C9300-24T-E – 24x1G Data Ports – Modular Uplink – Network Essentials

Brand: Cisco Category: Catalyst 9300 Switches Availability:
In Stock
Model: C9300-24T-E
Cisco SN CheckSN verification before shipment.Verify authenticity3-Year WarrantyExtended, enterprise-gradeWarranty terms14-Day ReturnsStraightforward RMA processReturn policy
4.912 reviews9 Questions7 sold this month
List Price: $7,607.35 78% OFF
$1,673.44
Price Alert
Condition
Related
Subscription C9300-DNA-E + $499.86 This item requires a mandatory DNA. Subtotal Price $2,173.30
Quantity
Shipping Express Shipping 2-6 Business Days, via UPS, FedEx, DHL and more
Trusted & Secure Payments

Shop Expert-Recommended Accessories for the C9300-24T-E

Explore optics, stacking accessories, modules, and power supplies—all verified by our engineers for use with this model.
  • SFP-10G-SR-S

    SFP-10G-SR-S

    10GBASE-SR SFP+ - S-Class - 400m OM4 MMF
    Original price was: $853.95.Current price is: $52.00.
  • SFP-10G-SR

    SFP-10G-SR

    10GBASE-SR SFP+ - 850nm MMF - 400m OM4
    Original price was: $1,213.85.Current price is: $91.68.
  • SFP-10G-LR-S

    SFP-10G-LR-S

    10GBASE-LR SFP+ - S-Class - 10km SMF
    Original price was: $2,439.88.Current price is: $150.00.
  • SFP-10G-LR

    SFP-10G-LR

    10GBASE-LR SFP+ - 1310nm SMF - 10km Reach
    Original price was: $4,873.66.Current price is: $149.00.
  • SFP-25G-SR-S

    SFP-25G-SR-S

    25GBASE-SR SFP28 - 850nm MMF - 100m OM4
    Original price was: $1,213.85.Current price is: $258.00.
  • SFP-10/25G-LR-S

    SFP-10/25G-LR-S

    10/25GBASE-LR SFP28 - 10 km G.652 SMF - 0 to 70°C Commercial Temperature
    Original price was: $2,787.19.Current price is: $431.00.
  • QSFP-40G-SR4

    QSFP-40G-SR4

    40G SR4 QSFP - MPO-12 MMF - 4x10G Breakout
    Original price was: $3,653.72.Current price is: $126.00.
  • GLC-LH-SMD

    GLC-LH-SMD

    1000BASE-LX/LH SFP - 10km SMF / 550m MMF - DOM
    Original price was: $1,260.58.Current price is: $95.80.
  • GLC-TE

    GLC-TE

    1000BASE-T SFP - RJ-45 Cat5 Copper - 100m Reach
    Original price was: $570.10.Current price is: $70.00.
  • GLC-SX-MMD

    GLC-SX-MMD

    1000BASE-SX SFP - MMF 850nm - DOM
    Original price was: $633.46.Current price is: $59.00.
  • STACK-T1-50CM

    STACK-T1-50CM

    50cm Type 1 StackWise Cable - C9300/C9300X Data Stack - 480G/1T
    Original price was: $121.99.Current price is: $70.00.
  • STACK-T1-1M

    STACK-T1-1M

    1m Type 1 StackWise Cable - C9300/C9300X Data Stack - 480G/1T
    Original price was: $252.03.Current price is: $140.00.
  • STACK-T1-3M

    STACK-T1-3M

    3m Type 1 StackWise Cable - C9300/C9300X Data Stack - 480G/1T
    Original price was: $378.07.Current price is: $200.00.
  • C9300-NM-2Y

    C9300-NM-2Y

    2x25G/10G/1G SFP28 Ports - Catalyst 9300 Module
    Original price was: $3,227.37.Current price is: $1,122.00.
  • C9300-NM-2Q

    C9300-NM-2Q

    2x40G QSFP+ Uplinks - Catalyst 9300 Module
    Original price was: $3,213.50.Current price is: $800.00.
  • C9300-NM-4G

    C9300-NM-4G

    4x1GE SFP Ports - Catalyst 9300 Module
    Original price was: $680.51.Current price is: $231.00.
  • C9300-NM-4M

    C9300-NM-4M

    4x10G/mGig Copper Ports - Catalyst 9300 Module
    Original price was: $1,890.30.Current price is: $626.00.
  • C9300-NM-8X

    C9300-NM-8X

    8x10G/1G SFP+ Uplinks - Network Module - Catalyst 9300
    Original price was: $3,213.50.Current price is: $761.00.
  • PWR-C1-350WAC-P

    PWR-C1-350WAC-P

    350W AC PSU - Catalyst 9300 C1 - Platinum Rated
    Original price was: $819.12.Current price is: $166.00.

