C9300L-24P-4G-A Description
The C9300L-24P-4G-A is a Cisco Catalyst 9300L fixed-uplink stackable access switch for wiring closets that power IP phones and access points. The switch has 24 10/100/1000 Mbps PoE+ ports, four fixed 1G SFP uplinks, a 505W default PoE budget on the 715W AC supply and 56 Gbps of switching capacity. The -A suffix carries Network Advantage, and stacking uses StackWise-320 with Catalyst 9300L or 9300LM switches at the same license level.
Quick Specs
|
Parameter |
Specification |
|---|---|
|
Product ID |
C9300L-24P-4G-A |
|
Product type |
Fixed-uplink stackable access switch |
|
Downlink ports |
24 x 10/100/1000 Mbps PoE+ copper ports |
|
Uplink ports |
4 x 1G SFP fixed uplink ports |
|
Network license |
Network Advantage |
|
Default power supply |
PWR-C1-715WAC-P |
|
Default PoE budget |
505W with 715W AC power supply |
|
Expanded PoE budget |
720W with supported secondary power supply configuration |
|
Stacking architecture |
StackWise-320 |
|
Switching capacity |
56 Gbps standalone; 376 Gbps with stacking |
|
Forwarding rate |
41.66 Mpps standalone; 279.76 Mpps with stacking |
Product Performance
Key Features
On the default 715W AC supply the switch has 505W for PoE. A second power supply raises the budget to 720W, which covers 30W on all 24 ports.
The four SFP uplinks are built into the chassis and there is no network module slot. Uplink speed is set by the switch rather than by a swappable module.
Up to eight members stack over 320 Gbps links, and Catalyst 9300L and 9300LM switches can mix in one stack at the same license level.
The -A tier adds BGP, VRF, VXLAN, LISP, Cisco TrustSec and MPLS, and lifts the 1,000-route OSPF limit that applies at Network Essentials.
Two internal supply slots take 715W or 1100W AC supplies and a 715W DC supply, so closets fed by DC power are covered.
Standalone, the switch forwards 41.66 Mpps with 56 Gbps of switching capacity. In a stack the figures reach 279.76 Mpps and 376 Gbps.
Application Scenarios
In a branch or campus closet with up to 24 phones, access points or cameras, the switch powers them from its PoE+ ports and hands traffic off over 1G SFP fiber.
A campus that runs VRF, VXLAN or TrustSec segmentation down to the access layer can place the switch there with Network Advantage routing and segmentation features.
When a floor adds PoE+ capacity, the switch joins an existing StackWise-320 stack of Catalyst 9300L or 9300LM switches at the same license level.
Product Comparison
|
Parameter |
C9300L-24P-4G-A | |||
|---|---|---|---|---|
|
Downlink ports |
24 x 10/100/1000 Mbps |
24 x 10/100/1000 Mbps |
24 x 10/100/1000 Mbps |
24 x 10/100/1000 Mbps |
|
PoE support |
PoE+ |
PoE+ |
PoE+ |
Not supported |
|
Available PoE power (default) |
505W |
505W |
505W |
Not supported |
|
Available PoE power (maximum) |
720W |
720W |
720W |
Not supported |
|
Uplink ports |
4 x 1G SFP |
4 x 1G SFP |
4 x 10G/1G SFP+ |
4 x 1G SFP |
|
Network license |
Network Advantage |
Network Essentials |
Network Advantage |
Network Advantage |
|
Stack bandwidth |
320 Gbps (StackWise-320) |
320 Gbps (StackWise-320) |
320 Gbps (StackWise-320) |
320 Gbps (StackWise-320) |
|
Switching capacity |
56 Gbps; 376 Gbps with stacking |
56 Gbps; 376 Gbps with stacking |
128 Gbps; 448 Gbps with stacking |
56 Gbps; 376 Gbps with stacking |
|
Default power supply |
PWR-C1-715WAC-P |
PWR-C1-715WAC-P |
PWR-C1-715WAC-P |
PWR-C1-350WAC-P |
C9300L-24P-4G-A and C9300L-24P-4G-E are the same 24-port PoE+ switch with four fixed 1G SFP uplinks and a 505W default budget; the difference is Network Advantage, which adds VXLAN, LISP, Cisco TrustSec, MPLS and OSPF without a route limit over Network Essentials. A site that needs none of these can order C9300L-24P-4G-E, but Cisco lists no Advantage-to-Essentials downgrade, while the reverse path is the C9300L-LIC= upgrade, such as C9300L-24-E-A-3. Uplinks above 1G call for C9300L-24P-4X-A, with four 10G/1G SFP+ ports and 128 Gbps against 56 Gbps. Closets without powered devices can use C9300L-24T-4G-A, which has a 350W supply and no PoE.
