- Stack links: Add at least two DAC cables or 10G SFP+ modules per stacked unit, such as SFP-H10GB-CU1M; DAC is the preferred stack medium. Third-party and RJ45 SFPs are not assured to work as stack links.
- Uplink optics: Add SFP+ modules or cables from the Catalyst 1300 supported list, such as SFP-10G-SR, SFP-10G-LR or SFP-H10GB-CU3M. The switch ships without optics, so an uplink without a module on the order stays dark.
- Power cord: Keep the included power cord or select NO-POWER-CORD. A switch ordered with NO-POWER-CORD arrives without a cord and needs one sourced locally.
Optional Add-ons
|
Model |
Description |
|---|---|
|
CAB-CONSOLE-RJ45 |
Console cable, 6 feet, RJ-45 connector |
|
CAB-CONSOLE-USB-C |
Console cable with USB Type C connector |
|
RCKMNT-1RU-1K= |
1RU rack-mount kit for C1000, C1200 and C1300 24-port and 48-port models |
|
10G SFP+ module for multimode fiber, 26 m to 400 m | |
|
10G SFP+ module for multimode fiber, 26 m to 400 m | |
|
10G SFP+ module for single-mode fiber, 10 km | |
|
10G SFP+ module for single-mode fiber, 10 km | |
|
10G SFP+ module for single-mode fiber, 40 km | |
|
SFP-10G-T-X |
10G SFP+ copper module for CAT6A/CAT7 or better, 30 m |
|
10G copper coax SFP+ cable, 1 m | |
|
10G copper coax SFP+ cable, 3 m | |
|
10G copper coax SFP+ cable, 5 m | |
|
10G active optical cable, 1 m | |
|
10G active optical cable, 3 m |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | C1300-48T-4X | Product type | Fixed managed Layer 3 Gigabit Ethernet switch, rack-mountable |
| Total ports | 48 x Gigabit Ethernet + 4 x 10G | RJ-45 ports | 48 x 10/100/1000 Gigabit Ethernet |
| Uplink ports | 4 x 10G SFP+ | Power dedicated to PoE | No PoE output (data-only switch) |
| Switching capacity | 176 Gbps, wire speed and nonblocking | Forwarding rate | 130.94 Mpps (64-byte packets) |
| Packet buffer | 1.5 MB, dynamically shared across all ports | Hardware stacking | Up to 8 C1300 Family 1 switches, single IP address, hardware failover; up to 400 ports per stack |
| Stack ports | SFP+ ports reconfigured as stack ports, minimum two; 10G links, DAC cables preferred | Layer 3 routing | IPv4/IPv6 wire-speed routing, RIP v2, policy-based routing, DHCP server, DHCP relay, UDP relay |
| VLANs | Up to 4094 (4078 to 4094 reserved for internal use) | Spanning tree | MSTP 16 instances; PVST+ and Rapid PVST+ 126 instances |
| Link aggregation | LACP, up to 8 groups with up to 8 ports per group | Jumbo frames | Up to 9000 bytes (default MTU 2000 bytes) |
| Multicast | IGMP v1/v2/v3 snooping, MLD v1/v2 snooping | Port mirroring | Up to 8 source ports to 1 destination port |
| VLAN features | Private VLAN, Guest VLAN, unauthenticated VLAN, RADIUS dynamic VLAN, Voice VLAN, Auto Smartports | Security | 802.1X, web authentication, DHCP snooping, IP Source Guard, DAI, port security, storm control, IPv6 First Hop Security, RADIUS, TACACS+, SSH, BPDU Guard, Root Guard |
| ACL | Ingress, egress and time-based ACLs | QoS | 8 hardware queues; strict priority and WRR; 802.1p, DSCP and IP precedence classification; ingress policing and egress shaping |
| Management | Cisco Business Dashboard with embedded probe, Cisco Business mobile app, Cisco Network Plug and Play, Web UI (HTTP/HTTPS), SNMP v1/v2c/v3, CLI | Firmware | Dual images; upgrade by SCP, TFTP or Web UI |
| Console port | Cisco standard RJ-45 console port and USB Type C port | Flash | 1GB SLC |
| CPU | ARM dual-core at 1.5 GHz | DRAM | 1 GB DDR4 |
| Cabling | 1000BASE-T: UTP Category 5e or better | Energy efficiency | IEEE 802.3az EEE on copper Gigabit Ethernet ports, energy detect, cable length detection, time-based port operation |
| Default power supply | Internal universal, 100-240V 50-60 Hz | System power consumption (worst case) | 40.01W at 110V; 39.77W at 220V |
| Idle power consumption | 13.12W at 110V; 12.93W at 220V | Heat dissipation | 136.50 BTU/hr |
| Number of fans | 1 | Acoustic noise | 29.7 dBA at 25°C |
| MTBF | 1,473,382 hours at 25°C | Dimensions (H x W x D) | 444.3 x 288 x 43.94 mm (17.49 x 11.33 x 1.73 in) |
| Weight | 4.35 kg (9.59 lb) | Operating temperature | -5°C to 50°C (23°F to 122°F); cold start minimum 0°C (32°F) |
| Storage temperature | -25°C to 70°C (-13°F to 158°F) | Operating humidity | 10% to 90% relative, noncondensing |
| Certifications | UL (UL 62368), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A | Package contents | Switch, power cord (omitted with NO-POWER-CORD), mounting kit with 19-inch brackets, pointer card |
Quality Certifications
Customer Reviews
Questions & Answers
-
Can C1300-48T-4X be stacked?
-
How far does Layer 3 go on C1300-48T-4X and how is it managed?
-
What access security can be configured on C1300-48T-4X?
-
Which IPv6 security checks does C1300-48T-4X offer?
-
Does C1300-48T-4X support zero-touch deployment?
-
How can C1300-48T-4X be managed beyond the web interface?