Why Layer23-Switch

Stocked, Shipped and Supported by One Team

Founded
Customers
Units shipped
Countries
Cisco switches in stock at the Layer23-Switch warehouse
Play

Inventory You Can See

Cisco stock on hand
Models ready to ship
Warehouse space

Ships in 1 Business Day

In-stock orders leave our Hong Kong or U.S. warehouse within 1 business day after payment, with tracking by email.

DHL FedEx UPS Duties included: US · CA · UK

LSCare Warranty

3years on enterprise equipment

  • Advance replacement for in-stock models
  • New unit for dead-on-arrival
  • 14-day returns on sealed items

Free CCIE Support

Certified engineers help before and after you buy. Reply within 1 business day by email or live chat.

Part number check Configuration Troubleshooting

Verify Before You Pay

100%factory-sealed

Get label and serial photos before shipment, and check every serial number with Cisco.

C9300-24T-E Description

The C9300-24T-E is a Cisco Catalyst 9300 Series stackable access switch for copper wiring closets that need Layer 2 switching and basic routed access. The switch has 24 10/100/1000 copper ports, a modular uplink slot, 208 Gbps of switching capacity and a default 350W AC supply, and carries the Network Essentials license. Network Essentials covers OSPF up to 1,000 routes and MACsec-128 but not BGP, VRF, VXLAN or Cisco TrustSec, and the ports provide no PoE.

Quick Specs

Parameter

Specification

Product ID

C9300-24T-E

Total ports

24x 10/100/1000 copper (data only, no PoE)

Uplink

Modular uplink bay (network module ordered separately)

Network license

Network Essentials

Switching capacity

208 Gbps (688 Gbps stacked)

Forwarding rate

154.76 Mpps (511.90 Mpps stacked)

Stacking

StackWise-480, up to 8 members, StackPower supported

Default power supply

PWR-C1-350WAC-P, 350W AC

Optional second power supply

PWR-C1-715WAC-P or PWR-C1-1100WAC-P

Minimum software release

Cisco IOS XE Release 16.5.1a

Chassis dimensions (with default supply)

1.73 x 17.5 x 17.7 in

Weight (with fans and default supply)

7.27 kg (16.03 lb)

Product Performance

Switching Capacity
Forwarding Rate
StackWise-480 Maximum Stack Size

Key Features

Essentials Routing Scope

Layer 2 switching plus RIP, EIGRP Stub and OSPF up to 1,000 routes gives an access layer enough routing to hand off to distribution or core.

Empty Uplink Slot

The slot accepts the C9300-NM-4G for 4x 1G up to the C9300-NM-8X for 8x 10G/1G SFP+. Uplink cost can match the closet’s needs.

Access Security At This Level

802.1X, MACsec-128, CoPP and model-driven telemetry are included, so authentication and basic visibility need no license upgrade.

Stacking At One License Level

Up to eight units join a StackWise-480 stack at 480 Gbps, and every member must run Network Essentials.

StackPower Ring

Up to four stacked switches can form a StackPower ring, extendable to eight with the XPS-2200 external supply. A member that loses its supply keeps drawing power from the ring.

Redundant Fans

Three field-replaceable fans run N+1 redundant at 20 cfm. A failed FAN-T2= can be swapped in place.

Application Scenarios

Layer 2 Closet Below Distribution

A closet that only forwards VLAN traffic can leave routing, segmentation and policy to the distribution switches above it.

Branch Office Copper Access

A branch wiring closet can connect desktops, VoIP phones with their own power and point-of-sale terminals, using VLANs and 802.1X for port control.

Stack Growth In A Closet

A closet that needs more copper ports can add another switch to an existing StackWise-480 stack of Network Essentials units.