PoE Power Planning
|
Planning Item |
Cisco Confirmed Value |
Order Impact |
|---|---|---|
|
PoE standard |
PoE+ on 24 x 10/100/1000 Mbps access ports |
Match endpoint power draw to the confirmed PoE+ access profile |
|
Default PoE budget |
505W with the default PWR-C1-715WAC-P power supply |
Keep endpoint count and power draw inside the default budget when no second supply is ordered |
|
720W PoE ceiling |
24 PoE+ ports are limited by port number and 30W port rating |
Treat 720W as the all-port PoE+ planning ceiling for this 24-port model |
|
Power supply check |
Cisco lists PWR-C1-715WAC-P, PWR-C1-1100WAC-P, and PWR-C1-715WDC as supported C9300L supply options |
Confirm AC or DC power design, spare supply, and regional power cord with the final bill of materials |
Ordering Checklist
- Subscription: Add a 24-port Network Advantage-tier term, Cisco Catalyst or Cisco DNA Advantage for 3, 5 or 7 years. Subscriptions are mandatory on new orders and must match the -A tier of the switch.
- Second power supply: A second supply matching PWR-C1-715WAC-P is selected by default; C9300L-SPS-NONE removes it. Without it the PoE budget stays at 505W instead of 720W.
- Stacking: C9300L-STACK-KIT is selected by default with a 50 cm cable; choose STACK-T3-1M or STACK-T3-3M for longer runs. Fixed-uplink C9300L switches stack with their own kit, not the C9300 STACK-T1 cables.
- Power cords: Select the cord type for the destination country; two cords ship and the default is North America, which may not match the site.
Optional Add-ons
|
Model |
Description |
|---|---|
|
Stack kit for Cisco Catalyst 9300L fixed-uplink switch stacking | |
|
50 cm StackWise-320 data stack cable for Catalyst 9300L stacking | |
|
1 m StackWise-320 data stack cable for Catalyst 9300L stacking | |
|
STACK-T3-3M |
3 m StackWise-320 data stack cable for Catalyst 9300L stacking |
|
715W AC Platinum-rated power supply spare | |
|
1100W AC Platinum-rated power supply spare | |
|
PWR-C1-715WDC= |
715W DC power supply spare |
|
C9300L Cisco DNA Advantage 24-port 3-year term license | |
|
C9300L-DNA-A-24-5Y |
C9300L Cisco DNA Advantage 24-port 5-year term license |
|
C9300L-DNA-A-24-7Y |
C9300L Cisco DNA Advantage 24-port 7-year term license |
Specifications
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product ID | C9300L-24P-4G-A | Product type | Fixed-uplink stackable access switch |
| Network license | Network Advantage | Downlink ports | 24 x 10/100/1000 Mbps PoE+ copper ports |
| Uplink ports | 4 x 1G SFP fixed uplink ports | Modular uplinks | No for C9300L fixed-uplink models |
| Default power supply | PWR-C1-715WAC-P | Default PoE budget | 505W with 715W AC power supply |
| Supported power supply options | PWR-C1-350WAC, PWR-C1-715WAC, PWR-C1-715WAC-P, PWR-C1-1100WAC-P, PWR-C1-1900WAC-P, PWR-C1-715WDC | Power supply slots | 2 internal power supply module slots |
| Stacking architecture | StackWise-320 | Supported stack members | Catalyst 9300L and C9300LM models with the same license level |
| Switching capacity | 56 Gbps standalone | Switching capacity with stacking | 376 Gbps |
| Forwarding rate | 41.66 Mpps standalone | Forwarding rate with stacking | 279.76 Mpps |
| MAC addresses | 32,000 | IPv4 routes | 32,000 total with 24,000 direct and 8,000 indirect routes |
| Packet buffer | 16 MB for C9300L 24- and 48-port Gigabit Ethernet models | Flexible NetFlow entries | 64,000 flows on C9300L 24- and 48-port Gigabit Ethernet models |
| DRAM | 8 GB | Flash | 16 GB |
| VLAN IDs | 4094 | Jumbo frames | 9198 bytes |
| Weight | 6.81 kg (14.99 lb) with default power supply | MTBF | 346,940 hours |
Quality Certifications
Customer Reviews
Questions & Answers
-
Can C9300L-24P-4G-A be stacked?
-
What does Network Advantage on C9300L-24P-4G-A include?
-
Which IOS XE baseline does the datasheet give for C9300L-24P-4G-A?
-
Which MACsec key length can C9300L-24P-4G-A use?
-
Which VXLAN and MPLS roles can C9300L-24P-4G-A take under Network Advantage?
-
Does C9300L-24P-4G-A support StackPower?
-
How does C9300L-24P-4G-A build its StackWise-320 bandwidth?
-
What power does a PoE+ port on C9300L-24P-4G-A give a device?
-
How many MAC addresses and routes does C9300L-24P-4G-A support?
-
Are the fans of C9300L-24P-4G-A field-replaceable?