Product Comparison

Parameter

C9300-24T-E

C9300-24T-A

C9300-48T-A

C9300-24P-A

Total 10/100/1000, Multigigabit copper or SFP fiber

24 ports data

24 ports data

48 ports data

24 ports PoE+

Uplink configuration

Modular uplinks

Modular uplinks

Modular uplinks

Modular uplinks

Network license

Network Essentials

Network Advantage

Network Advantage

Network Advantage

Default AC power supply

350W AC

350W AC

350W AC

715W AC

Available PoE power

No PoE

No PoE

No PoE

445W

Switching capacity

208 Gbps

208 Gbps

256 Gbps

208 Gbps

Forwarding rate

154.76 Mpps

154.76 Mpps

190.47 Mpps

154.76 Mpps

Stack bandwidth

480 Gbps

480 Gbps

480 Gbps

480 Gbps

C9300-24T-E and C9300-24T-A share the same 24 copper ports, modular uplink bay and 208 Gbps of switching capacity, and the difference is the license: Network Essentials lacks BGP, EIGRP, VRF, VXLAN and Cisco TrustSec, so a closet that needs any of them must move to C9300-24T-A, or upgrade an installed C9300-24T-E later with a C9300-LIC= term (C9300-24-E-A-3, -5 or -7) that cannot be placed on the switch order. Closets with more than 24 copper drops move to C9300-48T-A, with 48 ports and 256 Gbps of switching capacity on the same 350W supply. Powered endpoints need C9300-24P-A, which adds a 445W PoE budget on a 715W supply.

Ordering Checklist

  • Subscription tier: Select an Essentials term such as C9300-DNA-E-24 in 3, 5 or 7 years. The configurator defaults to Cisco DNA Advantage for 5 years, so change the tier to match the switch license.
  • Uplink module: Keep the default C9300-NM-8X, change it, or select C9300-NM-NONE. The default module is added to the order unless it is changed or removed.
  • Second power supply: A second PWR-C1-350WAC-P is selected by default; C9300-SPS-NONE removes it. The second supply is added to the order unless it is removed.
  • Stack cables: A default 50 cm StackWise cable (C9300-STACK-NONE removes it) and 30 cm StackPower cable (C9300-SPWR-NONE removes it) are added. Both cables are added whether or not the switch is stacked.
  • Power cords: Select the cord type for the destination country. The configurator defaults to North America cords, and two cords ship per switch.

Optional Add-ons

Add-on

Cisco PID

Purpose

Uplink Network Module

C9300-NM-4G

4x 1G SFP modular uplink module

Uplink Network Module

C9300-NM-4M

4x Multigigabit modular uplink module

Uplink Network Module

C9300-NM-8X

8x 10G/1G SFP+ modular uplink module

Uplink Network Module

C9300-NM-2Q

2x 40G QSFP+ modular uplink module

Uplink Network Module

C9300-NM-2Y

2x 25G/10G/1G SFP28 modular uplink module

Second Power Supply

PWR-C1-715WAC-P

715W AC redundant/replacement power supply

Second Power Supply

PWR-C1-1100WAC-P

1100W AC redundant/replacement power supply

Stacking Cable

STACK-T1-1M

1m StackWise stacking cable

Stacking Cable

STACK-T1-3M

3m StackWise stacking cable

C9300-24T-E Switch Rear Panel

The switch rear panel includes StackWise connectors, StackPower or XPS connectors, ports, fan modules, and power supply modules.

1

Ground connectors

7

StackPower connectors

2

USB3.0–SSD port

8

AC OK (input) status LED

3

BEACON LED

9

PS OK (output) status LED

4

CONSOLE (RJ-45 console port)

10

StackWise-480 port connectors

5

MGMT (RJ-45 10/100/1000 management port)

11

Power supply modules

6

Fan modules

–

–

Rear Panel of a Cisco Catalyst 9300 Series Switch

Components Delivered in the Shipping Box

The shipping box contains the model of the switch you ordered and other components needed for installation. Some components are optional, depending on your order.

1

Cisco Catalyst 9300 Series switch with optional network module1 (power supply and fan modules not shown)

9

Eight number-8 Phillips flat-head screws

2

AC power cord

10

Cable guide

3

Product documentation and compliance document

11

M4.0 x 20mm Phillips pan-head screw

4

Four rubber mounting feet

12

(Optional) RJ-45 console cable

5

Ground lug screw and ring terminal

13

(Optional) USB console cable

6

Two 19-inch mounting brackets

14

(Optional) StackWise-480/1T cable (0.5-meter, 1-meter, or 3-meter)

7

Four number-12 pan-head screws

15

(Optional) StackPower cable (0.3-meter or 1.5-meter)

8

Four number-10 pan-head screws

16

(Optional) StackWise-320 cable

cisco-catalyst-9300-switch-shipping-box

Specifications

Parameter Specification Parameter Specification
Product ID C9300-24T-E Network license Network Essentials
Total ports 24x 10/100/1000 copper, data only Default PoE budget Not a PoE Switch (Data Only)
Uplink Modular uplink bay (module ordered separately) Compatible network modules C9300-NM-4G, C9300-NM-4M, C9300-NM-8X, C9300-NM-2Q, C9300-NM-2Y
Switching capacity 208 Gbps Stacked switching capacity 688 Gbps (StackWise-480, 8 members)
Forwarding rate 154.76 Mpps Stacked forwarding rate 511.90 Mpps
Stacking StackWise-480, up to 8 members StackPower Supported
MAC addresses 32,000 entries IPv4 routes 32,000 (24,000 connected + 8,000 indirect)
IPv6 routes 16,000 entries Multicast routes 8,000 entries
QoS entries 5,120 ACL entries 5,120
DRAM / flash 8 GB / 16 GB VLAN IDs 4094
SVI total 1000 Jumbo frame size 9198 bytes
Default power supply PWR-C1-350WAC-P, 350W AC Optional second power supply PWR-C1-715WAC-P (715W) or PWR-C1-1100WAC-P (1100W)
Power supply input 100-240VAC 47-63Hz, IEC 320-C14 Power supply output (BTU/hr) 1,194 BTU/hr (350W supply)
Fan modules 3x field-replaceable, N+1 redundant, FAN-T2= Fan airflow 20 cfm
Chassis dimensions (H x W x D) 1.73 x 17.5 x 17.7 in (with default supply) Weight 7.27 kg (16.03 lb)
Operating temperature -5 to 45 C (up to 1500m) Storage temperature -40 to 70 C
Operating humidity 5%-90% non-condensing Operating altitude Up to 10,000 ft (3000m)
Acoustic noise 45 dB LpA typical / 48 dB LpA max MTBF 314,790 hours
Management port 10/100/1000 Ethernet mgmt, RJ-45 console, USB mini-Type B console USB / SSD support USB Type A 128MB-8GB flash; rear USB 3.0 SSD bay 120GB/240GB
Connector types RJ-45 (1000BASE-T, Cat 5E UTP) Minimum software release Cisco IOS XE Release 16.5.1a
Safety certifications UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950.1 EMC certifications FCC Part 15, EN 55032 Class A, CISPR 32 Class A, ICES-003 Class A
Environmental compliance RoHS 5

Quality Certifications

Customer Reviews

Write A Review
4.9
(12 reviews)
5 Stars
11
4 Stars
1
3 Stars
0
2 Stars
0
1 Stars
0
    Jacob Fischer
    Posted on 20/02/2026
    Verified Buyer
    5.0

    I’ve placed more orders with Layer23 than I can count. Always consistent.

    Amber Wu
    Posted on 20/02/2026
    Verified Buyer
    5.0

    Their customer success approach feels genuine, not scripted.

    Jason Liu
    Posted on 26/01/2026
    Verified Buyer
    5.0

    Their professionalism rivals the most established names in the industry.

    Michael Ross
    Posted on 25/06/2025
    Verified Buyer
    5.0

    Honest vendor. What you see is what you get. Brand new seals.

    Natalie Goodwin
    Posted on 22/05/2025
    Verified Buyer
    5.0

    License activation was straightforward; unit recognized SmartNet instantly.

Questions & Answers

  • Can C9300-24T-E be stacked?

    Yes. C9300-24T-E joins a StackWise-480 stack of up to 8 members at 480 Gbps, and every member must run Network Essentials. Up to 4 stacked switches can form a StackPower ring, extendable to 8 with the XPS-2200 external supply.

  • What does Network Essentials on C9300-24T-E include?

    Network Essentials on C9300-24T-E includes Layer 2 switching, RIP, EIGRP Stub, OSPF up to 1,000 routes, 802.1X, MACsec-128, CoPP and model-driven telemetry. BGP, VRF, VXLAN and Cisco TrustSec are not part of this tier.

  • What storage and humidity limits apply to C9300-24T-E?

    C9300-24T-E tolerates 5% to 90% non-condensing humidity in operation. Storage is rated from -40 to 70 C and up to 15,000 ft. The switch itself operates at altitudes up to 10,000 ft, so a high-altitude closet needs a check before mounting.

  • What is the BTU rating of the 1100W second supply for C9300-24T-E?

    A PWR-C1-1100WAC-P second supply in C9300-24T-E has an output rating of 3754 BTU/hr, and the PWR-C1-715WAC-P is rated at 2440 BTU/hr. With no PoE load, both supplies add redundancy only, so choose the supply for the closet's power feed and cooling capacity.

  • Which external storage can C9300-24T-E use for app hosting?

    C9300-24T-E takes a USB 3.0 SSD in the rear slot, either SSD-120G with 120 GB or SSD-240G with 240 GB. Both are orderable across the Catalyst 9300 family. The front USB Type A port accepts Cisco USB flash drives at 5V and 900 mA, but app-hosting storage uses the rear slot.

  • Does a Network Essentials subscription for C9300-24T-E include ThousandEyes?

    No. ThousandEyes Network and Application Synthetics (TE-EMBEDDED-T) comes by default only with 3, 5 or 7-year Cisco Catalyst or Cisco DNA Advantage subscriptions on Catalyst 9300 switches. A C9300-24T-E buyer who needs it must order the Advantage tier instead of the Essentials tier.

  • Which Cisco Catalyst subscription PID family matches the Network Essentials license on C9300-24T-E?

    C9300-24T-E pairs with the C9300-DNX-E-24 family for a Cisco Catalyst subscription and C9300-DNA-E-24 for Cisco DNA, each with a -3Y, -5Y or -7Y term suffix. The tier must be Essentials to match the built-in license, because the configurator defaults to Advantage.

  • Which StackPower cable lengths work with C9300-24T-E?

    C9300-24T-E accepts CAB-SPWR-30CM and CAB-SPWR-150CM StackPower cables. The StackWise data cables come as STACK-T1-50CM, STACK-T1-1M and STACK-T1-3M. Fixed-uplink Catalyst 9300L and 9300LM models have no StackPower, so these cables only apply to modular-uplink switches such as this one. Order the cables that match the ring layout planned for the closet.

  • How do I leave the uplink bay of C9300-24T-E empty?

    Select C9300-NM-NONE on the order to remove the default module, and install a C9300-NM-BLANK cover in the bay. The switch ships with the bay unpopulated, and no uplink module is included by default. The bay must carry the cover whenever no network module is fitted, so keep the cover with the switch until the team chooses an uplink module for the closet.

Warranty

100% Low Price Guarantee:

Layer23-Switch.com offers genuine, high-quality ICT products at competitive wholesale prices—ensuring exceptional value without compromising quality.

100% Quality Assurance:

All items are brand new, original, and factory-sealed.
Upon request, each unit can be fully tested and verified by a Cisco CCIE-certified engineer to ensure perfect working condition before shipment.

Free CCIE Technical Support:

Our Cisco CCIE-certified experts provide free professional support via phone, email, online chat, or remote login—helping you deploy and troubleshoot with confidence.

100% Money Back Guarantee:

If you are not satisfied with your purchase, you may request an exchange or full refund. Our customer service team will guide you through the return process quickly and smoothly. Visit Return Policy page for more information.

Flexible & Secure Payment and Shipping:

We support multiple secure payment and logistics options, backed by industry-leading verification:

Visit How to Pay page for more information

Warranty Coverage & RMA Instructions

Extended, Worry-Free Warranty Coverage Factory New Sealed Enterprise Hardware:
· 3 Years Factory New Sealed
Visit Warranty Policy page for more information

FREE NETWORK TOOLS

Verify, plan, and comparewith confidence

Use practical tools to check device details, review lifecyclemilestones, and compare hardware before you buy.

EOL EOSL checker
Check lifecycle dates
cisco switch selector tool

Cisco Switch Selector Tool

Filter Cisco switches by ports, uplinks, PoE, performance, features, license, and budget.

Find matching switches >
cisco sn check tool

Cisco Serial Number Lookup

Verify authenticity and identify exactmodel, coverage, and lifecycle detailsusing a Cisco serial number.

Verify a serial number >

Product Comparison

Compare specifications, capabilitiesand form factors side-by-side tochoose the right hardware.

Cisco Compare products >

DataSheet Downloads

  • C9300-24T-E Datasheet

  • Cisco Catalyst 9300 Switch Datasheet

Related Searches of Catalyst 9300 Switches
